SDO HMI 2014-09-01 11:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 138.96 | 684.18 | 75.54 | 371.60 | -15.30 | 206.27 | -8.49 | 159.98 | 0.4111 | 7.3 | 59.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-01 11:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.62 | -12.99 | 210.55 | -4.20 | 168.29 | 0.3534 | 928.0 | 764.0 | |
| 0.00 | 1.61 | 0.00 | 0.85 | -13.12 | 210.21 | -4.55 | 167.44 | 0.3567 | 855.0 | 793.9 | |
| 7.25 | 346.91 | 3.88 | 186.09 | -14.58 | 209.90 | -4.86 | 167.51 | 0.3810 | 1127.4 | 454.3 | |
| 8.77 | -3.00 | 4.70 | -3.00 | -14.72 | 209.58 | -5.18 | 166.81 | 0.3843 | 1021.7 | 999999 | |
| 2.06 | -3.00 | 1.11 | -3.00 | -14.98 | 209.57 | -5.19 | 166.95 | 0.3884 | 700.7 | 999999 | |
| 9.13 | -3.00 | 4.89 | -3.00 | -14.43 | 209.49 | -5.27 | 166.41 | 0.3800 | 1421.3 | 999999 | |
| 5.55 | -3.00 | 2.98 | -3.00 | -14.79 | 209.26 | -5.50 | 166.08 | 0.3866 | 1140.3 | 999999 | |
| 1.97 | -3.00 | 1.06 | -3.00 | -14.56 | 209.17 | -5.58 | 165.71 | 0.3833 | 1342.2 | 999999 | |
| 2.60 | -3.00 | 1.39 | -3.00 | -14.37 | 209.02 | -5.74 | 165.21 | 0.3809 | 1411.2 | 999999 | |
| 4.83 | -3.00 | 2.60 | -3.00 | -14.82 | 209.01 | -5.75 | 165.49 | 0.3881 | 1104.4 | 999999 | |
| 4.12 | -3.00 | 2.22 | -3.00 | -15.05 | 209.00 | -5.76 | 165.62 | 0.3917 | 823.4 | 999999 | |
| 3.94 | -3.00 | 2.12 | -3.00 | -15.22 | 208.78 | -5.98 | 165.20 | 0.3952 | 861.8 | 999999 | |
| 0.00 | 2.24 | 0.00 | 1.22 | -16.70 | 208.60 | -6.15 | 165.75 | 0.4188 | 801.0 | 615.4 | |
| 15.94 | -3.00 | 8.55 | -3.00 | -14.53 | 208.64 | -6.12 | 164.40 | 0.3851 | 1204.7 | 999999 | |
| 6.62 | -3.00 | 3.58 | -3.00 | -15.48 | 208.58 | -6.18 | 164.91 | 0.4001 | 780.3 | 999999 | |
| 1.79 | -3.00 | 0.97 | -3.00 | -15.19 | 208.53 | -6.23 | 164.58 | 0.3958 | 940.2 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.58 | -15.95 | 208.22 | -6.54 | 164.39 | 0.4088 | 575.0 | 523.5 | |
| 0.00 | 2.51 | 0.00 | 1.36 | -16.34 | 208.17 | -6.59 | 164.56 | 0.4151 | 857.0 | 704.7 | |
| 0.00 | 1.07 | 0.00 | 0.58 | -15.78 | 208.13 | -6.63 | 164.08 | 0.4067 | 800.0 | 634.1 | |
| 0.00 | 1.61 | 0.00 | 0.91 | -20.31 | 207.72 | -7.04 | 166.00 | 0.4768 | 663.0 | 555.8 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -17.11 | 207.83 | -6.93 | 164.31 | 0.4283 | 635.0 | 529.1 | |
| 0.00 | 1.07 | 0.00 | 0.59 | -16.91 | 207.77 | -6.99 | 164.05 | 0.4255 | 566.0 | 536.4 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -15.82 | 207.78 | -6.98 | 163.31 | 0.4088 | 553.0 | 419.7 | |
| 5.01 | 31.69 | 2.71 | 17.13 | -15.33 | 207.73 | -7.03 | 162.84 | 0.4015 | 954.0 | 384.4 | |
| 0.00 | 1.97 | 0.00 | 1.10 | -18.92 | 207.53 | -7.23 | 164.82 | 0.4569 | 878.0 | 724.9 | |
| 0.00 | 1.16 | 0.00 | 0.63 | -15.47 | 207.03 | -7.73 | 161.36 | 0.4071 | 407.0 | 310.6 | |
