SDO HMI 2014-09-07 14:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 222.74 | 959.39 | 151.75 | 659.14 | -13.76 | 95.15 | -38.71 | 118.70 | 0.6932 | -47.1 | -192.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-07 14:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.43 | 0.00 | 0.87 | -10.71 | 103.05 | -30.81 | 120.01 | 0.5834 | 609.0 | 515.6 | |
| 28.37 | 132.93 | 17.56 | 82.28 | -11.85 | 102.19 | -31.67 | 120.99 | 0.6017 | 1021.3 | 324.6 | |
| 1.87 | -2.00 | 1.17 | -2.00 | -11.73 | 101.66 | -32.20 | 120.39 | 0.6071 | 642.1 | 999999 | |
| 3.03 | -2.00 | 1.89 | -2.00 | -11.64 | 101.56 | -32.30 | 120.19 | 0.6077 | 665.9 | 999999 | |
| 1.07 | -2.00 | 0.67 | -2.00 | -11.36 | 101.45 | -32.41 | 119.70 | 0.6071 | 693.1 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.61 | -10.27 | 101.59 | -32.28 | 118.20 | 0.5984 | -771.0 | -648.1 | |
| 1.61 | 2.77 | 0.99 | 1.71 | -10.09 | 101.53 | -32.33 | 117.88 | 0.5978 | -733.3 | -549.0 | |
| 0.00 | 4.64 | 0.00 | 2.90 | -11.20 | 101.03 | -32.83 | 119.14 | 0.6111 | 841.0 | 647.0 | |
| 0.00 | 1.25 | 0.00 | 0.78 | -11.48 | 100.70 | -33.16 | 119.29 | 0.6169 | 505.0 | 350.0 | |
| 0.00 | 3.12 | 0.00 | 1.98 | -12.26 | 100.37 | -33.49 | 120.17 | 0.6259 | 676.0 | 563.7 | |
| 0.00 | 3.03 | 0.00 | 1.92 | -11.73 | 100.26 | -33.60 | 119.33 | 0.6238 | 583.0 | 585.5 | |
| 11.51 | 54.60 | 7.26 | 34.64 | -11.05 | 100.06 | -33.80 | 118.20 | 0.6219 | 902.0 | 445.1 | |
| 6.51 | 12.04 | 4.15 | 7.68 | -12.08 | 99.80 | -34.06 | 119.49 | 0.6314 | 773.8 | 552.5 | |
| 0.62 | -12.00 | 0.40 | -12.00 | -11.78 | 99.54 | -34.32 | 118.88 | 0.6325 | 599.7 | 999999 | |
| 14.81 | -12.00 | 9.41 | -12.00 | -11.21 | 99.59 | -34.27 | 118.10 | 0.6285 | 726.4 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.92 | -12.50 | 99.32 | -34.54 | 119.73 | 0.6396 | 475.0 | 307.4 | |
| 1.61 | -12.00 | 1.02 | -12.00 | -11.50 | 99.43 | -34.43 | 118.41 | 0.6321 | 466.2 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.80 | -12.22 | 99.29 | -34.57 | 119.31 | 0.6382 | 189.0 | 248.3 | |
| 0.00 | 1.07 | 0.00 | 0.69 | -11.94 | 99.07 | -34.79 | 118.77 | 0.6391 | 385.0 | 339.2 | |
| 0.00 | 0.54 | 0.00 | 0.34 | -11.53 | 99.02 | -34.84 | 118.16 | 0.6372 | 336.0 | 215.2 | |
| 3.12 | 14.45 | 2.01 | 9.33 | -11.90 | 98.77 | -35.09 | 118.51 | 0.6423 | 509.4 | 291.5 | |
| 0.54 | 1.61 | 0.35 | 1.05 | -12.54 | 98.33 | -35.53 | 119.08 | 0.6514 | 215.7 | 169.9 | |
| 0.00 | 1.43 | 0.00 | 0.91 | -10.29 | 98.66 | -35.20 | 116.16 | 0.6341 | 646.0 | 580.7 | |
| 0.00 | 1.07 | 0.00 | 0.69 | -11.90 | 98.43 | -35.43 | 118.26 | 0.6463 | 57.0 | 73.9 | |
