SDO HMI 2014-08-04 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.00 | 181.46 | 20.48 | 102.91 | -7.42 | 250.03 | 25.75 | 242.50 | 0.4875 | 385.0 | 335.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-04 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.90 | 0.00 | 0.56 | -7.30 | 259.05 | 34.77 | 249.49 | 0.6061 | 557.0 | 419.4 | |
| 0.00 | 1.72 | 0.00 | 1.07 | -7.08 | 258.99 | 34.71 | 249.80 | 0.6043 | 641.0 | 527.2 | |
| 0.00 | 0.90 | 0.00 | 0.56 | -8.63 | 258.39 | 34.11 | 247.03 | 0.6044 | 718.0 | 587.1 | |
| 0.00 | 1.45 | 0.00 | 0.87 | -5.71 | 256.97 | 32.69 | 250.86 | 0.5710 | 306.0 | 345.6 | |
| 0.00 | 0.72 | 0.00 | 0.43 | -5.48 | 256.70 | 32.42 | 251.09 | 0.5663 | 498.0 | 453.6 | |
| 2.17 | 14.84 | 1.26 | 8.57 | -6.84 | 252.63 | 28.35 | 246.01 | 0.5181 | 708.8 | 584.6 | |
| 6.06 | -6.00 | 3.50 | -6.00 | -6.76 | 252.42 | 28.14 | 245.97 | 0.5147 | 1008.6 | 999999 | |
| 0.00 | 2.71 | 0.00 | 1.56 | -5.98 | 252.30 | 28.02 | 247.30 | 0.5085 | 725.0 | 511.9 | |
| 4.07 | 20.99 | 2.35 | 12.09 | -7.32 | 252.28 | 28.00 | 244.88 | 0.5163 | 747.0 | -64.5 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -7.74 | 252.03 | 27.75 | 243.93 | 0.5156 | 371.0 | 256.7 | |
| 0.00 | 3.53 | 0.00 | 2.02 | -6.30 | 251.80 | 27.52 | 246.33 | 0.5034 | 718.0 | 602.5 | |
| 0.00 | 0.72 | 0.00 | 0.42 | -7.11 | 251.85 | 27.57 | 244.90 | 0.5091 | 609.0 | 375.6 | |
| 0.00 | 1.09 | 0.00 | 0.62 | -5.70 | 251.73 | 27.45 | 247.37 | 0.4990 | 877.0 | 709.3 | |
| 0.00 | 4.52 | 0.00 | 2.58 | -5.98 | 251.71 | 27.43 | 246.84 | 0.5003 | 716.0 | 726.6 | |
| 0.00 | 1.36 | 0.00 | 0.78 | -7.29 | 251.79 | 27.51 | 244.52 | 0.5095 | 521.0 | 409.7 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -5.48 | 251.69 | 27.41 | 247.75 | 0.4970 | 661.0 | 520.9 | |
| 0.00 | 1.27 | 0.00 | 0.73 | -8.86 | 251.80 | 27.52 | 241.80 | 0.5201 | -652.0 | -503.4 | |
| 0.00 | 2.71 | 0.00 | 1.55 | -5.91 | 251.54 | 27.26 | 246.83 | 0.4975 | 754.0 | 685.7 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -7.25 | 251.61 | 27.33 | 244.45 | 0.5069 | -569.0 | -395.3 | |
| 0.00 | 1.09 | 0.00 | 0.62 | -6.13 | 251.51 | 27.23 | 246.42 | 0.4984 | 757.0 | 633.5 | |
| 0.00 | 0.54 | 0.00 | 0.31 | -6.81 | 251.55 | 27.27 | 245.19 | 0.5032 | 575.0 | 412.0 | |
| 0.00 | 2.80 | 0.00 | 1.60 | -5.53 | 251.45 | 27.17 | 247.47 | 0.4940 | 944.0 | 786.5 | |
| 0.00 | 1.54 | 0.00 | 0.88 | -6.21 | 251.35 | 27.07 | 246.12 | 0.4966 | 796.0 | 664.5 | |
| 0.00 | 2.17 | 0.00 | 1.23 | -5.35 | 250.92 | 26.64 | 247.40 | 0.4856 | 843.0 | 657.3 | |
