SDO HMI 2014-08-11 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.41 | 0.00 | 2.70 | -27.04 | 124.39 | -7.88 | 167.84 | 0.5772 | -631.2 | -490.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-11 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.35 | 0.00 | 0.80 | -26.02 | 135.16 | 2.89 | 184.83 | 0.5405 | -667.0 | -494.3 | |
| 0.00 | 0.99 | 0.00 | 0.62 | -29.78 | 124.41 | -7.86 | 168.62 | 0.6040 | -612.0 | -437.7 | |
| 0.00 | 0.81 | 0.00 | 0.52 | -30.61 | 119.56 | -12.71 | 162.49 | 0.6315 | -534.0 | -445.0 | |
| 0.00 | 0.36 | 0.00 | 0.22 | -23.51 | 116.44 | -15.83 | 153.20 | 0.5570 | -695.0 | -609.8 | |
| 0.00 | 0.90 | 0.00 | 0.54 | -23.41 | 116.28 | -15.99 | 152.89 | 0.5568 | -648.0 | -541.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