| 0.80 | -21.00 | 0.52 | -21.00 | -11.59 | 98.33 | -35.53 | 117.76 | 0.6457 | 513.1 | 999999 | |
| 5.44 | 7.49 | 3.69 | 5.08 | -16.30 | 97.39 | -36.47 | 123.36 | 0.6855 | 698.6 | 501.0 | |
| 0.00 | 1.25 | 0.00 | 0.83 | -14.46 | 97.61 | -36.25 | 121.15 | 0.6714 | 622.0 | 534.1 | |
| 0.00 | 0.54 | 0.00 | 0.36 | -13.90 | 96.98 | -36.88 | 119.98 | 0.6749 | 655.0 | 597.7 | |
| 3.21 | 9.72 | 2.21 | 6.68 | -16.25 | 96.41 | -37.45 | 122.62 | 0.6954 | 730.9 | 561.4 | |
| 2.23 | -29.00 | 1.53 | -29.00 | -16.05 | 96.38 | -37.49 | 122.35 | 0.6946 | 803.3 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.78 | -14.11 | 96.78 | -37.08 | 120.12 | 0.6783 | 748.0 | 628.5 | |
| 0.00 | 2.14 | 0.00 | 1.48 | -16.70 | 96.11 | -37.75 | 122.97 | 0.7014 | 764.0 | 552.7 | |
| 0.00 | 1.25 | 0.00 | 0.84 | -13.92 | 96.70 | -37.16 | 119.82 | 0.6781 | 697.0 | 584.1 | |
| 0.00 | 1.52 | 0.00 | 1.02 | -14.32 | 96.58 | -37.28 | 120.26 | 0.6818 | 575.0 | 430.5 | |
| 0.71 | 1.70 | 0.48 | 1.14 | -13.73 | 96.62 | -37.24 | 119.52 | 0.6779 | 604.0 | 532.5 | |
| 0.00 | 1.87 | 0.00 | 1.26 | -14.13 | 96.50 | -37.36 | 119.96 | 0.6815 | 674.0 | 542.8 | |
| 1.61 | 4.37 | 1.11 | 3.03 | -16.38 | 95.94 | -37.92 | 122.47 | 0.7012 | 449.2 | 346.3 | |
| 0.00 | 4.55 | 0.00 | 3.17 | -16.79 | 95.81 | -38.06 | 122.88 | 0.7050 | 589.0 | 399.3 | |
| 0.71 | -37.00 | 0.49 | -37.00 | -16.22 | 95.90 | -37.96 | 122.24 | 0.7006 | 455.1 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.38 | -13.49 | 96.47 | -37.39 | 119.10 | 0.6782 | 429.0 | 237.8 | |
| 0.00 | 2.68 | 0.00 | 1.78 | -12.13 | 96.63 | -37.23 | 117.39 | 0.6685 | -859.0 | -661.8 | |
| 0.00 | 2.68 | 0.00 | 1.81 | -14.02 | 96.25 | -37.61 | 119.66 | 0.6837 | 713.0 | 511.3 | |
| 0.00 | 0.98 | 0.00 | 0.69 | -17.07 | 95.58 | -38.28 | 123.08 | 0.7091 | 287.0 | 203.0 | |
| 0.00 | 1.16 | 0.00 | 0.77 | -11.95 | 96.54 | -37.32 | 117.09 | 0.6685 | -215.0 | -192.3 | |
| 0.80 | 2.32 | 0.56 | 1.62 | -16.76 | 95.37 | -38.49 | 122.55 | 0.7094 | 216.9 | -2.2 | |
| 0.00 | 1.87 | 0.00 | 1.31 | -16.43 | 95.37 | -38.49 | 122.15 | 0.7074 | 480.0 | 312.8 | |
| 1.25 | 10.17 | 0.85 | 6.92 | -14.02 | 95.85 | -38.01 | 119.40 | 0.6880 | 606.9 | 18.7 | |
| 0.00 | 1.07 | 0.00 | 0.72 | -13.11 | 95.91 | -37.95 | 118.25 | 0.6823 | -750.0 | -608.2 | |
| 4.64 | 493.44 | 3.18 | 349.91 | -14.30 | 95.56 | -38.30 | 119.57 | 0.6929 | 674.3 | -352.3 | |
| 0.45 | 6.96 | 0.30 | 4.73 | -13.23 | 95.69 | -38.17 | 118.26 | 0.6854 | -855.6 | -766.2 | |
| 0.89 | -50.00 | 0.61 | -50.00 | -13.21 | 95.49 | -38.37 | 118.12 | 0.6874 | -884.7 | 999999 | |
