SDO HMI 2014-09-05 12:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48.33 | 347.87 | 81.44 | 600.76 | 15.03 | 87.15 | -74.23 | 76.43 | 0.9572 | 95.8 | -149.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-05 12:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.41 | 331.25 | 62.41 | 569.17 | 15.16 | 87.93 | -73.45 | 76.34 | 0.9535 | 279.4 | -144.4 | |
| 0.00 | 12.24 | 0.00 | 23.53 | 16.03 | 84.93 | -76.45 | 75.28 | 0.9672 | -303.0 | -286.1 | |
| 8.31 | -1.00 | 16.05 | -1.00 | 14.68 | 84.98 | -76.40 | 76.67 | 0.9674 | -447.2 | 999999 | |
| 1.61 | -1.00 | 2.98 | -1.00 | 13.95 | 85.61 | -75.76 | 77.47 | 0.9649 | -444.7 | 999999 | |
| 0.00 | 1.70 | 0.00 | 3.10 | 12.83 | 85.90 | -75.48 | 78.65 | 0.9639 | -350.0 | -302.3 | |
| 0.00 | 0.27 | 0.00 | 0.48 | 12.63 | 86.07 | -75.31 | 78.87 | 0.9632 | -278.0 | -254.0 | |
| 0.00 | 2.41 | 0.00 | 4.48 | 12.43 | 85.73 | -75.64 | 79.04 | 0.9648 | 176.0 | 149.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
