SDO HMI 2014-09-05 16:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.01 | 0.00 | 5.15 | -20.70 | 169.52 | 10.35 | 199.71 | 0.4981 | 756.4 | 605.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-05 16:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.25 | 0.00 | 0.72 | -21.03 | 171.19 | 12.02 | 202.43 | 0.5115 | 685.0 | 595.1 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -21.23 | 171.01 | 11.84 | 201.97 | 0.5132 | 764.0 | 666.2 | |
| 0.00 | 1.16 | 0.00 | 0.67 | -20.95 | 170.92 | 11.75 | 202.04 | 0.5089 | 813.0 | 636.2 | |
| 0.00 | 1.61 | 0.00 | 0.93 | -21.19 | 170.81 | 11.64 | 201.66 | 0.5115 | 611.0 | 495.1 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -22.25 | 169.10 | 9.93 | 198.03 | 0.5177 | 669.0 | 463.9 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -19.64 | 167.50 | 8.33 | 196.84 | 0.4729 | 832.0 | 725.4 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -19.47 | 167.43 | 8.25 | 196.81 | 0.4700 | 911.0 | 754.2 | |
| 0.00 | 1.07 | 0.00 | 0.60 | -19.67 | 167.31 | 8.13 | 196.45 | 0.4724 | 766.0 | 574.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
