SDO HMI 2014-08-22 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.86 | 135.74 | 14.21 | 87.53 | 16.50 | 27.89 | 39.37 | 287.62 | 0.6400 | -368.0 | -247.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-22 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.69 | 116.48 | 13.45 | 75.84 | 16.37 | 28.68 | 40.16 | 287.17 | 0.6499 | -1091.6 | -322.4 | |
| 1.17 | -1.00 | 0.76 | -1.00 | 16.41 | 28.28 | 39.76 | 287.31 | 0.6449 | -1049.1 | 999999 | |
| 0.00 | 1.71 | 0.00 | 1.07 | 13.94 | 26.52 | 38.00 | 283.80 | 0.6175 | -670.0 | -550.9 | |
| 0.00 | 1.71 | 0.00 | 1.09 | 17.89 | 26.69 | 38.17 | 290.05 | 0.6282 | -696.0 | -624.9 | |
| 0.00 | 0.99 | 0.00 | 0.63 | 17.62 | 26.62 | 38.10 | 289.64 | 0.6266 | -606.0 | -582.3 | |
| 0.00 | 1.80 | 0.00 | 1.13 | 17.01 | 25.95 | 37.42 | 288.87 | 0.6164 | -751.0 | -630.7 | |
| 0.00 | 0.63 | 0.00 | 0.39 | 17.41 | 24.33 | 35.81 | 290.02 | 0.5964 | -568.0 | -468.4 | |
| 0.00 | 1.26 | 0.00 | 0.76 | 17.60 | 21.97 | 33.45 | 291.22 | 0.5658 | 665.0 | 548.4 | |
| 0.00 | 0.72 | 0.00 | 0.43 | 17.55 | 21.77 | 33.25 | 291.22 | 0.5629 | 624.0 | 510.8 | |
| 0.00 | 1.08 | 0.00 | 0.65 | 18.37 | 21.60 | 33.08 | 292.70 | 0.5637 | 599.0 | 483.9 | |
| 0.00 | 2.25 | 0.00 | 1.34 | 17.42 | 21.29 | 32.77 | 291.20 | 0.5560 | 712.0 | 619.4 | |
| 0.00 | 1.26 | 0.00 | 0.75 | 16.66 | 21.10 | 32.58 | 289.93 | 0.5508 | 737.0 | 614.9 | |
| 0.00 | 0.54 | 0.00 | 0.32 | 18.27 | 20.75 | 32.22 | 292.92 | 0.5519 | 843.0 | 727.3 | |
| 0.00 | 1.26 | 0.00 | 0.74 | 16.92 | 20.40 | 31.88 | 290.69 | 0.5422 | 740.0 | 552.6 | |
| 0.00 | 0.54 | 0.00 | 0.32 | 18.86 | 20.80 | 32.27 | 293.92 | 0.5549 | 555.0 | 470.7 | |
| 0.00 | 1.26 | 0.00 | 0.75 | 18.84 | 20.60 | 32.08 | 293.98 | 0.5523 | 725.0 | 625.1 | |
| 0.00 | 0.81 | 0.00 | 0.48 | 19.06 | 20.46 | 31.94 | 294.45 | 0.5514 | 661.0 | 401.6 | |
| 0.00 | 1.44 | 0.00 | 0.84 | 17.24 | 19.72 | 31.19 | 291.57 | 0.5340 | 791.0 | 717.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
