SDO HMI 2014-08-12 21:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.41 | 212.46 | 33.51 | 203.14 | 13.92 | 54.13 | -59.39 | 77.63 | 0.8556 | -68.3 | 128.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-12 21:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.17 | 61.31 | 10.19 | 51.34 | 13.79 | 59.34 | -54.19 | 77.66 | 0.8084 | -1015.8 | -354.8 | |
| 1.71 | -1.00 | 1.45 | -1.00 | 13.94 | 58.96 | -54.56 | 77.49 | 0.8122 | -308.6 | 999999 | |
| 5.77 | 9.47 | 4.98 | 8.17 | 13.83 | 58.07 | -55.46 | 77.66 | 0.8209 | -647.9 | -371.0 | |
| 1.98 | 4.69 | 1.75 | 4.15 | 12.40 | 57.04 | -56.48 | 79.42 | 0.8305 | -717.3 | -597.9 | |
| 0.00 | 1.17 | 0.00 | 1.06 | 14.37 | 56.21 | -57.31 | 77.07 | 0.8386 | -474.0 | -460.6 | |
| 0.00 | 1.98 | 0.00 | 1.79 | 14.03 | 56.23 | -57.30 | 77.48 | 0.8384 | -594.0 | -484.0 | |
| 0.00 | 1.26 | 0.00 | 1.15 | 13.39 | 56.00 | -57.52 | 78.25 | 0.8403 | -459.0 | -460.1 | |
| 0.00 | 0.81 | 0.00 | 0.74 | 13.56 | 55.82 | -57.70 | 78.05 | 0.8420 | -493.0 | -396.3 | |
| 0.00 | 1.26 | 0.00 | 1.16 | 13.39 | 55.71 | -57.81 | 78.25 | 0.8430 | -511.0 | -459.4 | |
| 0.00 | 0.81 | 0.00 | 0.75 | 13.19 | 55.60 | -57.92 | 78.48 | 0.8439 | -475.0 | -409.9 | |
| 0.00 | 1.26 | 0.00 | 1.16 | 12.90 | 55.48 | -58.05 | 78.83 | 0.8451 | -236.0 | -201.1 | |
| 0.99 | 6.13 | 0.92 | 5.68 | 13.52 | 55.12 | -58.40 | 78.10 | 0.8484 | -118.3 | -259.8 | |
| 0.00 | 1.17 | 0.00 | 1.07 | 12.05 | 55.66 | -57.86 | 79.84 | 0.8434 | -622.0 | -497.6 | |
| 0.00 | 0.27 | 0.00 | 0.25 | 13.93 | 54.84 | -58.68 | 77.63 | 0.8510 | -84.0 | -92.7 | |
| 0.00 | 0.63 | 0.00 | 0.58 | 11.73 | 55.47 | -58.05 | 80.23 | 0.8451 | -485.0 | -424.3 | |
| 0.00 | 3.52 | 0.00 | 3.26 | 11.98 | 55.21 | -58.31 | 79.92 | 0.8475 | -364.0 | -370.1 | |
| 0.00 | 0.27 | 0.00 | 0.25 | 11.86 | 55.25 | -58.27 | 80.07 | 0.8471 | -450.0 | -396.3 | |
| 0.00 | 0.63 | 0.00 | 0.60 | 12.29 | 54.50 | -59.02 | 79.56 | 0.8539 | -123.0 | -58.0 | |
| 0.00 | 0.81 | 0.00 | 0.80 | 14.51 | 53.09 | -60.43 | 76.98 | 0.8662 | 510.0 | 470.6 | |
| 0.00 | 1.17 | 0.00 | 1.13 | 12.56 | 53.78 | -59.74 | 79.24 | 0.8602 | 373.0 | 343.9 | |
| 0.00 | 0.81 | 0.00 | 0.81 | 14.74 | 52.53 | -60.99 | 76.73 | 0.8709 | 558.0 | 522.6 | |
| 0.00 | 3.70 | 0.00 | 3.59 | 12.10 | 53.58 | -59.94 | 79.77 | 0.8620 | -221.0 | -145.6 | |
