SDO HMI 2014-08-21 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 88.27 | 437.74 | 46.54 | 231.14 | 9.16 | 343.64 | -20.28 | 82.19 | 0.3476 | -681.7 | -335.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-21 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.07 | 0.00 | 1.09 | 22.06 | 349.83 | -14.10 | 40.46 | 0.3495 | -26.0 | 1.1 | |
| 0.00 | 0.99 | 0.00 | 0.52 | 18.53 | 346.69 | -17.24 | 53.67 | 0.3502 | 6.0 | 1.9 | |
| 0.00 | 1.17 | 0.00 | 0.61 | 10.77 | 345.88 | -18.05 | 76.48 | 0.3144 | -695.0 | -532.4 | |
| 0.00 | 1.53 | 0.00 | 0.80 | 12.87 | 345.74 | -18.19 | 70.17 | 0.3249 | -823.0 | -470.2 | |
| 0.00 | 3.87 | 0.00 | 2.01 | 6.46 | 346.02 | -17.91 | 90.37 | 0.3069 | -852.0 | -758.0 | |
| 2.52 | 6.48 | 1.31 | 3.38 | 9.37 | 345.83 | -18.10 | 80.94 | 0.3118 | 1096.4 | 709.8 | |
| 2.97 | 11.43 | 1.55 | 5.97 | 9.91 | 345.57 | -18.36 | 79.34 | 0.3171 | 995.7 | 713.5 | |
| 7.11 | 9.09 | 3.72 | 4.76 | 10.90 | 345.32 | -18.61 | 76.39 | 0.3238 | 995.6 | 609.8 | |
| 0.00 | 1.71 | 0.00 | 0.90 | 12.53 | 344.88 | -19.05 | 71.85 | 0.3368 | -981.0 | -777.2 | |
| 0.00 | 1.08 | 0.00 | 0.57 | 9.98 | 344.95 | -18.98 | 79.39 | 0.3273 | -964.0 | -726.0 | |
| 0.90 | 2.07 | 0.47 | 1.09 | 12.22 | 344.64 | -19.29 | 72.93 | 0.3392 | -868.8 | -705.2 | |
| 0.00 | 1.62 | 0.00 | 0.85 | 11.90 | 344.30 | -19.63 | 74.06 | 0.3434 | 944.0 | 669.3 | |
| 0.81 | 1.80 | 0.43 | 0.95 | 10.90 | 344.34 | -19.59 | 76.93 | 0.3395 | -986.1 | -758.3 | |
| 0.00 | 0.63 | 0.00 | 0.33 | 7.62 | 344.52 | -19.41 | 86.65 | 0.3313 | -776.0 | -578.6 | |
| 6.30 | 371.86 | 3.31 | 196.39 | 8.89 | 344.16 | -19.76 | 82.92 | 0.3381 | -1450.5 | -416.6 | |
| 54.07 | -15.00 | 28.55 | -15.00 | 8.95 | 343.61 | -20.32 | 82.84 | 0.3473 | -1400.7 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.48 | 11.29 | 343.42 | -20.51 | 76.28 | 0.3552 | -931.0 | -792.4 | |
| 0.81 | 4.86 | 0.43 | 2.56 | 7.47 | 343.62 | -20.31 | 87.15 | 0.3461 | -959.9 | -382.5 | |
| 0.00 | 1.80 | 0.00 | 0.95 | 4.79 | 343.52 | -20.40 | 94.84 | 0.3502 | -1.0 | 1.0 | |
| 1.62 | -15.00 | 0.86 | -15.00 | 8.72 | 343.09 | -20.83 | 83.61 | 0.3553 | -748.8 | 999999 | |
| 11.16 | -15.00 | 5.91 | -15.00 | 9.08 | 343.04 | -20.89 | 82.60 | 0.3566 | -1077.5 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.67 | 8.67 | 341.81 | -22.12 | 83.95 | 0.3759 | -539.0 | -475.4 | |
| 0.00 | 0.99 | 0.00 | 0.53 | 9.21 | 340.34 | -23.59 | 82.78 | 0.3998 | 658.0 | 462.9 | |
| 0.00 | 0.90 | 0.00 | 0.49 | 9.97 | 339.64 | -24.28 | 81.05 | 0.4118 | 682.0 | 477.8 | |
| 0.00 | 1.35 | 0.00 | 0.73 | 9.08 | 339.61 | -24.32 | 83.20 | 0.4112 | 804.0 | 581.6 | |
| 0.00 | 2.25 | 0.00 | 1.22 | 10.07 | 339.37 | -24.56 | 80.85 | 0.4163 | 698.0 | 561.6 | |
| 0.00 | 0.90 | 0.00 | 0.49 | 11.56 | 339.17 | -24.76 | 77.38 | 0.4222 | 768.0 | 590.5 | |
| 0.00 | 1.62 | 0.00 | 0.88 | 9.97 | 339.10 | -24.83 | 81.15 | 0.4203 | 745.0 | 656.2 | |
| 0.00 | 1.17 | 0.00 | 0.64 | 10.15 | 338.95 | -24.98 | 80.77 | 0.4228 | 767.0 | 661.3 | |
| 0.00 | 1.08 | 0.00 | 0.59 | 11.52 | 338.42 | -25.51 | 77.71 | 0.4337 | 721.0 | 689.7 | |
| 0.00 | 1.26 | 0.00 | 0.69 | 11.37 | 338.40 | -25.53 | 78.07 | 0.4336 | 884.0 | 728.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
