SDO HMI 2014-08-19 17:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.54 | 107.14 | 22.32 | 89.97 | -9.45 | 331.79 | -51.42 | 107.03 | 0.8085 | 708.0 | 251.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-19 17:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.61 | -10.46 | 337.38 | -45.83 | 110.36 | 0.7546 | 475.0 | 396.8 | |
| 0.00 | 2.52 | 0.00 | 1.88 | -9.28 | 337.51 | -45.70 | 108.92 | 0.7490 | 442.0 | 466.6 | |
| 20.24 | 90.31 | 16.93 | 75.76 | -9.51 | 331.92 | -51.30 | 107.14 | 0.8076 | 836.5 | 221.6 | |
| 2.34 | -3.00 | 1.98 | -3.00 | -9.47 | 331.33 | -51.88 | 106.90 | 0.8133 | 532.3 | 999999 | |
| 3.96 | 6.93 | 3.41 | 5.97 | -9.32 | 330.55 | -52.66 | 106.48 | 0.8203 | 669.9 | 491.8 | |
| 0.00 | 1.35 | 0.00 | 1.18 | -9.44 | 330.01 | -53.20 | 106.44 | 0.8257 | 413.0 | 410.9 | |
| 0.00 | 1.53 | 0.00 | 1.33 | -9.16 | 330.02 | -53.19 | 106.11 | 0.8249 | 368.0 | 328.5 | |
| 0.00 | 1.53 | 0.00 | 1.36 | -9.71 | 329.48 | -53.73 | 106.59 | 0.8314 | 391.0 | 294.6 | |
| 0.00 | 2.16 | 0.00 | 1.88 | -7.37 | 329.71 | -53.51 | 103.92 | 0.8235 | 463.0 | 372.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
