SDO HMI 2014-08-06 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.54 | 28.31 | 15.75 | 26.74 | -20.40 | 251.30 | 52.92 | 241.43 | 0.8534 | 359.1 | 160.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-06 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.23 | 17.72 | 6.94 | 17.00 | -20.01 | 252.06 | 53.68 | 242.16 | 0.8581 | 495.0 | 267.4 | |
| 6.87 | -1.00 | 6.60 | -1.00 | -20.31 | 251.99 | 53.60 | 241.81 | 0.8585 | 560.3 | 999999 | |
| 0.36 | 1.36 | 0.34 | 1.28 | -19.95 | 251.32 | 52.94 | 241.95 | 0.8520 | 434.0 | 395.4 | |
| 0.00 | 1.81 | 0.00 | 1.71 | -20.42 | 251.39 | 53.01 | 241.45 | 0.8541 | 453.0 | 420.5 | |
| 0.00 | 2.53 | 0.00 | 2.36 | -19.94 | 250.89 | 52.50 | 241.78 | 0.8485 | 397.0 | 290.5 | |
| 0.00 | 1.18 | 0.00 | 1.06 | -20.83 | 249.15 | 50.76 | 240.08 | 0.8374 | -338.0 | -253.8 | |
| 2.08 | 3.71 | 1.87 | 3.33 | -21.96 | 248.55 | 50.17 | 238.57 | 0.8368 | -606.3 | -457.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
