SDO HMI 2014-09-02 10:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 209.35 | 885.18 | 112.94 | 477.47 | -15.49 | 206.02 | 3.92 | 189.75 | 0.3974 | -82.3 | 26.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-02 10:00:37 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.62 | -12.74 | 211.57 | 9.47 | 205.30 | 0.3770 | 883.0 | 685.9 | |
| 7.34 | 247.45 | 3.97 | 133.23 | -14.64 | 211.07 | 8.97 | 202.16 | 0.4018 | 1076.2 | 463.7 | |
| 17.18 | -2.00 | 9.27 | -2.00 | -14.34 | 210.97 | 8.87 | 202.21 | 0.3968 | 1313.6 | 999999 | |
| 1.61 | -2.00 | 0.87 | -2.00 | -14.33 | 210.52 | 8.42 | 201.21 | 0.3940 | 1278.9 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.34 | -15.97 | 210.52 | 8.43 | 199.76 | 0.4185 | 546.0 | 423.0 | |
| 5.37 | -2.00 | 2.89 | -2.00 | -14.46 | 210.24 | 8.14 | 200.45 | 0.3943 | 1133.2 | 999999 | |
| 6.89 | -2.00 | 3.70 | -2.00 | -14.16 | 209.95 | 7.85 | 200.04 | 0.3882 | 1340.9 | 999999 | |
| 5.10 | 26.22 | 2.76 | 14.17 | -15.01 | 209.82 | 7.72 | 199.00 | 0.4003 | 947.8 | 563.4 | |
| 6.09 | -8.00 | 3.29 | -8.00 | -15.17 | 209.76 | 7.66 | 198.74 | 0.4024 | 968.8 | 999999 | |
| 16.11 | -2.00 | 8.66 | -2.00 | -14.38 | 209.64 | 7.54 | 199.12 | 0.3899 | 1196.0 | 999999 | |
| 1.79 | 4.56 | 0.97 | 2.47 | -15.56 | 209.56 | 7.46 | 197.95 | 0.4073 | 817.8 | 659.6 | |
| 0.00 | 3.04 | 0.00 | 1.64 | -14.83 | 209.37 | 7.27 | 198.11 | 0.3954 | 747.0 | 661.9 | |
| 0.00 | 1.25 | 0.00 | 0.67 | -14.47 | 209.11 | 7.01 | 197.79 | 0.3885 | 803.0 | 604.1 | |
| 0.00 | 1.79 | 0.00 | 0.96 | -14.37 | 208.92 | 6.82 | 197.41 | 0.3861 | 992.0 | 792.4 | |
| 0.63 | 33.38 | 0.34 | 18.08 | -15.28 | 208.85 | 6.75 | 196.55 | 0.3998 | 762.9 | 690.1 | |
| 0.00 | 1.34 | 0.00 | 0.72 | -14.95 | 208.81 | 6.71 | 196.70 | 0.3945 | 472.0 | 398.5 | |
| 0.00 | 0.63 | 0.00 | 0.34 | -14.53 | 208.80 | 6.70 | 196.99 | 0.3880 | 720.0 | 613.0 | |
| 1.79 | -15.00 | 0.97 | -15.00 | -15.97 | 208.81 | 6.71 | 195.97 | 0.4102 | 877.8 | 999999 | |
| 0.89 | -15.00 | 0.49 | -15.00 | -16.10 | 208.69 | 6.59 | 195.60 | 0.4116 | 756.9 | 999999 | |
| 1.70 | 16.91 | 0.91 | 9.06 | -14.17 | 208.60 | 6.50 | 196.79 | 0.3814 | 1133.2 | 851.9 | |
| 0.81 | -20.00 | 0.43 | -20.00 | -14.33 | 208.38 | 6.28 | 196.15 | 0.3829 | 971.2 | 999999 | |
| 0.72 | 50.65 | 0.39 | 27.52 | -16.16 | 208.09 | 5.99 | 194.20 | 0.4100 | 893.2 | 145.1 | |
