SDO HMI 2014-08-19 11:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.61 | 0.00 | 5.79 | 10.39 | 21.94 | -4.58 | 95.19 | 0.1098 | 660.2 | 498.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-19 11:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.80 | 0.00 | 0.89 | 8.59 | 28.39 | 1.87 | 313.86 | 0.0449 | -1074.0 | -935.5 | |
| 0.00 | 1.44 | 0.00 | 0.72 | 10.50 | 22.35 | -4.17 | 48.00 | 0.0967 | 918.0 | 735.5 | |
| 0.00 | 2.61 | 0.00 | 1.30 | 9.71 | 22.33 | -4.19 | 54.90 | 0.0885 | 988.0 | 849.2 | |
| 0.00 | 1.17 | 0.00 | 0.58 | 9.74 | 21.99 | -4.53 | 56.69 | 0.0936 | 1000.0 | 844.2 | |
| 0.00 | 1.17 | 0.00 | 0.58 | 8.46 | 21.70 | -4.83 | 70.81 | 0.0885 | 942.0 | 726.8 | |
| 0.00 | 1.26 | 0.00 | 0.63 | 13.63 | 19.07 | -7.45 | 46.51 | 0.1745 | 773.0 | 635.8 | |
| 0.00 | 1.17 | 0.00 | 0.59 | 12.84 | 18.97 | -7.55 | 50.46 | 0.1669 | 945.0 | 795.9 | |
| 0.00 | 0.99 | 0.00 | 0.50 | 11.27 | 16.16 | -10.36 | 65.77 | 0.1943 | 790.0 | 619.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
