SDO HMI 2014-09-06 23:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 118.42 | 663.43 | 102.04 | 569.19 | 15.00 | 86.56 | -55.53 | 76.73 | 0.8204 | 187.8 | -70.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-06 23:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.54 | 1.70 | 0.42 | 1.35 | 15.27 | 90.20 | -51.90 | 76.23 | 0.7839 | -622.5 | -527.5 | |
| 0.00 | 1.25 | 0.00 | 1.00 | 15.61 | 89.87 | -52.23 | 75.82 | 0.7875 | 399.0 | 355.1 | |
| 0.00 | 1.43 | 0.00 | 1.19 | 18.79 | 88.25 | -53.85 | 71.96 | 0.8062 | 518.0 | 378.9 | |
| 0.00 | 0.89 | 0.00 | 0.73 | 13.85 | 88.66 | -53.44 | 78.09 | 0.7992 | 408.0 | 324.1 | |
| 0.00 | 1.70 | 0.00 | 1.38 | 12.30 | 89.09 | -53.01 | 80.04 | 0.7945 | -714.0 | -571.9 | |
| 0.00 | 0.54 | 0.00 | 0.44 | 13.86 | 88.39 | -53.70 | 78.09 | 0.8019 | -176.0 | -196.8 | |
| 0.00 | 0.80 | 0.00 | 0.67 | 14.09 | 88.21 | -53.89 | 77.81 | 0.8038 | 343.0 | 262.3 | |
| 0.00 | 0.54 | 0.00 | 0.47 | 18.19 | 86.31 | -55.79 | 72.87 | 0.8243 | 316.0 | 304.2 | |
| 74.33 | 633.70 | 62.80 | 543.72 | 15.55 | 87.40 | -54.69 | 76.03 | 0.8124 | 918.7 | -69.6 | |
| 0.00 | 4.55 | 0.00 | 3.79 | 13.97 | 87.93 | -54.16 | 77.97 | 0.8066 | -192.0 | -147.9 | |
| 0.00 | 1.43 | 0.00 | 1.25 | 16.77 | 85.88 | -56.21 | 74.62 | 0.8275 | 436.0 | 391.0 | |
| 0.00 | 8.57 | 0.00 | 7.55 | 16.41 | 85.70 | -56.39 | 75.07 | 0.8290 | 29.0 | 29.1 | |
| 0.00 | 1.25 | 0.00 | 1.07 | 12.98 | 86.97 | -55.13 | 79.21 | 0.8160 | -523.0 | -537.9 | |
| 0.00 | 1.34 | 0.00 | 1.15 | 12.71 | 86.51 | -55.59 | 79.53 | 0.8206 | -579.0 | -539.9 | |
| 0.00 | 1.07 | 0.00 | 0.96 | 16.30 | 85.00 | -57.10 | 75.22 | 0.8355 | -245.0 | -251.5 | |
| 12.85 | -9.00 | 11.38 | -9.00 | 13.46 | 85.41 | -56.69 | 78.63 | 0.8312 | -809.3 | 999999 | |
| 28.11 | -9.00 | 25.14 | -9.00 | 14.41 | 85.04 | -57.05 | 77.49 | 0.8347 | -899.7 | 999999 | |
| 2.59 | -9.00 | 2.30 | -9.00 | 13.81 | 85.22 | -56.88 | 78.21 | 0.8330 | -848.2 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.65 | 12.20 | 84.24 | -57.86 | 80.13 | 0.8422 | -281.0 | -257.1 | |
| 0.00 | 1.96 | 0.00 | 1.82 | 13.38 | 83.69 | -58.41 | 78.73 | 0.8471 | -600.0 | -496.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
