SDO HMI 2014-09-05 10:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.20 | 410.17 | 66.94 | 314.15 | -14.71 | 207.18 | 44.71 | 243.32 | 0.7616 | 48.0 | 45.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-05 10:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.36 | 0.00 | 0.30 | -15.32 | 211.35 | 48.87 | 244.79 | 0.8052 | -81.0 | -113.5 | |
| 0.00 | 0.54 | 0.00 | 0.43 | -12.57 | 210.48 | 48.01 | 247.66 | 0.7865 | 747.0 | 607.7 | |
| 36.28 | 232.16 | 29.43 | 188.50 | -14.09 | 210.65 | 48.17 | 245.92 | 0.7938 | 991.9 | 260.9 | |
| 0.00 | 1.43 | 0.00 | 1.17 | -15.20 | 210.74 | 48.26 | 244.67 | 0.7989 | 222.0 | 260.9 | |
| 1.70 | -3.00 | 1.36 | -3.00 | -14.43 | 209.86 | 47.38 | 245.17 | 0.7875 | 803.3 | 999999 | |
| 0.27 | -3.00 | 0.21 | -3.00 | -14.19 | 209.65 | 47.18 | 245.37 | 0.7845 | 889.0 | 999999 | |
| 1.07 | -3.00 | 0.85 | -3.00 | -14.31 | 209.59 | 47.12 | 245.19 | 0.7845 | 935.2 | 999999 | |
| 0.45 | 2.06 | 0.35 | 1.62 | -13.97 | 209.09 | 46.61 | 245.36 | 0.7781 | 738.2 | 620.9 | |
| 0.00 | 3.31 | 0.00 | 2.60 | -14.26 | 209.12 | 46.65 | 245.03 | 0.7796 | 699.0 | 643.9 | |
| 0.63 | 1.88 | 0.49 | 1.46 | -13.94 | 208.72 | 46.24 | 245.23 | 0.7743 | 792.7 | 691.1 | |
| 0.00 | 1.97 | 0.00 | 1.55 | -14.88 | 208.79 | 46.31 | 244.14 | 0.7789 | 591.0 | 473.8 | |
| 0.00 | 0.71 | 0.00 | 0.57 | -16.07 | 208.68 | 46.20 | 242.68 | 0.7829 | 551.0 | 534.9 | |
| 0.00 | 0.27 | 0.00 | 0.21 | -15.17 | 208.10 | 45.63 | 243.46 | 0.7734 | 562.0 | 504.0 | |
| 0.00 | 0.80 | 0.00 | 0.64 | -17.87 | 208.33 | 45.86 | 240.41 | 0.7877 | 448.0 | 354.4 | |
| 0.00 | 0.71 | 0.00 | 0.57 | -18.22 | 208.13 | 45.66 | 239.91 | 0.7874 | 278.0 | 267.0 | |
| 0.00 | 0.71 | 0.00 | 0.54 | -13.87 | 206.70 | 44.23 | 244.33 | 0.7536 | -390.0 | -267.6 | |
| 0.00 | 2.23 | 0.00 | 1.71 | -16.27 | 206.67 | 44.20 | 241.42 | 0.7644 | 718.0 | 498.0 | |
| 6.52 | 8.76 | 4.82 | 6.47 | -14.44 | 205.54 | 43.07 | 243.03 | 0.7443 | -612.6 | -330.5 | |
| 0.00 | 1.34 | 0.00 | 1.01 | -16.71 | 205.44 | 42.97 | 240.22 | 0.7544 | -481.0 | -430.5 | |
| 0.00 | 0.89 | 0.00 | 0.67 | -16.24 | 205.27 | 42.79 | 240.70 | 0.7503 | -371.0 | -262.0 | |
| 0.89 | 2.41 | 0.65 | 1.76 | -14.61 | 204.52 | 42.04 | 242.27 | 0.7344 | 768.4 | 637.9 | |
| 0.00 | 1.07 | 0.00 | 0.78 | -14.69 | 204.32 | 41.85 | 242.06 | 0.7328 | 697.0 | 512.1 | |
