SDO HMI 2014-09-07 00:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.28 | 31.15 | 11.49 | 87.32 | -16.59 | 64.55 | -77.00 | 108.40 | 0.9847 | -12.3 | -45.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-07 00:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.96 | 12.58 | 5.08 | 33.92 | -16.90 | 65.52 | -76.03 | 108.88 | 0.9822 | 357.3 | 35.6 | |
| 2.32 | -1.00 | 6.41 | -1.00 | -16.81 | 64.66 | -76.88 | 108.63 | 0.9847 | -74.2 | 999999 | |
| 0.00 | 11.87 | 0.00 | 31.38 | -16.30 | 65.19 | -76.36 | 108.22 | 0.9828 | 150.0 | 109.2 | |
| 0.00 | 3.48 | 0.00 | 10.98 | -17.01 | 63.33 | -78.21 | 108.59 | 0.9883 | -471.0 | -366.9 | |
| 0.00 | 1.07 | 0.00 | 3.29 | -16.63 | 63.59 | -77.96 | 108.26 | 0.9875 | -368.0 | -338.2 | |
| 0.00 | 0.45 | 0.00 | 1.37 | -15.60 | 63.31 | -78.23 | 107.19 | 0.9877 | -117.0 | -113.8 | |
| 0.00 | 1.16 | 0.00 | 4.34 | -16.27 | 61.62 | -79.92 | 107.56 | 0.9919 | -406.0 | -390.2 | |
| 0.00 | 0.54 | 0.00 | 2.04 | -15.95 | 61.60 | -79.95 | 107.24 | 0.9919 | -343.0 | -335.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
