SDO HMI 2014-08-16 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 92.83 | 373.39 | 58.99 | 234.69 | 16.10 | 23.76 | -37.44 | 72.18 | 0.6141 | 27.2 | -104.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-16 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.80 | 168.19 | 1.07 | 100.36 | 16.22 | 28.18 | -33.02 | 70.71 | 0.5566 | -1176.2 | -434.6 | |
| 15.67 | -1.00 | 9.35 | -1.00 | 15.92 | 27.86 | -33.34 | 71.35 | 0.5600 | -1246.6 | 999999 | |
| 8.64 | -1.00 | 5.17 | -1.00 | 16.16 | 27.77 | -33.43 | 70.95 | 0.5619 | -1078.0 | 999999 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 18.21 | 26.81 | -34.39 | 67.82 | 0.5816 | -549.0 | -501.0 | |
| 13.51 | 16.75 | 8.19 | 10.16 | 16.17 | 26.47 | -34.73 | 71.38 | 0.5796 | -880.7 | -527.3 | |
| 0.00 | 2.88 | 0.00 | 1.76 | 16.86 | 26.02 | -35.18 | 70.39 | 0.5876 | -744.0 | -611.6 | |
| 0.00 | 1.08 | 0.00 | 0.66 | 16.45 | 26.06 | -35.14 | 71.04 | 0.5858 | -508.0 | -327.1 | |
| 0.00 | 2.70 | 0.00 | 1.65 | 15.51 | 25.79 | -35.41 | 72.72 | 0.5869 | -652.0 | -557.4 | |
| 0.00 | 0.81 | 0.00 | 0.50 | 17.17 | 25.21 | -35.99 | 70.13 | 0.5992 | -607.0 | -467.0 | |
| 0.00 | 1.08 | 0.00 | 0.66 | 15.34 | 25.55 | -35.65 | 73.07 | 0.5897 | -669.0 | -529.1 | |
| 0.00 | 2.43 | 0.00 | 1.49 | 15.45 | 25.37 | -35.83 | 72.93 | 0.5923 | -496.0 | -391.1 | |
| 0.99 | 2.07 | 0.61 | 1.29 | 17.31 | 24.82 | -36.38 | 70.05 | 0.6046 | -760.4 | -648.7 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 15.07 | 25.18 | -36.02 | 73.63 | 0.5941 | -597.0 | -449.8 | |
| 0.00 | 1.35 | 0.00 | 0.84 | 16.78 | 24.46 | -36.74 | 71.01 | 0.6078 | -664.0 | -515.5 | |
| 0.00 | 1.80 | 0.00 | 1.12 | 17.05 | 24.32 | -36.88 | 70.62 | 0.6104 | -455.0 | -380.2 | |
| 0.00 | 2.34 | 0.00 | 1.52 | 17.14 | 21.55 | -39.65 | 71.28 | 0.6462 | 1000.0 | 749.9 | |
| 0.00 | 0.99 | 0.00 | 0.64 | 17.32 | 21.46 | -39.74 | 71.02 | 0.6477 | 426.0 | 470.0 | |
| 8.82 | 16.39 | 5.77 | 10.70 | 15.71 | 20.66 | -40.55 | 73.67 | 0.6544 | 920.4 | 654.8 | |
| 0.00 | 1.35 | 0.00 | 0.87 | 13.70 | 21.06 | -40.14 | 76.67 | 0.6459 | 636.0 | 466.6 | |
| 5.76 | 16.93 | 3.80 | 11.16 | 16.41 | 20.10 | -41.10 | 72.72 | 0.6626 | 910.2 | 656.2 | |
| 0.00 | 0.99 | 0.00 | 0.66 | 17.72 | 19.71 | -41.49 | 70.87 | 0.6702 | 548.0 | 478.8 | |
| 0.00 | 1.53 | 0.00 | 1.03 | 19.16 | 19.28 | -41.92 | 68.87 | 0.6788 | 738.0 | 543.8 | |
| 0.00 | 1.26 | 0.00 | 0.84 | 16.20 | 19.78 | -41.42 | 73.11 | 0.6663 | 638.0 | 560.7 | |
| 17.56 | 63.75 | 11.63 | 42.22 | 15.70 | 19.73 | -41.47 | 73.86 | 0.6659 | 990.3 | 334.4 | |
| 13.06 | 65.28 | 8.70 | 43.68 | 16.52 | 19.44 | -41.76 | 72.71 | 0.6710 | 835.7 | 110.4 | |
| 1.89 | -25.00 | 1.27 | -25.00 | 16.87 | 19.18 | -42.02 | 72.24 | 0.6750 | 487.8 | 999999 | |
| 0.90 | -24.00 | 0.60 | -24.00 | 15.73 | 19.26 | -41.94 | 73.91 | 0.6718 | 469.3 | 999999 | |
| 4.23 | -25.00 | 2.83 | -25.00 | 16.15 | 19.11 | -42.09 | 73.32 | 0.6744 | 602.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