| 0.00 | 1.52 | 0.00 | 0.83 | -16.13 | 206.88 | -7.88 | 161.55 | 0.4179 | 649.0 | 508.2 | |
| 0.00 | 2.33 | 0.00 | 1.27 | -15.84 | 206.60 | -8.15 | 160.71 | 0.4149 | 748.0 | 568.9 | |
| 0.00 | 0.63 | 0.00 | 0.34 | -17.00 | 206.43 | -8.33 | 161.26 | 0.4331 | -471.0 | -527.7 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -16.87 | 206.34 | -8.42 | 160.97 | 0.4316 | -886.0 | -661.2 | |
| 0.00 | 2.69 | 0.00 | 1.48 | -17.30 | 206.28 | -8.48 | 161.19 | 0.4383 | 636.0 | 522.3 | |
| 0.45 | 4.66 | 0.24 | 2.49 | -13.34 | 206.26 | -8.50 | 157.62 | 0.3793 | 960.0 | 724.7 | |
| 0.00 | 2.78 | 0.00 | 1.52 | -16.64 | 206.09 | -8.67 | 160.27 | 0.4295 | -897.0 | -768.7 | |
| 0.00 | 1.16 | 0.00 | 0.64 | -16.44 | 206.07 | -8.69 | 160.06 | 0.4267 | -782.0 | -639.3 | |
| 0.00 | 1.97 | 0.00 | 1.07 | -15.50 | 205.67 | -9.09 | 158.37 | 0.4149 | -869.0 | -645.1 | |
| 0.36 | 6.18 | 0.20 | 3.39 | -16.75 | 205.57 | -9.19 | 159.28 | 0.4339 | -896.8 | -803.2 | |
| 0.00 | 3.04 | 0.00 | 1.67 | -16.19 | 205.38 | -9.38 | 158.39 | 0.4269 | -884.0 | -658.4 | |
| 1.52 | 6.98 | 0.82 | 3.78 | -14.62 | 205.42 | -9.34 | 156.99 | 0.4035 | -977.4 | -884.2 | |
| 0.00 | 3.22 | 0.00 | 1.75 | -15.02 | 205.15 | -9.61 | 156.80 | 0.4110 | -871.0 | -756.1 | |
| 0.00 | 1.52 | 0.00 | 0.84 | -16.24 | 204.61 | -10.15 | 156.85 | 0.4322 | -828.0 | -733.9 | |
| 0.00 | 1.79 | 0.00 | 0.97 | -15.00 | 204.58 | -10.18 | 155.55 | 0.4144 | 682.0 | 565.9 | |
| 0.00 | 1.79 | 0.00 | 0.99 | -16.75 | 204.19 | -10.56 | 156.49 | 0.4420 | -875.0 | -680.2 | |
| 0.00 | 3.85 | 0.00 | 2.12 | -16.48 | 204.21 | -10.55 | 156.27 | 0.4381 | -728.0 | -459.5 | |
| 0.00 | 1.25 | 0.00 | 0.66 | -11.03 | 204.40 | -10.36 | 150.40 | 0.3588 | -744.0 | -587.3 | |
| 0.00 | 1.70 | 0.00 | 0.95 | -17.72 | 203.97 | -10.78 | 156.95 | 0.4572 | -679.0 | -471.1 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -14.81 | 204.01 | -10.75 | 154.17 | 0.4155 | 607.0 | 512.5 | |
| 0.00 | 1.61 | 0.00 | 0.89 | -16.63 | 203.78 | -10.98 | 155.57 | 0.4429 | -847.0 | -690.4 | |
| 0.00 | 1.34 | 0.00 | 0.73 | -15.37 | 203.82 | -10.94 | 154.38 | 0.4248 | 357.0 | 381.2 | |
| 0.00 | 0.45 | 0.00 | 0.24 | -14.85 | 203.66 | -11.10 | 153.49 | 0.4186 | 437.0 | 307.2 | |
| 0.00 | 1.79 | 0.00 | 1.00 | -18.03 | 203.40 | -11.36 | 156.16 | 0.4651 | -823.0 | -618.0 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -17.03 | 203.44 | -11.32 | 155.29 | 0.4509 | -900.0 | -728.2 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -18.61 | 203.23 | -11.52 | 156.37 | 0.4743 | -730.0 | -555.4 | |
| 0.00 | 1.07 | 0.00 | 0.59 | -16.61 | 203.24 | -11.52 | 154.48 | 0.4462 | -841.0 | -664.0 | |
| 0.98 | 2.33 | 0.54 | 1.29 | -16.48 | 203.05 | -11.71 | 154.00 | 0.4456 | -998.9 | -855.1 | |
