SDO HMI 2014-08-05 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 10.31 | 0.00 | 6.93 | 12.99 | 253.21 | 42.16 | 283.01 | 0.6713 | 571.2 | 483.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-05 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.86 | 9.87 | 259.00 | 47.95 | 277.83 | 0.7407 | 422.0 | 390.7 | |
| 0.00 | 1.90 | 0.00 | 1.36 | 9.26 | 257.70 | 46.65 | 277.02 | 0.7254 | 568.0 | 473.0 | |
| 0.00 | 0.81 | 0.00 | 0.60 | 16.90 | 258.62 | 47.57 | 287.36 | 0.7422 | 446.0 | 398.3 | |
| 0.00 | 1.99 | 0.00 | 1.38 | 14.72 | 255.60 | 44.54 | 284.84 | 0.7041 | 656.0 | 510.8 | |
| 0.00 | 0.72 | 0.00 | 0.47 | 8.61 | 251.10 | 40.04 | 276.17 | 0.6421 | 511.0 | 476.4 | |
| 0.00 | 0.99 | 0.00 | 0.62 | 16.08 | 247.98 | 36.92 | 288.59 | 0.6113 | 620.0 | 508.9 | |
| 0.00 | 1.63 | 0.00 | 1.02 | 16.48 | 248.03 | 36.97 | 289.22 | 0.6130 | 624.0 | 530.0 | |
| 0.00 | 1.09 | 0.00 | 0.62 | 12.36 | 240.15 | 29.10 | 284.47 | 0.4926 | 723.0 | 564.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
