SDO HMI 2014-08-04 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.70 | 31.66 | 2.68 | 17.98 | -18.95 | 239.38 | 15.10 | 210.22 | 0.4899 | 106.6 | 63.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-04 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.81 | -19.80 | 245.85 | 21.57 | 218.91 | 0.5528 | 742.0 | 604.9 | |
| 0.00 | 2.17 | 0.00 | 1.24 | -16.11 | 244.98 | 20.70 | 222.54 | 0.5042 | 846.0 | 651.7 | |
| 0.00 | 0.45 | 0.00 | 0.27 | -20.64 | 243.89 | 19.61 | 215.34 | 0.5449 | 711.0 | 548.0 | |
| 0.00 | 1.54 | 0.00 | 0.88 | -17.93 | 242.44 | 18.16 | 216.50 | 0.5005 | 691.0 | 562.1 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -17.58 | 241.93 | 17.65 | 216.17 | 0.4918 | 848.0 | 675.9 | |
| 0.00 | 1.36 | 0.00 | 0.79 | -20.66 | 241.63 | 17.35 | 212.12 | 0.5267 | 634.0 | 539.1 | |
| 0.00 | 3.26 | 0.00 | 1.86 | -19.17 | 240.55 | 16.27 | 212.13 | 0.4996 | 667.0 | 530.4 | |
| 4.70 | 6.60 | 2.68 | 3.76 | -19.12 | 240.21 | 15.93 | 211.64 | 0.4963 | 992.5 | 770.8 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -19.64 | 239.39 | 15.11 | 209.76 | 0.4966 | 859.0 | 732.7 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -18.83 | 238.38 | 14.10 | 208.94 | 0.4786 | 784.0 | 469.4 | |
| 0.00 | 1.18 | 0.00 | 0.67 | -20.46 | 237.29 | 13.01 | 205.46 | 0.4927 | -749.0 | -587.6 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -18.12 | 236.68 | 12.40 | 206.66 | 0.4567 | -902.0 | -763.5 | |
| 0.00 | 1.63 | 0.00 | 0.91 | -19.36 | 236.47 | 12.19 | 205.07 | 0.4723 | -731.0 | -563.6 | |
| 0.00 | 1.72 | 0.00 | 0.97 | -19.72 | 236.27 | 11.99 | 204.36 | 0.4761 | -927.0 | -718.1 | |
| 0.00 | 1.72 | 0.00 | 0.97 | -19.75 | 236.04 | 11.76 | 203.92 | 0.4750 | -713.0 | -515.8 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -18.03 | 235.76 | 11.48 | 205.02 | 0.4492 | -651.0 | -485.1 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -19.89 | 234.73 | 10.45 | 201.41 | 0.4692 | -751.0 | -510.4 | |
| 0.00 | 1.99 | 0.00 | 1.10 | -18.56 | 234.00 | 9.72 | 201.12 | 0.4460 | -996.0 | -805.6 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -18.38 | 233.21 | 8.93 | 199.68 | 0.4390 | -817.0 | -695.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
