SDO HMI 2014-08-18 17:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.90 | 216.07 | 66.77 | 374.16 | -17.64 | 106.35 | 69.92 | 249.15 | 0.9567 | -13.9 | -112.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-18 17:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.68 | 105.83 | 47.43 | 223.23 | -17.25 | 109.70 | 73.27 | 250.33 | 0.9723 | 222.0 | -1.8 | |
| 0.00 | 0.27 | 0.00 | 0.51 | -16.14 | 108.20 | 71.77 | 251.15 | 0.9653 | 346.0 | 361.0 | |
| 0.00 | 1.71 | 0.00 | 3.07 | -16.82 | 107.39 | 70.97 | 250.29 | 0.9624 | 369.0 | 339.9 | |
| 0.00 | 0.99 | 0.00 | 1.45 | -17.61 | 103.21 | 66.78 | 248.51 | 0.9428 | 216.0 | 210.2 | |
| 10.89 | 104.66 | 14.78 | 142.19 | -18.10 | 101.21 | 64.78 | 247.48 | 0.9324 | -652.2 | -286.8 | |
| 3.33 | -5.00 | 4.56 | -5.00 | -18.60 | 101.26 | 64.83 | 246.98 | 0.9335 | -540.0 | 999999 | |
| 0.00 | 2.61 | 0.00 | 3.71 | -19.85 | 101.82 | 65.39 | 245.84 | 0.9387 | -342.0 | -162.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
