SDO HMI 2014-08-07 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 14.90 | 0.00 | 9.12 | -19.93 | 159.06 | -25.00 | 137.35 | 0.5882 | 516.0 | 487.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-07 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.90 | 0.00 | 1.12 | -19.61 | 162.77 | -21.29 | 141.41 | 0.5504 | 683.0 | 467.7 | |
| 0.00 | 0.72 | 0.00 | 0.44 | -20.21 | 159.84 | -24.22 | 138.55 | 0.5838 | 729.0 | 673.0 | |
| 0.00 | 2.17 | 0.00 | 1.29 | -17.58 | 159.65 | -24.41 | 135.00 | 0.5593 | 795.0 | 605.2 | |
| 0.00 | 5.42 | 0.00 | 3.33 | -20.46 | 159.01 | -25.05 | 137.91 | 0.5940 | 899.0 | 698.0 | |
| 0.00 | 1.08 | 0.00 | 0.65 | -16.75 | 159.00 | -25.06 | 133.14 | 0.5580 | 686.0 | 498.6 | |
| 0.00 | 1.17 | 0.00 | 0.73 | -21.14 | 158.20 | -25.86 | 137.84 | 0.6083 | 579.0 | 456.7 | |
| 0.00 | 1.36 | 0.00 | 0.85 | -21.41 | 157.67 | -26.39 | 137.59 | 0.6157 | 339.0 | 241.7 | |
| 0.00 | 1.08 | 0.00 | 0.71 | -21.89 | 154.45 | -29.60 | 134.96 | 0.6501 | -582.0 | -489.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
