SDO HMI 2014-08-12 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.11 | 162.82 | 33.92 | 176.89 | 14.03 | 54.38 | -63.57 | 77.52 | 0.8899 | -49.4 | 74.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-12 13:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.71 | 55.13 | 12.87 | 51.71 | 13.82 | 59.21 | -58.74 | 77.74 | 0.8515 | -655.1 | -279.8 | |
| 0.00 | 0.63 | 0.00 | 0.62 | 14.41 | 57.90 | -60.05 | 77.07 | 0.8630 | -445.0 | -347.1 | |
| 3.88 | 7.40 | 3.76 | 7.18 | 13.80 | 58.04 | -59.91 | 77.78 | 0.8618 | -489.6 | -284.3 | |
| 0.00 | 1.08 | 0.00 | 1.08 | 12.28 | 57.07 | -60.88 | 79.54 | 0.8700 | -442.0 | -466.2 | |
| 0.00 | 1.17 | 0.00 | 1.19 | 13.68 | 56.42 | -61.53 | 77.93 | 0.8754 | -501.0 | -472.2 | |
| 0.00 | 2.08 | 0.00 | 2.09 | 12.28 | 56.74 | -61.21 | 79.54 | 0.8727 | -579.0 | -446.9 | |
| 0.00 | 0.27 | 0.00 | 0.27 | 12.20 | 56.52 | -61.43 | 79.63 | 0.8746 | -256.0 | -238.7 | |
| 0.00 | 1.89 | 0.00 | 1.95 | 13.11 | 56.07 | -61.88 | 78.58 | 0.8783 | -541.0 | -380.4 | |
| 0.00 | 2.08 | 0.00 | 2.16 | 13.42 | 55.73 | -62.22 | 78.22 | 0.8810 | -485.0 | -353.7 | |
| 0.00 | 0.90 | 0.00 | 0.94 | 13.16 | 55.58 | -62.37 | 78.52 | 0.8822 | -266.0 | -239.5 | |
| 0.00 | 0.90 | 0.00 | 0.95 | 13.70 | 55.33 | -62.62 | 77.91 | 0.8842 | -257.0 | -161.5 | |
| 0.00 | 0.45 | 0.00 | 0.48 | 14.19 | 55.02 | -62.93 | 77.35 | 0.8866 | -165.0 | -229.8 | |
| 2.71 | 4.87 | 2.88 | 5.17 | 13.48 | 55.02 | -62.93 | 78.16 | 0.8867 | -204.9 | -161.1 | |
| 0.00 | 1.89 | 0.00 | 2.00 | 11.89 | 55.30 | -62.65 | 79.96 | 0.8846 | -305.0 | -314.9 | |
| 0.00 | 2.44 | 0.00 | 2.60 | 12.10 | 54.87 | -63.08 | 79.72 | 0.8879 | -408.0 | -234.4 | |
| 0.00 | 1.80 | 0.00 | 1.99 | 13.61 | 53.82 | -64.13 | 78.00 | 0.8959 | 246.0 | 270.8 | |
| 0.00 | 0.81 | 0.00 | 0.92 | 14.51 | 53.13 | -64.82 | 77.00 | 0.9010 | 546.0 | 475.3 | |
| 0.00 | 1.26 | 0.00 | 1.39 | 12.16 | 53.93 | -64.02 | 79.63 | 0.8952 | -95.0 | -107.6 | |
| 0.00 | 0.45 | 0.00 | 0.52 | 14.45 | 52.56 | -65.39 | 77.06 | 0.9051 | 486.0 | 446.4 | |
| 0.00 | 0.72 | 0.00 | 0.83 | 13.05 | 52.62 | -65.32 | 78.61 | 0.9048 | 453.0 | 470.5 | |
| 0.00 | 0.81 | 0.00 | 0.95 | 13.72 | 52.20 | -65.75 | 77.85 | 0.9078 | 519.0 | 509.2 | |
| 4.24 | 39.79 | 5.12 | 48.04 | 14.76 | 51.36 | -66.59 | 76.70 | 0.9136 | 601.0 | 408.0 | |
| 0.63 | 3.34 | 0.74 | 3.93 | 13.47 | 52.10 | -65.85 | 78.14 | 0.9085 | 525.4 | 458.1 | |
| 2.17 | -22.00 | 2.64 | -22.00 | 15.11 | 51.06 | -66.89 | 76.32 | 0.9156 | 622.5 | 999999 | |
| 1.17 | -22.00 | 1.42 | -22.00 | 14.48 | 51.29 | -66.65 | 77.01 | 0.9140 | 523.4 | 999999 | |
| 0.00 | 1.62 | 0.00 | 1.90 | 12.71 | 52.27 | -65.68 | 78.98 | 0.9074 | 156.0 | 165.0 | |
| 0.00 | 1.17 | 0.00 | 1.40 | 13.67 | 51.68 | -66.27 | 77.90 | 0.9114 | 444.0 | 406.6 | |
| 0.00 | 0.81 | 0.00 | 1.01 | 15.25 | 50.57 | -67.38 | 76.16 | 0.9189 | 289.0 | 309.0 | |
| 0.00 | 1.17 | 0.00 | 1.45 | 14.79 | 50.69 | -67.25 | 76.66 | 0.9181 | 364.0 | 302.9 | |
| 1.35 | 9.02 | 1.61 | 10.73 | 12.69 | 51.81 | -66.14 | 78.99 | 0.9107 | 439.3 | 377.7 | |
| 1.53 | 3.52 | 1.96 | 4.50 | 15.74 | 49.81 | -68.14 | 75.62 | 0.9238 | 352.1 | 198.2 | |
| 0.00 | 2.08 | 0.00 | 2.66 | 15.49 | 49.82 | -68.13 | 75.90 | 0.9238 | 381.0 | 260.8 | |
| 0.00 | 2.53 | 0.00 | 3.16 | 14.46 | 50.49 | -67.46 | 77.02 | 0.9195 | 453.0 | 346.3 | |
| 0.00 | 1.26 | 0.00 | 1.61 | 15.00 | 49.98 | -67.97 | 76.43 | 0.9228 | 335.0 | 302.3 | |
| 0.72 | 3.34 | 0.92 | 4.25 | 14.75 | 49.97 | -67.98 | 76.70 | 0.9229 | 189.4 | 219.6 | |
| 0.00 | 1.35 | 0.00 | 1.69 | 13.73 | 50.44 | -67.51 | 77.81 | 0.9199 | 298.0 | 244.4 | |
| 0.00 | 0.90 | 0.00 | 1.17 | 15.23 | 49.47 | -68.47 | 76.17 | 0.9260 | 73.0 | 58.3 | |
| 0.00 | 1.89 | 0.00 | 2.40 | 13.97 | 50.04 | -67.91 | 77.54 | 0.9225 | 80.0 | 19.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
