SDO HMI 2014-09-04 18:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.05 | 95.00 | 7.33 | 53.58 | -18.24 | 158.50 | -12.77 | 153.93 | 0.4783 | 162.3 | -19.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-04 18:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.70 | 0.00 | 0.94 | -17.74 | 161.47 | -9.81 | 158.90 | 0.4525 | 1045.0 | 897.1 | |
| 0.00 | 0.89 | 0.00 | 0.49 | -17.54 | 161.38 | -9.89 | 158.57 | 0.4501 | 801.0 | 709.3 | |
| 0.00 | 1.07 | 0.00 | 0.59 | -17.12 | 160.83 | -10.45 | 157.11 | 0.4473 | 930.0 | 783.2 | |
| 0.00 | 4.29 | 0.00 | 2.38 | -17.49 | 160.77 | -10.50 | 157.33 | 0.4529 | 755.0 | 901.9 | |
| 1.61 | 7.32 | 0.90 | 4.08 | -17.92 | 160.68 | -10.59 | 157.54 | 0.4596 | 910.9 | 820.3 | |
| 0.27 | -5.00 | 0.15 | -5.00 | -17.76 | 160.60 | -10.68 | 157.23 | 0.4578 | 1075.0 | 999999 | |
| 0.00 | 3.48 | 0.00 | 1.95 | -18.26 | 160.43 | -10.84 | 157.37 | 0.4659 | 819.0 | 702.7 | |
| 0.71 | 2.77 | 0.40 | 1.54 | -17.60 | 160.25 | -11.02 | 156.43 | 0.4576 | 873.2 | 770.9 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -18.44 | 160.20 | -11.08 | 157.07 | 0.4698 | 595.0 | 457.8 | |
| 2.68 | 5.63 | 1.49 | 3.14 | -17.87 | 160.17 | -11.11 | 156.52 | 0.4619 | 949.9 | 707.1 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -17.47 | 160.03 | -11.24 | 155.90 | 0.4572 | 678.0 | 564.8 | |
| 1.25 | 3.48 | 0.70 | 1.95 | -17.94 | 159.90 | -11.37 | 156.09 | 0.4646 | 751.5 | 605.9 | |
| 0.00 | 5.89 | 0.00 | 3.31 | -18.35 | 159.78 | -11.49 | 156.23 | 0.4711 | 689.0 | 545.7 | |
| 0.00 | 1.25 | 0.00 | 0.70 | -17.41 | 159.81 | -11.46 | 155.42 | 0.4577 | 701.0 | 511.2 | |
| 0.00 | 1.43 | 0.00 | 0.80 | -17.75 | 159.76 | -11.52 | 155.63 | 0.4628 | 669.0 | 551.5 | |
| 0.00 | 4.73 | 0.00 | 2.64 | -17.52 | 159.51 | -11.76 | 154.96 | 0.4612 | 602.0 | 697.9 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -17.97 | 158.73 | -12.54 | 153.98 | 0.4726 | 902.0 | 714.2 | |
| 0.00 | 0.89 | 0.00 | 0.50 | -18.45 | 158.60 | -12.67 | 154.19 | 0.4800 | 586.0 | 378.5 | |
| 0.00 | 2.50 | 0.00 | 1.43 | -19.18 | 157.69 | -13.59 | 153.32 | 0.4961 | -924.0 | -817.9 | |
| 0.00 | 2.23 | 0.00 | 1.28 | -19.35 | 157.51 | -13.77 | 153.18 | 0.4996 | -715.0 | -604.9 | |
| 0.00 | 1.61 | 0.00 | 0.91 | -17.65 | 157.42 | -13.85 | 151.32 | 0.4774 | -692.0 | -659.8 | |
| 0.00 | 1.52 | 0.00 | 0.85 | -17.38 | 157.41 | -13.86 | 151.02 | 0.4740 | -937.0 | -658.2 | |
| 0.00 | 13.57 | 0.00 | 7.74 | -18.99 | 157.18 | -14.10 | 152.28 | 0.4971 | -1003.0 | -858.5 | |
| 0.00 | 1.52 | 0.00 | 0.87 | -19.26 | 157.12 | -14.15 | 152.45 | 0.5011 | -744.0 | -588.8 | |
| 1.70 | 2.86 | 0.94 | 1.59 | -16.10 | 157.18 | -14.09 | 149.20 | 0.4587 | -828.8 | -603.2 | |
| 0.00 | 0.98 | 0.00 | 0.56 | -18.13 | 156.96 | -14.32 | 151.03 | 0.4872 | -898.0 | -689.6 | |
| 3.04 | 16.25 | 1.73 | 9.28 | -18.61 | 156.48 | -14.79 | 150.75 | 0.4971 | -1005.4 | -693.2 | |
| 1.79 | -27.00 | 1.02 | -27.00 | -18.68 | 156.31 | -14.96 | 150.54 | 0.4993 | -854.8 | 999999 | |
| 0.00 | 3.93 | 0.00 | 2.26 | -19.15 | 155.41 | -15.87 | 149.58 | 0.5121 | -765.0 | -651.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
