SDO HMI 2014-09-07 04:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.75 | 248.54 | 45.50 | 164.43 | -19.77 | 107.25 | -32.10 | 131.10 | 0.6660 | 670.0 | 439.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-07 04:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.23 | 0.00 | 1.45 | -20.43 | 109.77 | -29.58 | 134.16 | 0.6470 | 749.0 | 624.6 | |
| 6.52 | 12.95 | 4.39 | 8.73 | -22.82 | 108.34 | -31.01 | 135.58 | 0.6807 | 847.4 | 659.4 | |
| 0.00 | 2.05 | 0.00 | 1.39 | -23.22 | 108.08 | -31.27 | 135.79 | 0.6864 | 561.0 | 478.7 | |
| 0.00 | 0.89 | 0.00 | 0.61 | -23.80 | 107.89 | -31.46 | 136.25 | 0.6928 | 575.0 | 472.4 | |
| 0.45 | -2.00 | 0.30 | -2.00 | -22.99 | 107.95 | -31.40 | 135.42 | 0.6856 | 587.8 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.92 | -23.49 | 107.78 | -31.57 | 135.82 | 0.6912 | 576.0 | 489.2 | |
| 15.45 | 87.40 | 10.00 | 56.53 | -18.80 | 108.40 | -30.95 | 130.93 | 0.6467 | 1124.1 | 550.0 | |
| 2.86 | -7.00 | 1.86 | -7.00 | -18.98 | 108.18 | -31.17 | 130.96 | 0.6504 | 671.6 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.40 | -22.58 | 107.32 | -32.02 | 134.42 | 0.6878 | 595.0 | 409.6 | |
| 3.48 | -7.00 | 2.26 | -7.00 | -18.78 | 108.14 | -31.20 | 130.68 | 0.6491 | 800.7 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.36 | -20.08 | 107.37 | -31.98 | 131.57 | 0.6672 | 664.0 | 657.5 | |
| 0.00 | 1.79 | 0.00 | 1.22 | -22.10 | 106.83 | -32.52 | 133.45 | 0.6884 | 722.0 | 589.3 | |
| 10.09 | 47.32 | 6.74 | 31.58 | -20.51 | 107.11 | -32.23 | 131.86 | 0.6730 | 866.7 | 358.4 | |
| 26.78 | 68.39 | 17.86 | 45.52 | -19.76 | 106.68 | -32.67 | 130.60 | 0.6714 | 999.1 | 532.4 | |
| 0.00 | 0.89 | 0.00 | 0.60 | -20.81 | 106.23 | -33.11 | 131.47 | 0.6838 | 335.0 | 313.4 | |
| 0.00 | 1.43 | 0.00 | 0.94 | -18.69 | 106.54 | -32.81 | 129.19 | 0.6645 | 589.0 | 550.8 | |
| 3.12 | 5.00 | 2.09 | 3.34 | -19.26 | 106.11 | -33.24 | 129.52 | 0.6732 | 671.6 | 359.0 | |
| 0.00 | 0.27 | 0.00 | 0.19 | -20.99 | 104.70 | -34.64 | 130.44 | 0.6997 | 660.0 | 548.0 | |
| 0.00 | 0.80 | 0.00 | 0.55 | -20.40 | 104.82 | -34.53 | 129.84 | 0.6943 | 647.0 | 508.8 | |
| 0.00 | 1.34 | 0.00 | 0.91 | -19.34 | 104.54 | -34.81 | 128.37 | 0.6893 | -565.0 | -326.5 | |
| 0.00 | 0.71 | 0.00 | 0.48 | -18.11 | 104.52 | -34.83 | 126.85 | 0.6807 | 741.0 | 652.8 | |
| 0.00 | 1.07 | 0.00 | 0.72 | -18.31 | 104.47 | -34.87 | 127.07 | 0.6826 | 716.0 | 529.9 | |
| 0.00 | 1.07 | 0.00 | 0.73 | -18.52 | 103.48 | -35.86 | 126.57 | 0.6940 | -484.0 | -356.1 | |
| 0.00 | 1.25 | 0.00 | 0.86 | -18.37 | 103.24 | -36.10 | 126.22 | 0.6954 | -602.0 | -468.0 | |
| 0.00 | 0.71 | 0.00 | 0.50 | -18.94 | 102.86 | -36.48 | 126.62 | 0.7030 | -236.0 | -271.8 | |
| 0.00 | 0.27 | 0.00 | 0.18 | -16.62 | 103.26 | -36.09 | 124.06 | 0.6836 | -636.0 | -629.7 | |
| 0.00 | 1.25 | 0.00 | 0.86 | -17.71 | 102.81 | -36.54 | 125.09 | 0.6954 | -390.0 | -295.3 | |
| 0.00 | 1.07 | 0.00 | 0.75 | -18.73 | 102.52 | -36.83 | 126.12 | 0.7051 | -581.0 | -378.9 | |
| 0.00 | 1.34 | 0.00 | 0.93 | -18.64 | 102.38 | -36.97 | 125.92 | 0.7059 | -654.0 | -570.1 | |
| 0.00 | 1.16 | 0.00 | 0.81 | -17.95 | 101.92 | -37.43 | 124.75 | 0.7060 | -654.0 | -485.5 | |
| 0.00 | 1.96 | 0.00 | 1.37 | -17.50 | 101.75 | -37.60 | 124.08 | 0.7049 | -636.0 | -560.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
