SDO HMI 2014-08-28 17:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.00 | 104.86 | 46.12 | 258.95 | 7.90 | 343.38 | 79.09 | 276.64 | 0.9801 | -73.8 | -54.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-08-28 17:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 1.16 | 8.48 | 348.53 | 84.24 | 277.76 | 0.9937 | -67.0 | -53.3 | |
| 17.30 | 98.31 | 42.09 | 243.19 | 7.70 | 343.37 | 79.08 | 276.43 | 0.9801 | -90.4 | -65.1 | |
| 1.70 | 5.47 | 4.03 | 12.89 | 11.38 | 343.34 | 79.05 | 280.17 | 0.9788 | 120.4 | 200.3 | |
| 0.00 | 0.81 | 0.00 | 1.71 | 9.97 | 341.72 | 77.43 | 278.59 | 0.9732 | -163.0 | -77.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
