SDO HMI 2014-08-21 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 84.13 | 452.88 | 42.48 | 229.04 | 9.17 | 343.67 | -11.44 | 78.04 | 0.2014 | -656.5 | -381.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-21 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.08 | 3.15 | 0.54 | 1.58 | 8.74 | 346.28 | -8.84 | 77.66 | 0.1561 | 1136.8 | 858.7 | |
| 3.77 | 6.29 | 1.89 | 3.16 | 9.19 | 346.02 | -9.09 | 75.23 | 0.1621 | 1081.2 | 694.0 | |
| 1.80 | 3.68 | 0.90 | 1.85 | 9.80 | 345.88 | -9.24 | 71.89 | 0.1671 | 1157.3 | 892.0 | |
| 9.44 | 12.67 | 4.75 | 6.38 | 10.95 | 345.70 | -9.42 | 65.93 | 0.1769 | 1076.7 | 529.6 | |
| 0.00 | 2.43 | 0.00 | 1.22 | 9.88 | 345.63 | -9.49 | 71.82 | 0.1717 | 878.0 | 775.6 | |
| 0.00 | 0.54 | 0.00 | 0.27 | 10.12 | 345.25 | -9.87 | 71.16 | 0.1791 | 802.0 | 644.7 | |
| 0.54 | 2.88 | 0.27 | 1.45 | 10.30 | 345.15 | -9.97 | 70.37 | 0.1816 | 1049.3 | 783.4 | |
| 0.00 | 1.08 | 0.00 | 0.55 | 11.18 | 343.71 | -11.41 | 68.45 | 0.2096 | -857.0 | -598.5 | |
| 55.09 | 393.81 | 27.85 | 199.13 | 8.97 | 343.72 | -11.40 | 78.98 | 0.1998 | -1533.6 | -457.1 | |
| 1.53 | -9.00 | 0.77 | -9.00 | 8.06 | 343.69 | -11.43 | 83.56 | 0.1984 | -706.2 | 999999 | |
| 0.00 | 1.44 | 0.00 | 0.73 | 10.97 | 343.56 | -11.56 | 69.66 | 0.2108 | -969.0 | -773.9 | |
| 0.27 | -9.00 | 0.14 | -9.00 | 9.45 | 343.58 | -11.54 | 76.74 | 0.2036 | -1196.0 | 999999 | |
| 0.81 | -9.00 | 0.41 | -9.00 | 8.42 | 343.58 | -11.54 | 81.80 | 0.2008 | -935.8 | 999999 | |
| 0.00 | 3.15 | 0.00 | 1.60 | 11.42 | 343.45 | -11.67 | 67.82 | 0.2151 | -1055.0 | -871.5 | |
| 0.00 | 1.71 | 0.00 | 0.86 | 7.53 | 343.39 | -11.73 | 86.26 | 0.2029 | -803.0 | -652.2 | |
| 7.82 | -9.00 | 3.96 | -9.00 | 9.29 | 343.24 | -11.88 | 77.82 | 0.2087 | -1206.6 | 999999 | |
| 1.98 | 6.11 | 1.00 | 3.10 | 11.50 | 343.10 | -12.02 | 68.00 | 0.2212 | -1155.9 | -954.9 | |
| 0.00 | 1.71 | 0.00 | 0.86 | 7.13 | 343.12 | -12.00 | 88.25 | 0.2074 | 775.0 | 455.4 | |
| 0.00 | 3.15 | 0.00 | 1.61 | 9.77 | 340.89 | -14.23 | 77.57 | 0.2492 | 631.0 | 458.7 | |
| 0.00 | 0.99 | 0.00 | 0.51 | 9.33 | 340.05 | -15.07 | 79.83 | 0.2618 | 850.0 | 641.7 | |
| 0.00 | 4.31 | 0.00 | 2.23 | 12.27 | 339.00 | -16.12 | 70.16 | 0.2897 | 682.0 | 586.3 | |
| 0.00 | 1.26 | 0.00 | 0.65 | 11.45 | 338.82 | -16.30 | 73.09 | 0.2887 | 898.0 | 769.9 | |
| 0.00 | 1.44 | 0.00 | 0.74 | 11.10 | 338.58 | -16.54 | 74.43 | 0.2912 | 798.0 | 660.2 | |
| 0.00 | 1.08 | 0.00 | 0.56 | 9.93 | 338.07 | -17.05 | 78.70 | 0.2958 | 702.0 | 578.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
