SDO HMI 2014-08-07 20:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 88.58 | 465.19 | 71.48 | 374.14 | 12.11 | 127.93 | -52.26 | 79.40 | 0.7882 | -166.3 | -73.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-07 20:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.99 | 0.00 | 0.74 | 13.26 | 131.44 | -48.74 | 77.78 | 0.7509 | -381.0 | -322.3 | |
| 35.94 | 277.53 | 27.55 | 213.27 | 13.19 | 130.16 | -50.02 | 77.97 | 0.7651 | -1051.3 | -313.6 | |
| 14.27 | -2.00 | 11.04 | -2.00 | 13.68 | 129.73 | -50.46 | 77.36 | 0.7701 | -795.0 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.43 | 13.51 | 128.78 | -51.40 | 77.64 | 0.7802 | -71.0 | -73.3 | |
| 0.00 | 2.17 | 0.00 | 1.72 | 13.73 | 128.41 | -51.77 | 77.39 | 0.7842 | 267.0 | 200.9 | |
| 0.00 | 0.72 | 0.00 | 0.57 | 11.56 | 129.02 | -51.16 | 80.15 | 0.7768 | -406.0 | -317.1 | |
| 0.00 | 2.08 | 0.00 | 1.66 | 13.50 | 128.28 | -51.91 | 77.69 | 0.7855 | 357.0 | 270.3 | |
| 3.43 | 13.19 | 2.79 | 10.71 | 11.81 | 127.28 | -52.90 | 79.87 | 0.7953 | 714.9 | 510.1 | |
| 2.62 | 10.84 | 2.17 | 8.98 | 11.69 | 126.53 | -53.65 | 80.05 | 0.8030 | 751.8 | 547.6 | |
| 0.00 | 1.54 | 0.00 | 1.28 | 10.05 | 126.11 | -54.07 | 82.09 | 0.8072 | 791.0 | 660.2 | |
| 0.00 | 1.26 | 0.00 | 1.06 | 9.81 | 125.80 | -54.38 | 82.39 | 0.8104 | 575.0 | 509.2 | |
| 0.00 | 1.17 | 0.00 | 1.00 | 11.06 | 125.32 | -54.87 | 80.84 | 0.8152 | 432.0 | 412.4 | |
| 0.99 | 151.00 | 0.84 | 130.83 | 10.29 | 125.36 | -54.82 | 81.78 | 0.8148 | 845.4 | 218.4 | |
| 5.51 | -13.00 | 4.69 | -13.00 | 10.07 | 125.31 | -54.88 | 82.05 | 0.8153 | 878.6 | 999999 | |
| 1.35 | -13.00 | 1.16 | -13.00 | 10.79 | 125.06 | -55.12 | 81.17 | 0.8177 | 698.5 | 999999 | |
| 2.80 | -13.00 | 2.40 | -13.00 | 10.32 | 124.97 | -55.21 | 81.75 | 0.8186 | 859.1 | 999999 | |
| 1.72 | -13.00 | 1.47 | -13.00 | 10.04 | 124.99 | -55.20 | 82.08 | 0.8185 | 890.4 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.94 | 11.64 | 124.55 | -55.64 | 80.14 | 0.8228 | -72.0 | -49.0 | |
| 0.27 | -13.00 | 0.23 | -13.00 | 9.91 | 124.91 | -55.27 | 82.24 | 0.8192 | 677.3 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.95 | 11.64 | 124.27 | -55.92 | 80.13 | 0.8255 | 34.0 | 83.2 | |
| 3.34 | -13.00 | 2.90 | -13.00 | 10.53 | 124.53 | -55.65 | 81.49 | 0.8229 | 609.9 | 999999 | |
| 2.26 | -13.00 | 1.96 | -13.00 | 10.22 | 124.56 | -55.62 | 81.86 | 0.8227 | 624.0 | 999999 | |
| 0.27 | -13.00 | 0.24 | -13.00 | 10.67 | 124.38 | -55.80 | 81.32 | 0.8244 | 457.3 | 999999 | |
| 9.30 | -13.00 | 8.07 | -13.00 | 9.85 | 124.54 | -55.64 | 82.31 | 0.8229 | 605.6 | 999999 | |
| 3.34 | -13.00 | 2.93 | -13.00 | 10.49 | 124.10 | -56.08 | 81.53 | 0.8271 | 289.2 | 999999 | |
| 1.17 | -13.00 | 1.04 | -13.00 | 10.21 | 123.78 | -56.40 | 81.86 | 0.8302 | -420.5 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
