SDO HMI 2014-09-05 01:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.37 | 107.56 | 11.32 | 59.79 | -18.24 | 158.59 | -8.82 | 161.40 | 0.4554 | 270.4 | 2.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-05 01:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.63 | -17.40 | 163.68 | -3.73 | 171.54 | 0.4232 | 704.0 | 499.2 | |
| 0.00 | 1.52 | 0.00 | 0.83 | -17.75 | 161.64 | -5.77 | 167.21 | 0.4346 | 757.0 | 631.3 | |
| 0.00 | 0.71 | 0.00 | 0.39 | -16.96 | 161.63 | -5.78 | 166.77 | 0.4223 | 643.0 | 547.0 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -16.86 | 161.44 | -5.96 | 166.30 | 0.4215 | 633.0 | 470.3 | |
| 0.00 | 1.70 | 0.00 | 0.93 | -17.30 | 161.02 | -6.39 | 165.62 | 0.4299 | 885.0 | 771.2 | |
| 0.00 | 1.79 | 0.00 | 0.98 | -17.10 | 161.02 | -6.39 | 165.51 | 0.4268 | 761.0 | 645.2 | |
| 0.00 | 1.61 | 0.00 | 0.88 | -17.53 | 160.91 | -6.50 | 165.54 | 0.4338 | 997.0 | 789.2 | |
| 1.88 | 3.39 | 1.03 | 1.87 | -17.87 | 160.74 | -6.67 | 165.37 | 0.4396 | 915.8 | 750.3 | |
| 0.00 | 1.88 | 0.00 | 1.04 | -18.20 | 160.60 | -6.81 | 165.28 | 0.4453 | 742.0 | 588.8 | |
| 4.65 | 25.28 | 2.56 | 13.92 | -17.70 | 160.36 | -7.05 | 164.48 | 0.4387 | 978.3 | 756.3 | |
| 0.00 | 2.50 | 0.00 | 1.38 | -18.01 | 160.35 | -7.06 | 164.65 | 0.4433 | 714.0 | 533.6 | |
| 0.00 | 1.43 | 0.00 | 0.79 | -17.91 | 160.00 | -7.41 | 163.87 | 0.4434 | 613.0 | 513.2 | |
| 0.00 | 1.52 | 0.00 | 0.83 | -17.04 | 160.01 | -7.40 | 163.29 | 0.4303 | 693.0 | 625.1 | |
| 0.00 | 0.63 | 0.00 | 0.34 | -15.82 | 159.99 | -7.42 | 162.37 | 0.4119 | 721.0 | 637.0 | |
| 0.00 | 1.25 | 0.00 | 0.68 | -16.78 | 159.92 | -7.49 | 162.92 | 0.4267 | 713.0 | 536.8 | |
| 2.14 | -10.00 | 1.18 | -10.00 | -17.51 | 159.83 | -7.58 | 163.24 | 0.4382 | 883.8 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.69 | -17.28 | 159.71 | -7.70 | 162.83 | 0.4352 | 686.0 | 476.2 | |
| 0.00 | 0.98 | 0.00 | 0.54 | -17.49 | 159.28 | -8.13 | 162.10 | 0.4403 | 228.0 | 298.4 | |
| 0.89 | 2.86 | 0.49 | 1.58 | -18.00 | 158.97 | -8.44 | 161.83 | 0.4494 | 768.6 | 656.1 | |
| 0.00 | 1.88 | 0.00 | 1.05 | -18.74 | 158.42 | -8.99 | 161.28 | 0.4631 | 772.0 | 566.6 | |
| 0.00 | 1.70 | 0.00 | 0.95 | -18.70 | 157.51 | -9.90 | 159.51 | 0.4670 | -826.0 | -641.4 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -19.51 | 157.30 | -10.11 | 159.75 | 0.4799 | -297.0 | -405.1 | |
| 3.39 | 34.48 | 1.91 | 19.38 | -18.97 | 157.30 | -10.11 | 159.33 | 0.4721 | -1100.8 | -739.9 | |
| 0.98 | 1.97 | 0.54 | 1.08 | -16.17 | 157.27 | -10.14 | 156.86 | 0.4320 | -725.4 | -621.5 | |
| 4.65 | -23.00 | 2.61 | -23.00 | -19.01 | 157.01 | -10.40 | 158.81 | 0.4743 | -1073.9 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -18.95 | 156.75 | -10.66 | 158.29 | 0.4749 | -577.0 | -508.8 | |
| 1.79 | 10.63 | 1.00 | 5.97 | -18.62 | 156.32 | -11.09 | 157.22 | 0.4728 | -837.3 | -784.2 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -19.32 | 155.55 | -11.86 | 156.43 | 0.4871 | -764.0 | -562.5 | |
| 0.00 | 1.25 | 0.00 | 0.72 | -20.70 | 153.62 | -13.79 | 154.39 | 0.5180 | 709.0 | 552.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
