SDO HMI 2014-08-02 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.02 | 142.87 | 17.82 | 79.28 | -18.88 | 238.22 | -10.30 | 158.03 | 0.4528 | -11.9 | 91.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-02 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.17 | 0.00 | 1.18 | -17.58 | 242.95 | -5.57 | 166.90 | 0.4099 | 865.0 | 623.5 | |
| 0.00 | 1.45 | 0.00 | 0.78 | -16.40 | 241.90 | -6.62 | 163.72 | 0.3959 | 892.0 | 704.4 | |
| 0.00 | 1.63 | 0.00 | 0.88 | -16.60 | 241.77 | -6.75 | 163.55 | 0.3996 | 663.0 | 574.9 | |
| 0.00 | 2.62 | 0.00 | 1.44 | -18.41 | 240.21 | -8.31 | 161.52 | 0.4344 | 824.0 | 716.2 | |
| 3.17 | 62.51 | 1.75 | 34.51 | -18.88 | 239.99 | -8.53 | 161.43 | 0.4425 | 963.3 | 613.1 | |
| 0.00 | 2.08 | 0.00 | 1.17 | -20.64 | 239.76 | -8.76 | 162.26 | 0.4695 | 658.0 | 482.3 | |
| 6.33 | -5.00 | 3.50 | -5.00 | -18.82 | 239.70 | -8.82 | 160.80 | 0.4430 | 958.9 | 999999 | |
| 5.34 | -5.00 | 2.95 | -5.00 | -18.76 | 239.38 | -9.14 | 160.10 | 0.4438 | 884.8 | 999999 | |
| 0.72 | -5.00 | 0.40 | -5.00 | -18.96 | 239.24 | -9.28 | 159.98 | 0.4475 | 485.0 | 999999 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -18.70 | 238.99 | -9.53 | 159.28 | 0.4450 | 777.0 | 675.3 | |
| 0.81 | -5.00 | 0.45 | -5.00 | -19.03 | 238.94 | -9.58 | 159.46 | 0.4502 | -420.0 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -18.63 | 238.80 | -9.72 | 158.85 | 0.4451 | 620.0 | 532.2 | |
| 0.54 | 2.44 | 0.30 | 1.35 | -18.97 | 238.58 | -9.94 | 158.71 | 0.4513 | 565.5 | 425.9 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -18.51 | 238.48 | -10.04 | 158.11 | 0.4451 | 728.0 | 608.0 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -18.34 | 238.30 | -10.22 | 157.60 | 0.4438 | 763.0 | 600.3 | |
| 0.00 | 4.25 | 0.00 | 2.35 | -18.64 | 238.21 | -10.31 | 157.70 | 0.4487 | 170.0 | 67.7 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -19.76 | 238.07 | -10.44 | 158.40 | 0.4654 | -586.0 | -519.8 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -18.99 | 237.60 | -10.92 | 156.84 | 0.4573 | -248.0 | -177.1 | |
| 0.00 | 10.40 | 0.00 | 5.79 | -18.93 | 237.21 | -11.31 | 156.06 | 0.4589 | -942.0 | -654.9 | |
| 1.00 | 2.99 | 0.56 | 1.67 | -19.54 | 236.94 | -11.58 | 156.11 | 0.4691 | -796.2 | -590.5 | |
| 0.00 | 2.44 | 0.00 | 1.37 | -19.35 | 236.56 | -11.96 | 155.24 | 0.4689 | -821.0 | -670.6 | |
| 10.22 | 16.65 | 5.71 | 9.30 | -18.98 | 236.42 | -12.10 | 154.64 | 0.4647 | -1042.8 | -753.7 | |
| 0.00 | 7.96 | 0.00 | 4.46 | -19.06 | 235.99 | -12.53 | 153.93 | 0.4686 | -744.0 | -698.2 | |
| 0.00 | 1.27 | 0.00 | 0.71 | -18.66 | 235.85 | -12.67 | 153.29 | 0.4641 | -846.0 | -674.0 | |
| 0.00 | 1.18 | 0.00 | 0.65 | -17.36 | 235.92 | -12.60 | 152.03 | 0.4458 | -860.0 | -707.8 | |
| 1.27 | 3.35 | 0.71 | 1.89 | -19.60 | 235.61 | -12.91 | 153.80 | 0.4786 | -877.7 | -656.9 | |
| 2.62 | 5.61 | 1.49 | 3.18 | -19.92 | 235.19 | -13.33 | 153.37 | 0.4858 | -912.2 | -673.7 | |
| 0.00 | 0.90 | 0.00 | 0.51 | -18.52 | 234.58 | -13.94 | 150.88 | 0.4714 | -779.0 | -546.3 | |
| 0.00 | 1.99 | 0.00 | 1.12 | -18.69 | 234.43 | -14.09 | 150.81 | 0.4748 | -817.0 | -611.8 | |
| 0.00 | 1.00 | 0.00 | 0.56 | -17.85 | 233.61 | -14.91 | 148.46 | 0.4701 | -876.0 | -716.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
