SDO HMI 2014-09-06 11:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.81 | 37.41 | 18.88 | 64.90 | -20.37 | 79.43 | -69.29 | 113.83 | 0.9596 | -138.4 | -135.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-06 11:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.07 | 4.91 | 1.62 | 7.41 | -20.62 | 82.35 | -66.36 | 114.83 | 0.9461 | 335.1 | 339.2 | |
| 0.89 | 2.14 | 1.40 | 3.35 | -20.48 | 81.57 | -67.15 | 114.48 | 0.9499 | 287.0 | 171.6 | |
| 1.70 | 3.39 | 2.91 | 5.82 | -21.73 | 80.10 | -68.62 | 115.36 | 0.9585 | 387.6 | 311.9 | |
| 1.70 | 3.93 | 2.93 | 6.78 | -21.40 | 79.81 | -68.91 | 114.95 | 0.9594 | 60.4 | -42.5 | |
| 0.00 | 1.70 | 0.00 | 2.86 | -19.96 | 79.88 | -68.84 | 113.51 | 0.9572 | -387.0 | -348.5 | |
| 0.00 | 0.27 | 0.00 | 0.46 | -19.94 | 79.54 | -69.18 | 113.40 | 0.9587 | -454.0 | -435.0 | |
| 0.00 | 1.25 | 0.00 | 2.24 | -20.45 | 78.83 | -69.89 | 113.75 | 0.9625 | -171.0 | -117.5 | |
| 0.00 | 0.71 | 0.00 | 1.24 | -19.80 | 79.30 | -69.42 | 113.21 | 0.9596 | -466.0 | -417.2 | |
| 0.00 | 1.16 | 0.00 | 2.08 | -20.25 | 78.85 | -69.87 | 113.56 | 0.9622 | -435.0 | -401.5 | |
| 0.00 | 1.16 | 0.00 | 1.94 | -19.20 | 79.86 | -68.85 | 112.74 | 0.9563 | -430.0 | -358.5 | |
| 5.45 | 16.79 | 10.02 | 30.72 | -19.96 | 78.29 | -70.43 | 113.13 | 0.9642 | -334.2 | -278.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
