SDO HMI 2014-08-05 04:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 71.72 | 397.66 | 48.30 | 267.14 | 9.26 | 172.79 | -42.65 | 82.87 | 0.6757 | 239.9 | 184.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-05 04:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 0.91 | 4.44 | 182.04 | -33.40 | 91.15 | 0.5511 | -781.0 | -659.6 | |
| 0.00 | 1.00 | 0.00 | 0.59 | 5.06 | 181.23 | -34.21 | 89.94 | 0.5622 | -676.0 | -509.9 | |
| 0.00 | 1.27 | 0.00 | 0.76 | 6.76 | 180.63 | -34.81 | 86.88 | 0.5699 | -693.0 | -593.6 | |
| 0.00 | 2.17 | 0.00 | 1.31 | 6.83 | 180.14 | -35.31 | 86.76 | 0.5769 | -273.0 | -312.1 | |
| 0.00 | 1.00 | 0.00 | 0.62 | 11.48 | 177.67 | -37.78 | 79.07 | 0.6137 | -890.0 | -738.1 | |
| 0.00 | 1.18 | 0.00 | 0.74 | 11.65 | 177.56 | -37.89 | 78.80 | 0.6153 | -704.0 | -635.2 | |
| 4.79 | 12.30 | 3.00 | 7.70 | 9.82 | 177.59 | -37.85 | 81.79 | 0.6131 | -935.5 | -534.6 | |
| 0.00 | 0.45 | 0.00 | 0.28 | 11.36 | 177.37 | -38.08 | 79.29 | 0.6176 | -629.0 | -532.8 | |
| 0.00 | 1.36 | 0.00 | 0.85 | 12.00 | 177.26 | -38.18 | 78.27 | 0.6197 | -645.0 | -467.3 | |
| 2.99 | 11.76 | 1.88 | 7.40 | 10.23 | 177.30 | -38.14 | 81.14 | 0.6174 | -985.0 | -746.8 | |
| 2.26 | -10.00 | 1.42 | -10.00 | 10.04 | 177.21 | -38.24 | 81.46 | 0.6185 | -943.0 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.68 | 9.75 | 177.09 | -38.36 | 81.93 | 0.6199 | -605.0 | -509.3 | |
| 0.00 | 1.45 | 0.00 | 0.92 | 10.96 | 176.83 | -38.61 | 80.00 | 0.6243 | -855.0 | -686.2 | |
| 0.00 | 1.36 | 0.00 | 0.86 | 11.16 | 176.60 | -38.84 | 79.71 | 0.6276 | -637.0 | -573.0 | |
| 0.00 | 2.08 | 0.00 | 1.31 | 2.60 | 177.34 | -38.11 | 93.53 | 0.6199 | -642.0 | -546.0 | |
| 0.00 | 2.62 | 0.00 | 1.66 | 9.17 | 176.65 | -38.79 | 82.89 | 0.6255 | -768.0 | -638.0 | |
| 0.00 | 0.90 | 0.00 | 0.58 | 10.22 | 176.31 | -39.14 | 81.23 | 0.6307 | -562.0 | -458.2 | |
| 0.00 | 1.72 | 0.00 | 1.09 | 8.86 | 176.45 | -38.99 | 83.40 | 0.6281 | -794.0 | -631.9 | |
| 0.00 | 0.90 | 0.00 | 0.58 | 10.34 | 176.25 | -39.19 | 81.05 | 0.6316 | -464.0 | -424.3 | |
| 0.00 | 1.54 | 0.00 | 0.98 | 9.76 | 176.25 | -39.19 | 81.97 | 0.6312 | -870.0 | -678.6 | |
| 0.00 | 1.18 | 0.00 | 0.75 | 9.06 | 176.35 | -39.10 | 83.08 | 0.6296 | -574.0 | -440.6 | |
| 1.36 | 2.71 | 0.87 | 1.74 | 10.51 | 176.02 | -39.42 | 80.80 | 0.6347 | -669.1 | -533.1 | |
| 0.00 | 0.72 | 0.00 | 0.46 | 8.66 | 176.28 | -39.17 | 83.72 | 0.6304 | -497.0 | -412.1 | |
| 0.00 | 1.72 | 0.00 | 1.10 | 10.75 | 175.91 | -39.54 | 80.44 | 0.6365 | -686.0 | -542.2 | |
| 0.00 | 1.72 | 0.00 | 1.10 | 8.87 | 176.17 | -39.27 | 83.39 | 0.6319 | -601.0 | -479.0 | |
| 0.54 | 3.89 | 0.35 | 2.49 | 10.01 | 175.90 | -39.55 | 81.60 | 0.6361 | -660.7 | -527.4 | |
| 0.00 | 0.90 | 0.00 | 0.58 | 11.56 | 175.57 | -39.87 | 79.21 | 0.6416 | -547.0 | -433.6 | |
| 0.00 | 0.90 | 0.00 | 0.58 | 10.68 | 175.72 | -39.73 | 80.57 | 0.6389 | -269.0 | -251.8 | |
| 0.90 | 36.36 | 0.58 | 23.47 | 9.92 | 175.35 | -40.10 | 81.79 | 0.6433 | -339.1 | 5.5 | |
| 1.99 | 15.20 | 1.30 | 9.94 | 10.50 | 174.40 | -41.04 | 80.96 | 0.6560 | 1016.1 | 614.4 | |