| 0.00 | 2.52 | 0.00 | 2.47 | 12.42 | 53.33 | -60.19 | 79.40 | 0.8641 | 632.0 | 489.6 | |
| 1.17 | 2.52 | 1.14 | 2.46 | 11.81 | 53.44 | -60.09 | 80.11 | 0.8632 | -234.2 | -125.8 | |
| 3.88 | 7.21 | 3.90 | 7.26 | 13.32 | 52.33 | -61.19 | 78.37 | 0.8726 | 740.0 | 568.2 | |
| 0.00 | 3.88 | 0.00 | 3.96 | 13.61 | 51.87 | -61.65 | 78.03 | 0.8763 | 661.0 | 560.2 | |
| 3.16 | 49.77 | 3.29 | 51.57 | 14.86 | 51.21 | -62.32 | 76.61 | 0.8817 | 873.6 | 562.1 | |
| 1.26 | -27.00 | 1.31 | -27.00 | 14.37 | 51.31 | -62.21 | 77.17 | 0.8809 | 753.3 | 999999 | |
| 0.90 | -27.00 | 0.94 | -27.00 | 14.58 | 51.21 | -62.31 | 76.93 | 0.8817 | 764.4 | 999999 | |
| 0.00 | 2.07 | 0.00 | 2.13 | 13.25 | 51.70 | -61.83 | 78.44 | 0.8778 | 639.0 | 518.9 | |
| 0.00 | 11.63 | 0.00 | 11.88 | 12.65 | 51.82 | -61.70 | 79.13 | 0.8768 | 282.0 | 256.0 | |
| 0.00 | 1.71 | 0.00 | 1.81 | 14.94 | 50.75 | -62.77 | 76.52 | 0.8853 | 443.0 | 369.3 | |
| 0.00 | 1.35 | 0.00 | 1.42 | 14.52 | 50.97 | -62.56 | 76.99 | 0.8837 | 342.0 | 427.3 | |
| 0.90 | 2.07 | 0.97 | 2.22 | 15.58 | 50.34 | -63.19 | 75.80 | 0.8887 | 441.2 | 393.7 | |
| 0.00 | 1.26 | 0.00 | 1.35 | 15.43 | 50.42 | -63.10 | 75.96 | 0.8880 | 634.0 | 565.4 | |
| 1.44 | 2.89 | 1.49 | 2.98 | 13.07 | 51.44 | -62.08 | 78.64 | 0.8799 | 520.1 | 425.0 | |
| 0.54 | 2.25 | 0.59 | 2.45 | 15.85 | 49.90 | -63.62 | 75.50 | 0.8920 | 338.5 | 255.6 | |
| 0.00 | 3.52 | 0.00 | 3.76 | 14.65 | 50.41 | -63.11 | 76.85 | 0.8880 | 587.0 | 438.8 | |
| 0.00 | 1.98 | 0.00 | 2.14 | 14.88 | 50.22 | -63.30 | 76.59 | 0.8895 | 360.0 | 315.8 | |
| 0.00 | 3.52 | 0.00 | 3.83 | 15.13 | 49.87 | -63.65 | 76.31 | 0.8922 | 486.0 | 415.1 | |
| 0.00 | 2.16 | 0.00 | 2.37 | 15.61 | 49.61 | -63.91 | 75.78 | 0.8942 | 258.0 | 203.7 | |
| 0.00 | 0.90 | 0.00 | 0.97 | 14.48 | 50.22 | -63.30 | 77.05 | 0.8895 | 275.0 | 196.5 | |
| 0.00 | 0.99 | 0.00 | 1.05 | 13.52 | 50.62 | -62.90 | 78.13 | 0.8864 | 247.0 | 257.3 | |
| 0.00 | 1.26 | 0.00 | 1.37 | 14.89 | 49.94 | -63.59 | 76.59 | 0.8917 | 315.0 | 266.5 | |
| 0.54 | 1.89 | 0.59 | 2.06 | 14.32 | 49.88 | -63.64 | 77.22 | 0.8921 | 212.0 | 136.5 | |
| 0.00 | 1.98 | 0.00 | 2.14 | 13.84 | 50.12 | -63.40 | 77.76 | 0.8903 | 177.0 | 112.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
