SDO HMI 2014-08-11 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.26 | 78.26 | 27.14 | 147.57 | 14.15 | 55.30 | -75.87 | 77.02 | 0.9643 | -69.2 | -40.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-11 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.03 | 40.17 | 13.97 | 61.90 | 13.75 | 58.91 | -72.26 | 77.62 | 0.9486 | -398.8 | -259.9 | |
| 0.00 | 6.32 | 0.00 | 10.21 | 13.53 | 58.01 | -73.16 | 77.82 | 0.9533 | -356.0 | -196.1 | |
| 0.00 | 1.90 | 0.00 | 3.30 | 12.12 | 56.74 | -74.43 | 79.23 | 0.9600 | -412.0 | -367.1 | |
| 0.00 | 1.26 | 0.00 | 2.34 | 12.72 | 55.64 | -75.53 | 78.54 | 0.9649 | -139.0 | -132.7 | |
| 0.00 | 3.43 | 0.00 | 7.01 | 13.74 | 54.10 | -77.07 | 77.40 | 0.9712 | 348.0 | 297.2 | |
| 4.33 | 19.86 | 10.67 | 48.65 | 14.88 | 51.56 | -79.61 | 76.08 | 0.9803 | 346.2 | 213.7 | |
| 0.90 | 3.79 | 2.50 | 10.53 | 15.14 | 50.18 | -80.99 | 75.73 | 0.9846 | -84.6 | -61.8 | |
| 0.00 | 1.53 | 0.00 | 3.63 | 13.77 | 52.05 | -79.12 | 77.24 | 0.9789 | 424.0 | 381.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
