SDO HMI 2014-08-13 08:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.16 | 8.74 | 1.56 | 4.34 | 7.30 | 106.62 | -0.86 | 285.37 | 0.0240 | -181.9 | -87.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-13 08:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.17 | 0.00 | 0.58 | 7.33 | 107.83 | 0.36 | 335.63 | 0.0150 | -937.0 | -833.0 | |
| 3.16 | 5.05 | 1.56 | 2.50 | 7.36 | 107.19 | -0.29 | 19.31 | 0.0151 | -1133.0 | -783.6 | |
| 0.00 | 1.08 | 0.00 | 0.54 | 7.26 | 105.05 | -2.43 | 73.31 | 0.0441 | 937.0 | 838.1 | |
| 0.00 | 1.44 | 0.00 | 0.72 | 7.11 | 104.83 | -2.64 | 77.72 | 0.0471 | 938.0 | 736.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
