SDO HMI 2014-08-06 14:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.63 | 30.29 | 14.66 | 29.82 | -20.40 | 251.31 | 54.58 | 242.07 | 0.8663 | 288.5 | 87.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-06 14:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.47 | 18.26 | 12.57 | 18.39 | -20.21 | 252.24 | 55.51 | 242.64 | 0.8729 | 405.6 | 117.3 | |
| 0.45 | 1.36 | 0.45 | 1.34 | -19.90 | 251.73 | 55.00 | 242.79 | 0.8681 | 697.4 | 618.2 | |
| 0.63 | 1.54 | 0.63 | 1.53 | -20.26 | 251.69 | 54.96 | 242.38 | 0.8689 | 526.7 | 489.5 | |
| 0.00 | 1.54 | 0.00 | 1.51 | -20.04 | 251.46 | 54.74 | 242.54 | 0.8665 | 630.0 | 421.7 | |
| 0.00 | 0.72 | 0.00 | 0.69 | -20.49 | 250.14 | 53.41 | 241.54 | 0.8575 | 178.0 | 171.8 | |
| 0.00 | 1.27 | 0.00 | 1.20 | -20.54 | 249.62 | 52.89 | 241.28 | 0.8536 | -349.0 | -246.6 | |
| 0.00 | 0.81 | 0.00 | 0.77 | -20.79 | 249.47 | 52.75 | 240.94 | 0.8533 | -292.0 | -289.3 | |
| 0.00 | 0.90 | 0.00 | 0.84 | -20.82 | 249.00 | 52.27 | 240.72 | 0.8497 | -262.0 | -280.3 | |
| 1.08 | 2.71 | 1.01 | 2.53 | -21.99 | 248.53 | 51.80 | 239.24 | 0.8500 | -582.4 | -510.1 | |
| 0.00 | 1.18 | 0.00 | 1.02 | -20.46 | 246.10 | 49.37 | 239.86 | 0.8243 | 491.0 | 418.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
