SDO HMI 2014-08-12 07:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.22 | 55.23 | 14.54 | 39.64 | -18.09 | 160.98 | 39.74 | 237.18 | 0.7254 | 553.5 | 284.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-12 07:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.26 | 0.00 | 0.98 | -17.92 | 166.01 | 44.76 | 240.30 | 0.7736 | 266.0 | 322.9 | |
| 12.73 | 24.19 | 9.24 | 17.55 | -16.65 | 162.53 | 41.29 | 239.92 | 0.7328 | 818.0 | 380.9 | |
| 0.00 | 1.90 | 0.00 | 1.37 | -16.77 | 162.01 | 40.77 | 239.47 | 0.7282 | 855.0 | 681.3 | |
| 0.00 | 1.35 | 0.00 | 0.98 | -19.65 | 160.63 | 39.39 | 235.12 | 0.7307 | 668.0 | 536.9 | |
| 0.00 | 0.81 | 0.00 | 0.58 | -19.71 | 159.98 | 38.73 | 234.64 | 0.7246 | 567.0 | 443.9 | |
| 6.59 | 9.66 | 4.67 | 6.85 | -19.11 | 159.65 | 38.40 | 235.13 | 0.7177 | 878.4 | 605.4 | |
| 0.00 | 2.80 | 0.00 | 2.00 | -19.96 | 159.76 | 38.52 | 234.19 | 0.7241 | 679.0 | 474.9 | |
| 0.00 | 1.26 | 0.00 | 0.89 | -18.86 | 159.46 | 38.21 | 235.30 | 0.7143 | 743.0 | 558.3 | |
| 0.00 | 1.35 | 0.00 | 0.96 | -19.43 | 159.45 | 38.20 | 234.61 | 0.7177 | 433.0 | 417.2 | |
| 0.00 | 1.72 | 0.00 | 1.22 | -19.75 | 159.25 | 38.00 | 234.09 | 0.7178 | 665.0 | 595.4 | |
| 0.00 | 2.17 | 0.00 | 1.53 | -19.92 | 158.80 | 37.56 | 233.58 | 0.7145 | 132.0 | 32.4 | |
| 0.00 | 0.90 | 0.00 | 0.63 | -19.66 | 158.49 | 37.24 | 233.67 | 0.7097 | -376.0 | -378.5 | |
| 0.00 | 0.99 | 0.00 | 0.70 | -19.90 | 158.55 | 37.31 | 233.43 | 0.7119 | -531.0 | -408.7 | |
| 0.90 | 3.88 | 0.63 | 2.71 | -19.38 | 158.33 | 37.09 | 233.90 | 0.7063 | -733.7 | -544.3 | |
| 0.00 | 0.99 | 0.00 | 0.69 | -20.40 | 157.47 | 36.23 | 232.06 | 0.7047 | -608.0 | -487.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
