SDO HMI 2014-09-04 15:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 26.36 | 0.00 | 13.35 | 10.13 | 178.95 | 6.02 | 250.92 | 0.1935 | -191.6 | -202.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-04 15:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.97 | 0.00 | 1.01 | 11.40 | 187.95 | 15.02 | 286.88 | 0.2667 | -795.0 | -674.6 | |
| 0.00 | 1.34 | 0.00 | 0.69 | 11.17 | 187.62 | 14.69 | 286.33 | 0.2604 | -786.0 | -657.4 | |
| 0.00 | 3.04 | 0.00 | 1.55 | 11.18 | 186.16 | 13.23 | 287.87 | 0.2369 | -1054.0 | -822.2 | |
| 0.00 | 0.80 | 0.00 | 0.41 | 11.71 | 185.96 | 13.03 | 290.23 | 0.2364 | -695.0 | -583.8 | |
| 0.00 | 1.79 | 0.00 | 0.91 | 5.72 | 185.68 | 12.75 | 264.00 | 0.2218 | -879.0 | -697.8 | |
| 0.00 | 0.98 | 0.00 | 0.50 | 10.83 | 185.76 | 12.83 | 286.85 | 0.2290 | -876.0 | -733.8 | |
| 0.00 | 1.79 | 0.00 | 0.91 | 5.94 | 185.44 | 12.51 | 264.86 | 0.2173 | -1023.0 | -791.4 | |
| 0.00 | 2.23 | 0.00 | 1.13 | 10.64 | 185.25 | 12.32 | 286.57 | 0.2198 | -1009.0 | -853.0 | |
| 0.00 | 2.32 | 0.00 | 1.18 | 5.95 | 185.03 | 12.10 | 264.70 | 0.2104 | -913.0 | -774.4 | |
| 0.00 | 1.88 | 0.00 | 0.93 | 10.33 | 172.70 | -0.23 | 4.11 | 0.0546 | 1000.0 | 788.4 | |
| 0.00 | 1.79 | 0.00 | 0.89 | 9.54 | 171.60 | -1.33 | 29.47 | 0.0467 | 855.0 | 728.0 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 11.39 | 171.32 | -1.61 | 20.79 | 0.0781 | 906.0 | 688.1 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 14.72 | 164.21 | -8.73 | 48.04 | 0.1982 | 742.0 | 602.7 | |
| 0.00 | 2.68 | 0.00 | 1.35 | 10.43 | 163.94 | -8.99 | 69.47 | 0.1648 | 851.0 | 723.6 | |
| 0.00 | 1.52 | 0.00 | 0.77 | 15.28 | 161.77 | -11.17 | 52.66 | 0.2360 | 802.0 | 608.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