| 0.00 | 1.70 | 0.00 | 1.24 | -15.63 | 204.26 | 41.78 | 240.87 | 0.7369 | -489.0 | -420.9 | |
| 0.00 | 1.25 | 0.00 | 0.90 | -14.99 | 203.64 | 41.16 | 241.30 | 0.7272 | 630.0 | 582.7 | |
| 0.00 | 1.07 | 0.00 | 0.80 | -17.75 | 204.14 | 41.67 | 238.24 | 0.7470 | -453.0 | -366.9 | |
| 0.00 | 0.63 | 0.00 | 0.47 | -18.08 | 204.16 | 41.68 | 237.86 | 0.7489 | -291.0 | -276.3 | |
| 0.00 | 0.71 | 0.00 | 0.53 | -17.67 | 203.70 | 41.23 | 238.06 | 0.7422 | -511.0 | -437.2 | |
| 0.00 | 1.52 | 0.00 | 1.13 | -18.28 | 203.79 | 41.31 | 237.40 | 0.7464 | -473.0 | -390.9 | |
| 9.03 | 21.63 | 6.40 | 15.36 | -16.34 | 202.02 | 39.55 | 238.64 | 0.7178 | -727.9 | -200.2 | |
| 1.97 | 4.38 | 1.38 | 3.08 | -15.77 | 201.80 | 39.33 | 239.22 | 0.7122 | -595.6 | -459.3 | |
| 0.00 | 0.98 | 0.00 | 0.69 | -15.62 | 201.56 | 39.09 | 239.26 | 0.7089 | -372.0 | -388.3 | |
| 0.00 | 1.43 | 0.00 | 1.01 | -16.12 | 201.64 | 39.16 | 238.68 | 0.7125 | -670.0 | -616.3 | |
| 2.06 | 4.74 | 1.46 | 3.35 | -16.65 | 201.72 | 39.25 | 238.08 | 0.7165 | -667.6 | -535.7 | |
| 0.00 | 0.89 | 0.00 | 0.64 | -17.45 | 201.84 | 39.37 | 237.18 | 0.7224 | -557.0 | -434.6 | |
| 5.18 | 13.76 | 3.62 | 9.61 | -15.95 | 201.28 | 38.80 | 238.65 | 0.7078 | -915.2 | -723.2 | |
| 0.00 | 1.43 | 0.00 | 1.00 | -16.42 | 201.34 | 38.87 | 238.12 | 0.7112 | -686.0 | -560.8 | |
| 4.38 | -35.00 | 3.06 | -35.00 | -16.14 | 201.12 | 38.64 | 238.32 | 0.7072 | -926.3 | 999999 | |
| 0.54 | 1.43 | 0.38 | 1.00 | -16.60 | 201.14 | 38.67 | 237.77 | 0.7102 | -684.5 | -609.5 | |
| 0.00 | 3.40 | 0.00 | 2.42 | -18.14 | 201.41 | 38.93 | 236.06 | 0.7221 | -702.0 | -554.0 | |
| 0.00 | 1.79 | 0.00 | 1.23 | -14.92 | 200.57 | 38.09 | 239.50 | 0.6942 | -27.0 | -75.1 | |
| 0.00 | 1.88 | 0.00 | 1.31 | -16.28 | 200.83 | 38.35 | 237.96 | 0.7050 | -743.0 | -658.9 | |
| 4.56 | 79.53 | 3.14 | 54.18 | -15.43 | 200.48 | 38.00 | 238.79 | 0.6962 | -674.8 | -562.5 | |
| 11.08 | -42.00 | 7.57 | -42.00 | -15.08 | 200.16 | 37.69 | 239.03 | 0.6908 | -1002.0 | 999999 | |
| 2.59 | -42.00 | 1.77 | -42.00 | -14.82 | 200.11 | 37.63 | 239.33 | 0.6886 | -911.8 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.91 | -19.82 | 197.04 | 34.56 | 230.89 | 0.6902 | -592.0 | -471.5 | |
| 0.00 | 1.07 | 0.00 | 0.73 | -20.60 | 196.57 | 34.09 | 229.60 | 0.6914 | -471.0 | -409.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