| 0.00 | 1.90 | 0.00 | 1.24 | 7.86 | 174.77 | -40.68 | 85.00 | 0.6504 | -463.0 | -374.2 | |
| 0.00 | 1.09 | 0.00 | 0.71 | 9.22 | 174.51 | -40.93 | 82.91 | 0.6540 | 854.0 | 753.3 | |
| 2.17 | 12.66 | 1.42 | 8.31 | 9.81 | 174.30 | -41.14 | 82.01 | 0.6569 | 1014.4 | 749.7 | |
| 1.45 | -30.00 | 0.95 | -30.00 | 10.45 | 174.20 | -41.24 | 81.04 | 0.6586 | 882.1 | 999999 | |
| 2.35 | -33.00 | 1.54 | -33.00 | 10.08 | 174.18 | -41.27 | 81.60 | 0.6587 | 1071.3 | 999999 | |
| 0.00 | 2.35 | 0.00 | 1.54 | 8.80 | 174.24 | -41.20 | 83.56 | 0.6574 | -404.0 | -206.5 | |
| 0.00 | 1.72 | 0.00 | 1.13 | 7.03 | 174.33 | -41.11 | 86.26 | 0.6563 | 724.0 | 641.4 | |
| 0.00 | 1.27 | 0.00 | 0.84 | 9.38 | 173.83 | -41.62 | 82.68 | 0.6629 | 709.0 | 516.8 | |
| 0.54 | 1.63 | 0.36 | 1.08 | 10.02 | 173.69 | -41.75 | 81.73 | 0.6649 | 708.8 | 612.9 | |
| 0.00 | 0.90 | 0.00 | 0.60 | 10.65 | 173.51 | -41.94 | 80.79 | 0.6677 | 684.0 | 529.0 | |
| 0.00 | 2.71 | 0.00 | 1.80 | 9.39 | 173.41 | -42.03 | 82.69 | 0.6683 | 676.0 | 515.0 | |
| 0.00 | 1.36 | 0.00 | 0.90 | 9.98 | 173.20 | -42.25 | 81.81 | 0.6713 | 853.0 | 676.9 | |
| 0.00 | 0.81 | 0.00 | 0.54 | 6.75 | 173.33 | -42.11 | 86.65 | 0.6694 | 561.0 | 469.9 | |
| 0.00 | 1.18 | 0.00 | 0.79 | 10.86 | 172.59 | -42.86 | 80.54 | 0.6795 | 211.0 | 201.8 | |
| 0.00 | 1.18 | 0.00 | 0.79 | 9.73 | 172.56 | -42.88 | 82.22 | 0.6792 | 832.0 | 757.1 | |
| 0.00 | 1.36 | 0.00 | 0.92 | 10.70 | 172.06 | -43.38 | 80.81 | 0.6860 | 546.0 | 535.6 | |
| 1.18 | 246.13 | 0.80 | 169.42 | 9.60 | 172.08 | -43.37 | 82.43 | 0.6853 | 886.7 | 321.8 | |
| 0.63 | 2.08 | 0.43 | 1.40 | 6.33 | 172.50 | -42.94 | 87.24 | 0.6802 | -591.3 | -495.4 | |
| 1.00 | -47.00 | 0.68 | -47.00 | 9.31 | 171.82 | -43.62 | 82.86 | 0.6884 | 1020.3 | 999999 | |
| 5.16 | -47.00 | 3.52 | -47.00 | 9.51 | 171.75 | -43.70 | 82.56 | 0.6894 | 941.8 | 999999 | |
| 5.97 | -47.00 | 4.07 | -47.00 | 9.02 | 171.70 | -43.75 | 83.28 | 0.6900 | 971.8 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.43 | 10.29 | 171.45 | -44.00 | 81.45 | 0.6934 | 639.0 | 563.9 | |
| 0.27 | -47.00 | 0.19 | -47.00 | 9.29 | 171.57 | -43.88 | 82.89 | 0.6916 | 975.0 | 999999 | |
| 1.90 | -47.00 | 1.30 | -47.00 | 9.21 | 171.41 | -44.04 | 83.00 | 0.6936 | 941.0 | 999999 | |
| 4.88 | -47.00 | 3.36 | -47.00 | 9.32 | 171.22 | -44.23 | 82.85 | 0.6960 | 822.8 | 999999 | |
| 24.69 | -47.00 | 17.02 | -47.00 | 8.82 | 171.08 | -44.36 | 83.57 | 0.6976 | 874.5 | 999999 | |
| 1.99 | -47.00 | 1.38 | -47.00 | 9.51 | 170.88 | -44.56 | 82.58 | 0.7001 | 565.1 | 999999 | |
| 2.71 | -47.00 | 1.88 | -47.00 | 9.20 | 170.76 | -44.68 | 83.04 | 0.7016 | 599.9 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.56 | 6.89 | 171.04 | -44.41 | 86.35 | 0.6984 | 472.0 | 409.0 | |
| 0.00 | 1.00 | 0.00 | 0.69 | 6.88 | 170.82 | -44.62 | 86.36 | 0.7011 | 625.0 | 562.5 | |
| 0.00 | 1.18 | 0.00 | 0.87 | 9.52 | 166.92 | -48.52 | 82.64 | 0.7473 | 435.0 | 354.5 | |
| 0.00 | 0.72 | 0.00 | 0.55 | 10.17 | 166.18 | -49.27 | 81.78 | 0.7558 | 534.0 | 374.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
