SDO HMI 2014-08-28 03:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.36 | 182.00 | 72.73 | 277.88 | 7.69 | 343.80 | 71.81 | 275.72 | 0.9475 | -127.8 | -223.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-28 03:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.99 | 2.60 | 1.98 | 5.24 | 8.30 | 348.47 | 76.48 | 276.79 | 0.9700 | -304.4 | -130.3 | |
| 0.00 | 1.79 | 0.00 | 3.40 | 9.80 | 347.76 | 75.78 | 278.27 | 0.9664 | 10.0 | 60.0 | |
| 5.83 | 171.33 | 9.23 | 260.26 | 7.34 | 344.38 | 72.40 | 275.41 | 0.9510 | 527.4 | -242.1 | |
| 5.92 | -3.00 | 9.32 | -3.00 | 7.05 | 344.26 | 72.28 | 275.09 | 0.9505 | 515.8 | 999999 | |
| 34.62 | -3.00 | 52.20 | -3.00 | 7.82 | 343.48 | 71.49 | 275.83 | 0.9458 | -369.3 | 999999 | |
| 0.00 | 4.84 | 0.00 | 6.92 | 6.70 | 342.30 | 70.31 | 274.54 | 0.9396 | -158.0 | -71.1 | |
| 0.00 | 0.27 | 0.00 | 0.37 | 6.31 | 341.37 | 69.38 | 274.04 | 0.9342 | 259.0 | 205.7 | |
| 0.00 | 1.17 | 0.00 | 1.69 | 11.12 | 342.90 | 70.92 | 279.28 | 0.9411 | 293.0 | 361.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