| 0.81 | 14.95 | 0.44 | 8.17 | -15.07 | 202.91 | -11.85 | 152.21 | 0.4270 | -868.9 | -825.6 | |
| 0.00 | 2.42 | 0.00 | 1.33 | -15.36 | 202.89 | -11.86 | 152.50 | 0.4312 | -788.0 | -611.3 | |
| 1.07 | -55.00 | 0.59 | -55.00 | -14.84 | 202.86 | -11.90 | 151.85 | 0.4242 | -1047.8 | 999999 | |
| 0.00 | 2.42 | 0.00 | 1.34 | -16.75 | 202.71 | -12.05 | 153.63 | 0.4518 | -755.0 | -671.5 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -16.36 | 202.70 | -12.05 | 153.20 | 0.4463 | -800.0 | -642.2 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -15.17 | 202.71 | -12.05 | 151.93 | 0.4299 | -886.0 | -767.1 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -15.96 | 202.67 | -12.09 | 152.71 | 0.4411 | -448.0 | -453.9 | |
| 0.00 | 1.25 | 0.00 | 0.71 | -18.76 | 202.44 | -12.32 | 155.08 | 0.4814 | -658.0 | -657.6 | |
| 0.00 | 0.72 | 0.00 | 0.40 | -17.09 | 202.56 | -12.20 | 153.68 | 0.4575 | -716.0 | -589.1 | |
| 6.00 | 188.81 | 3.33 | 104.39 | -16.50 | 202.37 | -12.39 | 152.72 | 0.4506 | -879.1 | -469.3 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -17.19 | 202.26 | -12.50 | 153.24 | 0.4610 | -661.0 | -590.8 | |
| 0.00 | 1.34 | 0.00 | 0.75 | -17.39 | 202.25 | -12.51 | 153.41 | 0.4639 | -587.0 | -472.1 | |
| 0.00 | 1.61 | 0.00 | 0.88 | -14.92 | 202.38 | -12.38 | 150.98 | 0.4289 | -1042.0 | -818.2 | |
| 3.76 | -64.00 | 2.08 | -64.00 | -16.00 | 202.28 | -12.48 | 152.01 | 0.4446 | -1107.0 | 999999 | |
| 6.09 | -64.00 | 3.35 | -64.00 | -15.51 | 202.24 | -12.52 | 151.40 | 0.4381 | -1071.9 | 999999 | |
| 2.42 | -64.00 | 1.34 | -64.00 | -16.40 | 202.15 | -12.61 | 152.21 | 0.4509 | -873.9 | 999999 | |
| 0.90 | 3.94 | 0.49 | 2.16 | -14.73 | 202.23 | -12.53 | 150.46 | 0.4274 | -951.5 | -740.2 | |
| 4.30 | -64.00 | 2.37 | -64.00 | -15.88 | 201.99 | -12.77 | 151.34 | 0.4450 | -1118.8 | 999999 | |
| 4.30 | -64.00 | 2.39 | -64.00 | -16.38 | 201.83 | -12.93 | 151.59 | 0.4530 | -767.0 | 999999 | |
| 2.51 | -64.00 | 1.39 | -64.00 | -16.08 | 201.79 | -12.97 | 151.18 | 0.4493 | -838.2 | 999999 | |
| 10.21 | -64.00 | 5.64 | -64.00 | -15.72 | 201.75 | -13.01 | 150.70 | 0.4447 | -1142.1 | 999999 | |
| 13.70 | -64.00 | 7.57 | -64.00 | -15.60 | 201.50 | -13.26 | 150.09 | 0.4449 | -1082.8 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.45 | -17.35 | 201.37 | -13.39 | 151.79 | 0.4695 | -541.0 | -500.0 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -14.49 | 201.34 | -13.42 | 148.47 | 0.4313 | -715.0 | -505.5 | |
| 0.00 | 1.25 | 0.00 | 0.70 | -17.53 | 201.00 | -13.76 | 151.32 | 0.4746 | -721.0 | -662.4 | |
| 0.00 | 0.72 | 0.00 | 0.42 | -19.05 | 196.77 | -17.99 | 146.22 | 0.5270 | -726.0 | -647.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
