SDO HMI 2014-08-12 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 66.28 | 422.96 | 34.75 | 221.44 | 14.78 | 133.46 | 17.17 | 297.58 | 0.3231 | -816.9 | -367.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-12 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.03 | 396.56 | 33.62 | 208.10 | 14.98 | 133.96 | 17.67 | 297.50 | 0.3319 | -1452.0 | -435.7 | |
| 0.00 | 1.26 | 0.00 | 0.66 | 14.72 | 132.42 | 16.13 | 298.73 | 0.3078 | -870.0 | -567.0 | |
| 0.00 | 2.07 | 0.00 | 1.08 | 17.83 | 129.56 | 13.27 | 312.38 | 0.2970 | -917.0 | -671.0 | |
| 0.00 | 1.44 | 0.00 | 0.73 | 12.44 | 127.15 | 10.85 | 299.86 | 0.2130 | 889.0 | 674.6 | |
| 0.00 | 1.17 | 0.00 | 0.59 | 12.27 | 126.79 | 10.50 | 299.90 | 0.2063 | 815.0 | 701.8 | |
| 0.00 | 1.44 | 0.00 | 0.73 | 11.73 | 126.01 | 9.72 | 299.33 | 0.1905 | 965.0 | 844.0 | |
| 0.00 | 1.17 | 0.00 | 0.59 | 8.79 | 125.67 | 9.38 | 284.44 | 0.1670 | 811.0 | 622.2 | |
| 0.00 | 2.80 | 0.00 | 1.41 | 10.86 | 125.57 | 9.28 | 296.07 | 0.1772 | 870.0 | 778.0 | |
| 0.00 | 1.53 | 0.00 | 0.77 | 10.68 | 125.16 | 8.87 | 296.13 | 0.1695 | 1040.0 | 856.0 | |
| 0.00 | 1.08 | 0.00 | 0.54 | 10.87 | 124.79 | 8.50 | 298.10 | 0.1653 | 928.0 | 806.9 | |
| 0.00 | 4.24 | 0.00 | 2.13 | 10.91 | 124.54 | 8.25 | 298.98 | 0.1618 | 963.0 | 873.8 | |
| 0.00 | 1.71 | 0.00 | 0.86 | 10.39 | 124.37 | 8.08 | 296.54 | 0.1553 | 1072.0 | 858.3 | |
| 0.00 | 1.08 | 0.00 | 0.54 | 11.22 | 124.36 | 8.07 | 301.18 | 0.1617 | 969.0 | 734.4 | |
| 2.25 | 4.15 | 1.13 | 2.08 | 10.22 | 124.15 | 7.86 | 296.09 | 0.1505 | 1205.4 | 986.7 | |
| 0.00 | 1.26 | 0.00 | 0.63 | 11.38 | 123.40 | 7.11 | 305.34 | 0.1494 | 914.0 | 648.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