| 0.00 | 1.61 | 0.00 | 0.85 | -12.44 | 207.74 | 5.64 | 195.97 | 0.3506 | -849.0 | -645.2 | |
| 1.88 | -22.00 | 1.02 | -22.00 | -16.45 | 207.52 | 5.43 | 192.76 | 0.4125 | 880.0 | 999999 | |
| 0.00 | 2.33 | 0.00 | 1.28 | -18.18 | 207.54 | 5.44 | 191.89 | 0.4393 | 712.0 | 554.8 | |
| 0.00 | 1.07 | 0.00 | 0.57 | -13.96 | 207.37 | 5.27 | 193.89 | 0.3729 | 849.0 | 733.8 | |
| 0.00 | 0.45 | 0.00 | 0.25 | -18.24 | 207.35 | 5.25 | 191.46 | 0.4397 | 602.0 | 609.4 | |
| 3.67 | -22.00 | 1.99 | -22.00 | -16.58 | 207.24 | 5.14 | 192.05 | 0.4135 | 740.7 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.62 | -13.66 | 207.05 | 4.95 | 193.27 | 0.3670 | 840.0 | 704.5 | |
| 0.00 | 2.06 | 0.00 | 1.10 | -13.95 | 207.03 | 4.93 | 193.02 | 0.3715 | 922.0 | 604.7 | |
| 1.61 | -22.00 | 0.87 | -22.00 | -16.50 | 206.86 | 4.76 | 191.21 | 0.4112 | -870.3 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.62 | -13.33 | 206.79 | 4.70 | 192.81 | 0.3609 | 935.0 | 597.2 | |
| 0.00 | 1.25 | 0.00 | 0.67 | -14.08 | 206.71 | 4.62 | 192.15 | 0.3724 | 136.0 | 245.6 | |
| 0.00 | 0.98 | 0.00 | 0.52 | -13.62 | 206.64 | 4.54 | 192.24 | 0.3649 | 677.0 | 579.9 | |
| 1.97 | 9.84 | 1.05 | 5.24 | -13.88 | 206.37 | 4.27 | 191.37 | 0.3681 | 967.0 | 384.4 | |
| 4.03 | 24.34 | 2.19 | 13.23 | -16.96 | 205.79 | 3.69 | 188.57 | 0.4154 | -871.8 | -420.2 | |
| 0.00 | 2.51 | 0.00 | 1.34 | -14.33 | 205.69 | 3.59 | 189.39 | 0.3733 | -725.0 | -600.0 | |
| 1.43 | 87.70 | 0.76 | 46.92 | -14.39 | 205.22 | 3.12 | 188.16 | 0.3731 | -762.1 | 331.6 | |
| 0.00 | 1.16 | 0.00 | 0.63 | -15.53 | 205.14 | 3.04 | 187.54 | 0.3913 | -751.0 | -541.8 | |
| 5.10 | -38.00 | 2.73 | -38.00 | -14.68 | 205.07 | 2.97 | 187.65 | 0.3775 | 769.8 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.62 | -15.23 | 204.82 | 2.72 | 186.85 | 0.3859 | -165.0 | -152.7 | |
| 8.77 | -38.00 | 4.69 | -38.00 | -14.61 | 204.72 | 2.62 | 186.79 | 0.3757 | 1239.9 | 999999 | |
| 23.54 | 102.11 | 12.79 | 55.43 | -16.88 | 204.62 | 2.52 | 185.89 | 0.4118 | -1142.9 | -682.4 | |
| 2.95 | -38.00 | 1.58 | -38.00 | -14.81 | 204.50 | 2.40 | 186.18 | 0.3784 | 1107.8 | 999999 | |
| 0.00 | 2.77 | 0.00 | 1.52 | -17.61 | 204.38 | 2.28 | 185.16 | 0.4230 | -578.0 | -522.0 | |
| 4.03 | -38.00 | 2.16 | -38.00 | -15.03 | 204.22 | 2.12 | 185.41 | 0.3816 | 679.8 | 999999 | |
