SDO HMI 2014-09-06 08:11:06 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.09 | 21.17 | 3.68 | 15.01 | -8.76 | 193.25 | 42.98 | 250.21 | 0.7181 | -111.6 | -127.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-06 08:11:06 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.34 | 2.95 | 0.98 | 2.17 | -8.95 | 195.18 | 44.91 | 250.83 | 0.7406 | 511.3 | 438.4 | |
| 0.00 | 0.89 | 0.00 | 0.65 | -9.45 | 194.78 | 44.51 | 250.02 | 0.7381 | 396.0 | 362.9 | |
| 2.86 | 4.82 | 2.08 | 3.50 | -9.10 | 194.47 | 44.20 | 250.32 | 0.7334 | 665.2 | 518.0 | |
| 0.00 | 1.25 | 0.00 | 0.90 | -8.99 | 193.94 | 43.67 | 250.23 | 0.7270 | 535.0 | 483.4 | |
| 0.00 | 1.70 | 0.00 | 1.18 | -8.14 | 192.48 | 42.21 | 250.70 | 0.7070 | -601.0 | -521.2 | |
| 0.00 | 2.86 | 0.00 | 1.98 | -8.26 | 192.08 | 41.81 | 250.35 | 0.7029 | -617.0 | -463.9 | |
| 0.00 | 0.54 | 0.00 | 0.37 | -8.04 | 192.05 | 41.78 | 250.64 | 0.7016 | -514.0 | -502.5 | |
| 0.00 | 0.63 | 0.00 | 0.43 | -8.60 | 191.96 | 41.69 | 249.85 | 0.7028 | -556.0 | -434.3 | |
| 0.00 | 0.80 | 0.00 | 0.56 | -8.49 | 191.82 | 41.55 | 249.93 | 0.7008 | -608.0 | -468.8 | |
| 0.89 | 3.04 | 0.62 | 2.10 | -8.83 | 191.74 | 41.48 | 249.43 | 0.7013 | -606.9 | -426.4 | |
| 0.00 | 0.71 | 0.00 | 0.49 | -8.57 | 191.67 | 41.40 | 249.74 | 0.6994 | -424.0 | -442.8 | |
| 0.00 | 0.98 | 0.00 | 0.68 | -8.68 | 191.52 | 41.25 | 249.52 | 0.6981 | -534.0 | -516.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
