SDO HMI 2014-08-09 23:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 122.11 | 676.44 | 66.40 | 366.37 | 12.62 | 129.16 | -22.92 | 72.00 | 0.4014 | -41.3 | -111.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-09 23:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.43 | 16.66 | 133.53 | -18.55 | 58.84 | 0.3576 | -705.0 | -605.9 | |
| 0.00 | 1.81 | 0.00 | 0.96 | 16.25 | 133.37 | -18.71 | 60.06 | 0.3569 | -648.0 | -445.5 | |
| 0.27 | 392.66 | 0.14 | 208.33 | 14.53 | 132.57 | -19.51 | 65.37 | 0.3572 | -1040.0 | -459.5 | |
| 60.75 | -3.00 | 32.23 | -3.00 | 14.12 | 132.27 | -19.81 | 66.73 | 0.3593 | -1397.9 | 999999 | |
| 0.27 | -3.00 | 0.14 | -3.00 | 14.13 | 131.67 | -20.41 | 67.24 | 0.3683 | -798.3 | 999999 | |
| 0.90 | -3.00 | 0.48 | -3.00 | 14.03 | 131.45 | -20.63 | 67.69 | 0.3711 | -595.2 | 999999 | |
| 0.36 | 6.05 | 0.19 | 3.23 | 13.33 | 130.94 | -21.14 | 69.87 | 0.3753 | -860.2 | -730.4 | |
| 0.00 | 0.72 | 0.00 | 0.39 | 12.66 | 130.87 | -21.21 | 71.67 | 0.3735 | -769.0 | -617.6 | |
| 0.54 | 1.53 | 0.29 | 0.83 | 12.92 | 129.77 | -22.31 | 71.71 | 0.3914 | 902.2 | 690.0 | |
| 0.00 | 0.90 | 0.00 | 0.49 | 12.55 | 129.63 | -22.45 | 72.72 | 0.3920 | 793.0 | 625.4 | |
| 0.00 | 0.90 | 0.00 | 0.49 | 12.02 | 129.51 | -22.57 | 74.10 | 0.3919 | 657.0 | 508.8 | |
| 0.00 | 0.99 | 0.00 | 0.54 | 12.17 | 127.29 | -24.79 | 74.82 | 0.4264 | 859.0 | 689.5 | |
| 0.00 | 1.17 | 0.00 | 0.65 | 12.27 | 126.77 | -25.31 | 74.82 | 0.4347 | 777.0 | 724.6 | |
| 0.00 | 0.99 | 0.00 | 0.54 | 9.56 | 126.81 | -25.27 | 81.07 | 0.4280 | 734.0 | 583.9 | |
| 0.00 | 1.08 | 0.00 | 0.60 | 12.47 | 126.50 | -25.58 | 74.48 | 0.4393 | 595.0 | 475.4 | |
| 0.00 | 1.99 | 0.00 | 1.09 | 12.26 | 126.49 | -25.59 | 74.97 | 0.4388 | 709.0 | 595.2 | |
| 0.00 | 1.17 | 0.00 | 0.64 | 7.91 | 126.79 | -25.29 | 84.93 | 0.4266 | 651.0 | 517.5 | |
| 0.00 | 2.08 | 0.00 | 1.14 | 12.01 | 126.41 | -25.67 | 75.56 | 0.4393 | 899.0 | 698.4 | |
| 0.00 | 1.08 | 0.00 | 0.59 | 10.28 | 126.54 | -25.54 | 79.47 | 0.4333 | 821.0 | 604.7 | |
| 0.00 | 2.89 | 0.00 | 1.59 | 10.09 | 126.45 | -25.63 | 79.92 | 0.4343 | 868.0 | 709.1 | |
| 0.00 | 1.44 | 0.00 | 0.80 | 11.57 | 126.11 | -25.97 | 76.66 | 0.4427 | -653.0 | -543.9 | |
| 0.00 | 2.44 | 0.00 | 1.35 | 9.85 | 125.82 | -26.26 | 80.62 | 0.4436 | 841.0 | 701.1 | |
| 0.00 | 1.17 | 0.00 | 0.65 | 11.24 | 125.66 | -26.42 | 77.54 | 0.4488 | 853.0 | 718.2 | |
| 0.54 | 5.15 | 0.30 | 2.85 | 11.54 | 125.49 | -26.59 | 76.94 | 0.4520 | 877.3 | 562.6 | |
| 3.25 | 246.70 | 1.80 | 137.79 | 10.13 | 125.49 | -26.59 | 80.05 | 0.4492 | 1097.6 | 399.4 | |
| 0.27 | -25.00 | 0.15 | -25.00 | 10.76 | 125.26 | -26.82 | 78.72 | 0.4539 | 1038.7 | 999999 | |
| 2.80 | -25.00 | 1.55 | -25.00 | 10.46 | 125.18 | -26.90 | 79.41 | 0.4545 | 1194.0 | 999999 | |
| 4.51 | -25.00 | 2.51 | -25.00 | 10.24 | 125.13 | -26.95 | 79.90 | 0.4549 | 1083.2 | 999999 | |
| 3.07 | -25.00 | 1.71 | -25.00 | 10.69 | 125.02 | -27.06 | 78.94 | 0.4574 | 1191.6 | 999999 | |
| 4.51 | -25.00 | 2.51 | -25.00 | 10.87 | 124.97 | -27.11 | 78.56 | 0.4585 | 979.8 | 999999 | |
| 9.84 | -25.00 | 5.48 | -25.00 | 10.56 | 124.86 | -27.22 | 79.26 | 0.4596 | 1168.3 | 999999 | |
| 0.00 | 0.72 | 0.00 | 0.40 | 11.50 | 124.76 | -27.32 | 77.25 | 0.4629 | 535.0 | 485.8 | |
| 4.87 | -25.00 | 2.72 | -25.00 | 10.15 | 124.55 | -27.53 | 80.22 | 0.4636 | 1008.2 | 999999 | |
| 17.60 | -25.00 | 9.85 | -25.00 | 10.60 | 124.40 | -27.68 | 79.29 | 0.4666 | 974.8 | 999999 | |
| 4.69 | -25.00 | 2.63 | -25.00 | 9.80 | 124.20 | -27.88 | 81.05 | 0.4684 | 1029.1 | 999999 | |
| 3.07 | -25.00 | 1.72 | -25.00 | 10.07 | 124.10 | -27.98 | 80.49 | 0.4702 | 850.9 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