| 13.48 | 22.07 | 7.63 | 12.50 | -6.78 | 250.28 | 26.00 | 244.16 | 0.4856 | 988.9 | 596.5 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -10.73 | 250.02 | 25.74 | 236.95 | 0.5112 | -622.0 | -456.9 | |
| 3.08 | 50.39 | 1.73 | 28.28 | -7.27 | 249.39 | 25.11 | 242.43 | 0.4768 | 870.2 | 696.8 | |
| 4.25 | -27.00 | 2.39 | -27.00 | -7.17 | 249.22 | 24.94 | 242.45 | 0.4737 | 1140.1 | 999999 | |
| 0.00 | 2.62 | 0.00 | 1.51 | -11.42 | 249.26 | 24.98 | 235.00 | 0.5074 | -651.0 | -596.9 | |
| 2.89 | -27.00 | 1.62 | -27.00 | -7.37 | 248.79 | 24.51 | 241.65 | 0.4693 | 1070.2 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -11.42 | 249.09 | 24.81 | 234.82 | 0.5053 | -663.0 | -522.6 | |
| 0.00 | 2.26 | 0.00 | 1.29 | -10.14 | 248.88 | 24.60 | 236.75 | 0.4920 | -665.0 | -478.0 | |
| 0.00 | 4.79 | 0.00 | 2.69 | -7.86 | 248.55 | 24.27 | 240.49 | 0.4697 | 925.0 | 730.6 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -12.53 | 247.70 | 23.42 | 231.42 | 0.4983 | -794.0 | -687.0 | |
| 0.00 | 1.54 | 0.00 | 0.87 | -10.36 | 247.51 | 23.23 | 234.83 | 0.4766 | -834.0 | -587.7 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -12.90 | 247.22 | 22.94 | 230.26 | 0.4961 | -457.0 | -346.3 | |
| 0.00 | 1.45 | 0.00 | 0.79 | -6.37 | 246.63 | 22.35 | 241.35 | 0.4324 | 651.0 | 531.0 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -8.02 | 246.58 | 22.30 | 238.02 | 0.4448 | 729.0 | 653.0 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -8.30 | 246.57 | 22.29 | 237.46 | 0.4469 | 742.0 | 554.3 | |
| 0.00 | 1.81 | 0.00 | 1.00 | -7.70 | 246.50 | 22.22 | 238.54 | 0.4411 | 667.0 | 535.7 | |
| 0.00 | 2.80 | 0.00 | 1.54 | -6.26 | 246.36 | 22.08 | 241.27 | 0.4279 | 818.0 | 604.1 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -10.64 | 245.19 | 20.91 | 231.43 | 0.4505 | -630.0 | -460.8 | |
| 0.00 | 4.70 | 0.00 | 2.59 | -10.27 | 244.64 | 20.36 | 231.34 | 0.4402 | -795.0 | -636.6 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -5.84 | 244.41 | 20.13 | 239.83 | 0.3976 | -575.0 | -436.4 | |
| 0.00 | 0.72 | 0.00 | 0.40 | -9.76 | 244.57 | 20.29 | 232.17 | 0.4345 | -472.0 | -416.2 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -11.32 | 243.88 | 19.60 | 228.42 | 0.4416 | -768.0 | -644.8 | |
| 0.00 | 1.72 | 0.00 | 0.94 | -9.90 | 243.10 | 18.82 | 229.81 | 0.4178 | -688.0 | -457.3 | |
| 0.00 | 1.72 | 0.00 | 0.93 | -10.12 | 241.39 | 17.11 | 226.67 | 0.3999 | -869.0 | -685.6 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -7.28 | 241.01 | 16.73 | 231.70 | 0.3653 | -945.0 | -802.1 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -9.24 | 239.26 | 14.98 | 224.53 | 0.3654 | -717.0 | -593.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