| 0.72 | -38.00 | 0.38 | -38.00 | -14.93 | 203.94 | 1.84 | 184.71 | 0.3796 | 768.1 | 999999 | |
| 16.38 | -43.00 | 8.88 | -43.00 | -16.74 | 203.92 | 1.82 | 184.30 | 0.4086 | -1192.3 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -15.85 | 203.92 | 1.82 | 184.46 | 0.3944 | -743.0 | -591.0 | |
| 2.77 | -43.00 | 1.51 | -43.00 | -17.01 | 203.86 | 1.76 | 184.11 | 0.4128 | -850.5 | 999999 | |
| 0.00 | 1.79 | 0.00 | 0.96 | -15.75 | 203.70 | 1.60 | 183.93 | 0.3925 | -893.0 | -621.7 | |
| 0.00 | 2.33 | 0.00 | 1.24 | -14.21 | 203.59 | 1.49 | 183.96 | 0.3675 | -944.0 | -783.8 | |
| 0.00 | 1.16 | 0.00 | 0.63 | -16.41 | 203.61 | 1.51 | 183.60 | 0.4030 | -327.0 | -221.2 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -17.67 | 203.39 | 1.29 | 182.93 | 0.4229 | -721.0 | -592.1 | |
| 3.76 | -43.00 | 2.04 | -43.00 | -17.01 | 203.36 | 1.26 | 182.93 | 0.4123 | -1065.5 | 999999 | |
| 0.00 | 1.52 | 0.00 | 0.83 | -17.37 | 203.33 | 1.23 | 182.81 | 0.4181 | -676.0 | -566.3 | |
| 0.00 | 3.58 | 0.00 | 1.97 | -18.78 | 203.27 | 1.17 | 182.53 | 0.4403 | -722.0 | -529.5 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -18.57 | 203.01 | 0.92 | 181.99 | 0.4369 | -840.0 | -680.6 | |
| 0.81 | 3.67 | 0.43 | 1.98 | -15.98 | 202.97 | 0.87 | 182.13 | 0.3956 | -985.9 | -805.0 | |
| 0.00 | 1.79 | 0.00 | 0.96 | -14.96 | 202.94 | 0.84 | 182.15 | 0.3791 | -957.0 | -825.9 | |
| 0.00 | 2.15 | 0.00 | 1.16 | -16.28 | 202.94 | 0.84 | 182.03 | 0.4003 | -897.0 | -698.4 | |
| 0.00 | 1.25 | 0.00 | 0.67 | -15.72 | 202.91 | 0.81 | 182.00 | 0.3913 | -893.0 | -664.6 | |
| 0.00 | 0.98 | 0.00 | 0.52 | -14.21 | 202.84 | 0.74 | 181.97 | 0.3669 | -890.0 | -696.8 | |
| 0.00 | 1.07 | 0.00 | 0.57 | -14.47 | 202.81 | 0.71 | 181.87 | 0.3711 | -1022.0 | -814.7 | |
| 0.00 | 0.54 | 0.00 | 0.29 | -17.37 | 202.72 | 0.63 | 181.43 | 0.4177 | -690.0 | -518.8 | |
| 3.58 | 7.16 | 1.94 | 3.88 | -16.84 | 202.47 | 0.37 | 180.87 | 0.4091 | -986.9 | -762.8 | |
| 0.00 | 1.07 | 0.00 | 0.57 | -12.69 | 202.41 | 0.31 | 180.88 | 0.3418 | -843.0 | -642.1 | |
| 0.00 | 1.34 | 0.00 | 0.72 | -14.57 | 202.28 | 0.18 | 180.47 | 0.3725 | -872.0 | -692.8 | |
| 0.00 | 1.70 | 0.00 | 0.93 | -18.20 | 202.06 | -0.04 | 179.91 | 0.4308 | -820.0 | -685.8 | |
