SDO HMI 2014-08-17 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 90.11 | 363.14 | 52.63 | 209.95 | 16.15 | 24.62 | -29.98 | 69.35 | 0.5133 | -126.8 | -124.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-17 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.99 | 0.00 | 0.54 | 15.19 | 30.01 | -24.59 | 68.63 | 0.4331 | -667.0 | -497.5 | |
| 2.52 | 187.09 | 1.41 | 104.39 | 16.22 | 28.51 | -26.09 | 67.34 | 0.4595 | -1188.6 | -409.0 | |
| 13.07 | -2.00 | 7.29 | -2.00 | 16.15 | 28.27 | -26.33 | 67.64 | 0.4625 | -1230.6 | 999999 | |
| 17.66 | -2.00 | 9.87 | -2.00 | 15.83 | 28.11 | -26.49 | 68.40 | 0.4635 | -1239.8 | 999999 | |
| 0.27 | -2.00 | 0.15 | -2.00 | 15.94 | 27.70 | -26.90 | 68.42 | 0.4697 | -758.3 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.61 | 18.26 | 27.09 | -27.51 | 64.17 | 0.4893 | -661.0 | -505.8 | |
| 0.00 | 0.90 | 0.00 | 0.51 | 17.32 | 26.92 | -27.68 | 66.11 | 0.4870 | -673.0 | -452.7 | |
| 10.99 | 14.33 | 6.21 | 8.10 | 16.20 | 26.81 | -27.79 | 68.39 | 0.4835 | -903.0 | -582.4 | |
| 0.00 | 0.99 | 0.00 | 0.56 | 17.51 | 26.42 | -28.18 | 66.04 | 0.4948 | -477.0 | -418.9 | |
| 0.00 | 1.26 | 0.00 | 0.72 | 17.18 | 25.42 | -29.18 | 67.24 | 0.5071 | -916.0 | -781.9 | |
| 0.00 | 1.71 | 0.00 | 0.98 | 16.13 | 25.45 | -29.15 | 69.24 | 0.5024 | -767.0 | -613.1 | |
| 0.00 | 2.07 | 0.00 | 1.19 | 16.26 | 25.07 | -29.53 | 69.17 | 0.5083 | -828.0 | -714.4 | |
| 0.00 | 1.53 | 0.00 | 0.88 | 16.72 | 24.96 | -29.65 | 68.35 | 0.5117 | -775.0 | -604.8 | |
| 0.00 | 5.32 | 0.00 | 3.06 | 16.44 | 24.97 | -29.64 | 68.88 | 0.5104 | -811.0 | -669.7 | |
| 0.00 | 0.72 | 0.00 | 0.42 | 17.33 | 24.81 | -29.79 | 67.28 | 0.5162 | -717.0 | -603.4 | |
| 0.00 | 1.98 | 0.00 | 1.15 | 17.04 | 24.64 | -29.96 | 67.90 | 0.5173 | -648.0 | -455.9 | |
| 0.00 | 0.90 | 0.00 | 0.52 | 16.54 | 24.58 | -30.02 | 68.87 | 0.5162 | -673.0 | -548.8 | |
| 0.54 | 1.71 | 0.31 | 0.99 | 16.62 | 24.31 | -30.29 | 68.85 | 0.5202 | -547.7 | -405.2 | |
| 0.00 | 1.53 | 0.00 | 0.89 | 16.07 | 24.37 | -30.23 | 69.86 | 0.5174 | -429.0 | -392.8 | |
| 0.00 | 1.89 | 0.00 | 1.12 | 18.44 | 22.89 | -31.71 | 66.26 | 0.5469 | -737.0 | -630.0 | |
| 0.00 | 1.35 | 0.00 | 0.79 | 15.48 | 23.22 | -31.38 | 71.45 | 0.5315 | 852.0 | 699.7 | |
| 0.00 | 2.34 | 0.00 | 1.37 | 15.68 | 23.04 | -31.57 | 71.14 | 0.5347 | 930.0 | 758.6 | |
| 0.00 | 1.80 | 0.00 | 1.06 | 15.27 | 22.29 | -32.31 | 72.18 | 0.5438 | 791.0 | 633.2 | |
| 0.00 | 3.15 | 0.00 | 1.89 | 17.47 | 21.38 | -33.22 | 68.62 | 0.5633 | 860.0 | 753.5 | |
| 0.00 | 1.17 | 0.00 | 0.70 | 16.34 | 21.15 | -33.45 | 70.68 | 0.5626 | 899.0 | 809.5 | |
| 0.00 | 1.62 | 0.00 | 0.97 | 15.65 | 21.02 | -33.58 | 71.93 | 0.5624 | 695.0 | 629.3 | |
| 0.00 | 4.51 | 0.00 | 2.72 | 17.26 | 20.51 | -34.09 | 69.34 | 0.5743 | 866.0 | 785.0 | |
| 6.31 | 10.27 | 3.79 | 6.18 | 15.75 | 20.58 | -34.02 | 71.91 | 0.5687 | 943.4 | 544.5 | |
| 4.87 | 15.59 | 2.95 | 9.44 | 16.68 | 20.17 | -34.44 | 70.45 | 0.5770 | 904.8 | 750.1 | |
| 1.08 | -29.00 | 0.65 | -29.00 | 16.46 | 20.13 | -34.47 | 70.83 | 0.5768 | 903.8 | 999999 | |
| 0.99 | 2.34 | 0.60 | 1.43 | 16.93 | 19.73 | -34.87 | 70.18 | 0.5836 | 679.3 | 548.7 | |
| 2.16 | 44.43 | 1.32 | 27.19 | 17.01 | 19.40 | -35.20 | 70.17 | 0.5881 | 463.4 | 146.7 | |
| 12.89 | -32.00 | 7.87 | -32.00 | 16.61 | 19.45 | -35.15 | 70.83 | 0.5863 | 905.8 | 999999 | |
| 12.98 | 48.57 | 7.89 | 29.58 | 15.75 | 19.58 | -35.02 | 72.23 | 0.5821 | 1030.0 | 431.5 | |
| 2.52 | -32.00 | 1.55 | -32.00 | 16.42 | 18.98 | -35.62 | 71.29 | 0.5920 | 572.3 | 999999 | |
| 1.26 | -34.00 | 0.77 | -34.00 | 15.74 | 19.00 | -35.60 | 72.42 | 0.5899 | 500.6 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
