SDO HMI 2014-08-07 22:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 20.14 | 0.00 | 40.82 | -21.05 | 251.25 | 72.17 | 246.38 | 0.9702 | -137.4 | -82.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-07 22:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 0.60 | -20.38 | 252.78 | 73.71 | 247.39 | 0.9757 | 0.0 | -17.3 | |
| 0.00 | 1.08 | 0.00 | 2.36 | -20.47 | 252.44 | 73.36 | 247.23 | 0.9745 | 189.0 | 208.0 | |
| 0.00 | 8.58 | 0.00 | 18.96 | -20.95 | 252.60 | 73.52 | 246.77 | 0.9755 | -10.0 | -24.9 | |
| 0.00 | 2.35 | 0.00 | 5.22 | -21.28 | 252.56 | 73.49 | 246.44 | 0.9756 | -104.0 | -113.8 | |
| 0.00 | 1.54 | 0.00 | 2.76 | -20.67 | 249.28 | 70.21 | 246.37 | 0.9622 | -262.0 | -133.6 | |
| 0.00 | 0.99 | 0.00 | 1.81 | -21.34 | 249.33 | 70.25 | 245.70 | 0.9631 | -1.0 | 58.0 | |
| 0.00 | 0.90 | 0.00 | 1.53 | -20.69 | 248.27 | 69.19 | 246.11 | 0.9577 | -213.0 | -156.4 | |
| 0.00 | 1.81 | 0.00 | 3.09 | -21.36 | 248.30 | 69.22 | 245.44 | 0.9586 | -348.0 | -218.8 | |
| 0.00 | 2.62 | 0.00 | 4.49 | -21.66 | 248.24 | 69.16 | 245.12 | 0.9587 | -488.0 | -354.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
