SDO HMI 2014-08-06 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.31 | 50.51 | 28.86 | 67.95 | 11.08 | 126.48 | -69.15 | 80.47 | 0.9311 | -20.5 | 91.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-06 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.52 | 7.14 | 4.32 | 8.73 | 12.11 | 128.74 | -66.88 | 79.45 | 0.9164 | -526.1 | -468.4 | |
| 0.00 | 0.27 | 0.00 | 0.33 | 12.35 | 128.62 | -67.00 | 79.19 | 0.9172 | -426.0 | -393.3 | |
| 0.00 | 1.27 | 0.00 | 1.56 | 11.84 | 128.55 | -67.07 | 79.73 | 0.9177 | -16.0 | -26.8 | |
| 6.14 | 10.12 | 7.70 | 12.70 | 12.27 | 128.17 | -67.45 | 79.26 | 0.9202 | -368.4 | -197.9 | |
| 0.00 | 2.35 | 0.00 | 2.94 | 11.44 | 128.26 | -67.36 | 80.16 | 0.9198 | -200.0 | -130.8 | |
| 0.72 | 1.90 | 0.93 | 2.45 | 12.17 | 127.47 | -68.15 | 79.34 | 0.9248 | -38.5 | -3.9 | |
| 0.00 | 1.17 | 0.00 | 1.50 | 9.88 | 127.83 | -67.80 | 81.84 | 0.9231 | 398.0 | 400.6 | |
| 0.00 | 0.36 | 0.00 | 0.48 | 9.83 | 126.92 | -68.70 | 81.86 | 0.9290 | 400.0 | 292.8 | |
| 0.00 | 2.53 | 0.00 | 3.48 | 11.62 | 125.94 | -69.68 | 79.89 | 0.9346 | -247.0 | -106.5 | |
| 0.45 | 0.99 | 0.62 | 1.36 | 9.66 | 126.21 | -69.41 | 81.99 | 0.9335 | 448.2 | 402.0 | |
| 0.99 | 4.16 | 1.40 | 5.80 | 9.94 | 125.54 | -70.08 | 81.67 | 0.9375 | 365.4 | 341.5 | |
| 9.49 | 18.25 | 13.89 | 26.62 | 10.32 | 124.69 | -70.93 | 81.22 | 0.9423 | 268.8 | 394.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
