SDO HMI 2014-08-15 18:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.07 | 11.16 | 1.79 | 8.78 | -5.88 | 26.14 | -49.38 | 103.20 | 0.7761 | 306.1 | 237.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-15 18:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.62 | 0.00 | 1.17 | -5.14 | 30.11 | -45.41 | 103.49 | 0.7317 | 546.0 | 432.2 | |
| 0.00 | 0.99 | 0.00 | 0.73 | -5.13 | 29.19 | -46.34 | 103.16 | 0.7422 | 659.0 | 565.6 | |
| 0.00 | 1.26 | 0.00 | 0.93 | -4.70 | 29.10 | -46.43 | 102.58 | 0.7421 | 730.0 | 602.9 | |
| 0.00 | 0.90 | 0.00 | 0.67 | -5.25 | 28.87 | -46.66 | 103.22 | 0.7462 | 573.0 | 484.3 | |
| 0.00 | 1.98 | 0.00 | 1.47 | -4.92 | 28.77 | -46.76 | 102.75 | 0.7465 | 596.0 | 441.7 | |
| 2.07 | 4.41 | 1.79 | 3.81 | -7.03 | 22.13 | -53.40 | 103.43 | 0.8213 | -573.0 | -392.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
