SDO HMI 2014-09-06 21:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.16 | 148.43 | 34.06 | 207.04 | -14.46 | 209.35 | 66.15 | 251.42 | 0.9351 | 334.1 | 136.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-06 21:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.43 | 131.50 | 29.17 | 188.60 | -14.36 | 210.03 | 66.83 | 251.72 | 0.9394 | 579.9 | 163.9 | |
| 0.00 | 0.80 | 0.00 | 1.10 | -13.26 | 209.32 | 66.12 | 252.70 | 0.9338 | 348.0 | 304.2 | |
| 0.00 | 2.14 | 0.00 | 2.61 | -16.28 | 205.60 | 62.40 | 248.55 | 0.9157 | 462.0 | 392.7 | |
| 0.00 | 1.87 | 0.00 | 2.17 | -17.14 | 203.81 | 60.61 | 247.11 | 0.9056 | -346.0 | -362.1 | |
| 1.52 | 2.85 | 1.59 | 3.00 | -14.89 | 201.40 | 58.20 | 248.76 | 0.8832 | -376.6 | -231.9 | |
| 1.43 | 2.94 | 1.51 | 3.12 | -15.62 | 201.55 | 58.35 | 248.02 | 0.8860 | -297.2 | -149.9 | |
| 0.00 | 1.43 | 0.00 | 1.49 | -15.38 | 201.14 | 57.94 | 248.15 | 0.8823 | -625.0 | -514.8 | |
| 0.00 | 0.80 | 0.00 | 0.84 | -15.57 | 201.10 | 57.90 | 247.93 | 0.8825 | -602.0 | -547.8 | |
| 1.78 | 3.21 | 1.79 | 3.22 | -15.26 | 199.80 | 56.60 | 247.83 | 0.8717 | -651.5 | -524.9 | |
| 0.00 | 0.89 | 0.00 | 0.89 | -14.92 | 199.61 | 56.41 | 248.14 | 0.8692 | -554.0 | -537.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
