SDO HMI 2014-08-27 03:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 86.69 | 397.14 | 82.26 | 373.85 | 7.79 | 344.09 | 58.90 | 274.80 | 0.8533 | -358.4 | -340.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-27 03:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.26 | 0.00 | 1.34 | 8.26 | 348.19 | 63.00 | 275.64 | 0.8879 | -192.0 | -112.3 | |
| 0.00 | 2.78 | 0.00 | 2.96 | 7.76 | 347.99 | 62.79 | 275.06 | 0.8865 | -567.0 | -370.3 | |
| 0.00 | 1.53 | 0.00 | 1.62 | 8.01 | 347.92 | 62.73 | 275.34 | 0.8859 | -393.0 | -311.9 | |
| 5.47 | 10.77 | 5.73 | 11.25 | 8.45 | 347.58 | 62.38 | 275.81 | 0.8829 | -520.6 | -428.6 | |
| 2.96 | 4.85 | 3.05 | 4.99 | 9.63 | 347.14 | 61.94 | 277.13 | 0.8788 | 490.8 | 346.1 | |
| 0.00 | 1.71 | 0.00 | 1.71 | 7.44 | 346.20 | 61.00 | 274.55 | 0.8720 | 149.0 | 138.5 | |
| 0.00 | 0.72 | 0.00 | 0.72 | 7.40 | 345.94 | 60.74 | 274.49 | 0.8698 | 324.0 | 279.9 | |
| 21.63 | 366.86 | 20.65 | 343.28 | 7.01 | 344.44 | 59.24 | 273.92 | 0.8569 | 399.8 | -360.4 | |
| 7.72 | -8.00 | 7.33 | -8.00 | 7.43 | 344.23 | 59.03 | 274.39 | 0.8548 | -544.6 | 999999 | |
| 0.00 | 0.72 | 0.00 | 0.68 | 9.20 | 344.30 | 59.11 | 276.47 | 0.8546 | 210.0 | 185.9 | |
| 47.56 | -8.00 | 44.29 | -8.00 | 8.08 | 343.60 | 58.41 | 275.11 | 0.8488 | -834.4 | 999999 | |
| 1.35 | -8.00 | 1.21 | -8.00 | 6.81 | 342.30 | 57.10 | 273.50 | 0.8374 | 306.9 | 999999 | |
| 0.00 | 1.44 | 0.00 | 1.35 | 14.56 | 344.14 | 58.95 | 282.76 | 0.8522 | -395.0 | -324.6 | |
| 0.00 | 1.08 | 0.00 | 0.94 | 6.49 | 341.23 | 56.04 | 273.03 | 0.8274 | 447.0 | 395.5 | |
| 0.00 | 0.99 | 0.00 | 0.87 | 8.30 | 341.48 | 56.28 | 275.23 | 0.8287 | -264.0 | -215.0 | |
| 0.00 | 1.35 | 0.00 | 1.19 | 10.68 | 341.87 | 56.67 | 278.13 | 0.8315 | 561.0 | 507.2 | |
| 0.00 | 1.08 | 0.00 | 0.95 | 10.22 | 341.62 | 56.42 | 277.56 | 0.8293 | 504.0 | 474.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
