SDO HMI 2014-08-14 19:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.37 | 39.54 | 10.93 | 22.35 | -17.32 | 104.26 | 16.07 | 213.33 | 0.4826 | 402.9 | 298.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-14 19:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.80 | 0.00 | 1.02 | -17.31 | 105.36 | 17.17 | 215.13 | 0.4918 | 809.0 | 588.0 | |
| 0.00 | 2.52 | 0.00 | 1.44 | -18.01 | 105.30 | 17.11 | 214.19 | 0.4998 | 861.0 | 620.3 | |
| 2.07 | 20.00 | 1.18 | 11.36 | -17.37 | 105.10 | 16.91 | 214.65 | 0.4903 | 1069.0 | 668.8 | |
| 0.00 | 0.81 | 0.00 | 0.46 | -17.66 | 104.96 | 16.77 | 214.08 | 0.4927 | 643.0 | 626.7 | |
| 6.49 | -3.00 | 3.68 | -3.00 | -17.62 | 104.79 | 16.60 | 213.86 | 0.4908 | 1027.2 | 999999 | |
| 3.69 | -3.00 | 2.10 | -3.00 | -17.82 | 104.65 | 16.46 | 213.39 | 0.4920 | 854.8 | 999999 | |
| 1.08 | 12.52 | 0.60 | 7.00 | -16.58 | 103.41 | 15.22 | 212.84 | 0.4660 | -804.2 | -677.7 | |
| 0.00 | 1.89 | 0.00 | 1.07 | -17.67 | 103.27 | 15.08 | 211.32 | 0.4789 | 870.0 | 686.5 | |
| 6.04 | -7.00 | 3.37 | -7.00 | -16.60 | 103.06 | 14.87 | 212.19 | 0.4633 | -1044.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