| 0.00 | 2.24 | 0.00 | 1.23 | -18.34 | 201.90 | -0.20 | 179.56 | 0.4329 | -706.0 | -581.1 | |
| 1.61 | 191.88 | 0.87 | 103.11 | -16.64 | 201.87 | -0.23 | 179.46 | 0.4059 | -891.6 | -494.8 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -20.98 | 201.83 | -0.27 | 179.46 | 0.4743 | -856.0 | -689.1 | |
| 1.52 | -71.00 | 0.82 | -71.00 | -15.52 | 201.78 | -0.32 | 179.20 | 0.3879 | -1128.2 | 999999 | |
| 1.16 | -71.00 | 0.63 | -71.00 | -16.44 | 201.71 | -0.39 | 179.08 | 0.4027 | -1091.9 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.74 | -18.14 | 201.58 | -0.52 | 178.85 | 0.4298 | -876.0 | -693.3 | |
| 0.00 | 0.89 | 0.00 | 0.50 | -21.16 | 201.57 | -0.53 | 178.95 | 0.4770 | -668.0 | -602.6 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -21.50 | 201.56 | -0.53 | 178.96 | 0.4823 | -656.0 | -563.2 | |
| 11.81 | -71.00 | 6.35 | -71.00 | -15.58 | 201.56 | -0.54 | 178.66 | 0.3890 | -1306.2 | 999999 | |
| 0.00 | 1.70 | 0.00 | 0.93 | -17.77 | 201.52 | -0.58 | 178.69 | 0.4240 | -831.0 | -656.9 | |
| 5.37 | -71.00 | 2.90 | -71.00 | -16.41 | 201.46 | -0.64 | 178.47 | 0.4023 | -916.0 | 999999 | |
| 9.58 | -71.00 | 5.16 | -71.00 | -15.84 | 201.40 | -0.70 | 178.28 | 0.3933 | -984.4 | 999999 | |
| 2.42 | -71.00 | 1.29 | -71.00 | -15.19 | 201.40 | -0.70 | 178.24 | 0.3827 | -1419.4 | 999999 | |
| 10.11 | -71.00 | 5.43 | -71.00 | -15.38 | 201.28 | -0.82 | 177.94 | 0.3860 | -1359.0 | 999999 | |
| 0.00 | 2.77 | 0.00 | 1.51 | -17.50 | 201.20 | -0.90 | 177.95 | 0.4199 | -663.0 | -704.4 | |
| 3.94 | -71.00 | 2.12 | -71.00 | -15.61 | 201.15 | -0.95 | 177.64 | 0.3897 | -1035.5 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -19.21 | 201.00 | -1.10 | 177.67 | 0.4470 | -651.0 | -563.1 | |
| 0.00 | 1.16 | 0.00 | 0.64 | -18.24 | 200.97 | -1.12 | 177.51 | 0.4317 | -775.0 | -531.4 | |
| 0.00 | 1.16 | 0.00 | 0.63 | -16.21 | 200.99 | -1.11 | 177.32 | 0.3994 | 29.0 | 23.9 | |
| 0.00 | 3.85 | 0.00 | 2.16 | -20.81 | 200.92 | -1.18 | 177.66 | 0.4720 | -638.0 | -593.1 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -18.64 | 200.59 | -1.51 | 176.72 | 0.4384 | -826.0 | -708.7 | |
| 0.81 | 1.88 | 0.45 | 1.06 | -20.74 | 196.51 | -5.59 | 168.99 | 0.4787 | 773.6 | 640.8 | |
| 0.00 | 3.04 | 0.00 | 1.71 | -20.17 | 195.50 | -6.60 | 166.77 | 0.4735 | -940.0 | -726.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