| 0.71 | -49.00 | 0.49 | -49.00 | -14.17 | 95.23 | -38.64 | 119.19 | 0.6957 | 498.8 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.74 | -14.53 | 95.15 | -38.71 | 119.61 | 0.6986 | 423.0 | 375.4 | |
| 0.00 | 0.62 | 0.00 | 0.43 | -13.94 | 95.27 | -38.59 | 118.92 | 0.6939 | 242.0 | 234.7 | |
| 0.00 | 1.78 | 0.00 | 1.22 | -13.45 | 95.29 | -38.57 | 118.31 | 0.6911 | -762.0 | -694.0 | |
| 0.00 | 0.80 | 0.00 | 0.57 | -16.73 | 94.52 | -39.34 | 121.97 | 0.7179 | -538.0 | -448.6 | |
| 0.00 | 0.98 | 0.00 | 0.66 | -12.13 | 95.41 | -38.45 | 116.64 | 0.6824 | 346.0 | 238.3 | |
| 0.00 | 1.25 | 0.00 | 0.91 | -18.26 | 93.95 | -39.91 | 123.46 | 0.7326 | -572.0 | -495.5 | |
| 0.00 | 1.52 | 0.00 | 1.03 | -12.27 | 95.23 | -38.63 | 116.72 | 0.6853 | -645.0 | -574.1 | |
| 2.41 | -49.00 | 1.67 | -49.00 | -14.30 | 94.80 | -39.06 | 119.09 | 0.7011 | 368.9 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.89 | -16.65 | 94.26 | -39.61 | 121.71 | 0.7202 | 356.0 | 219.8 | |
| 0.00 | 1.25 | 0.00 | 0.84 | -11.79 | 95.27 | -38.59 | 116.10 | 0.6822 | 466.0 | 450.5 | |
| 2.50 | -49.00 | 1.74 | -49.00 | -14.48 | 94.56 | -39.30 | 119.18 | 0.7047 | 479.5 | 999999 | |
| 4.01 | 11.87 | 2.89 | 8.52 | -17.18 | 93.87 | -39.99 | 122.11 | 0.7271 | -723.7 | -491.9 | |
| 1.25 | -49.00 | 0.86 | -49.00 | -13.64 | 94.53 | -39.33 | 118.09 | 0.7005 | -851.9 | 999999 | |
| 0.00 | 3.30 | 0.00 | 2.27 | -13.13 | 94.59 | -39.27 | 117.45 | 0.6970 | -558.0 | -526.4 | |
| 0.00 | 1.16 | 0.00 | 0.78 | -11.19 | 94.86 | -39.00 | 115.05 | 0.6838 | -639.0 | -528.7 | |
| 0.00 | 1.25 | 0.00 | 0.92 | -18.42 | 92.90 | -40.96 | 122.99 | 0.7438 | -644.0 | -526.8 | |
| 0.00 | 1.78 | 0.00 | 1.32 | -18.50 | 92.75 | -41.11 | 122.99 | 0.7457 | -516.0 | -470.8 | |
| 7.67 | 25.60 | 5.59 | 18.73 | -17.12 | 93.01 | -40.85 | 121.50 | 0.7354 | -826.6 | -596.6 | |
| 0.00 | 1.34 | 0.00 | 0.91 | -11.01 | 94.33 | -39.53 | 114.51 | 0.6890 | -701.0 | -480.7 | |
| 13.65 | -49.00 | 9.71 | -49.00 | -15.06 | 93.45 | -40.41 | 119.23 | 0.7197 | 381.6 | 999999 | |
| 0.00 | 4.37 | 0.00 | 3.24 | -18.15 | 92.56 | -41.31 | 122.46 | 0.7457 | -510.0 | -544.3 | |
| 3.12 | -70.00 | 2.30 | -70.00 | -17.58 | 92.63 | -41.23 | 121.83 | 0.7418 | -725.2 | 999999 | |
| 36.93 | -49.00 | 26.12 | -49.00 | -14.04 | 93.27 | -40.60 | 117.84 | 0.7162 | -1060.5 | 999999 | |
| 0.80 | 3.39 | 0.59 | 2.51 | -17.71 | 92.34 | -41.52 | 121.80 | 0.7453 | -416.3 | -423.2 | |
| 2.32 | 65.93 | 1.61 | 45.90 | -12.22 | 93.59 | -40.27 | 115.69 | 0.7033 | -1088.1 | -488.6 | |
| 0.00 | 0.89 | 0.00 | 0.66 | -17.32 | 92.20 | -41.66 | 121.26 | 0.7447 | -379.0 | -336.4 | |
| 8.39 | -77.00 | 5.86 | -77.00 | -12.16 | 93.16 | -40.71 | 115.37 | 0.7079 | -743.4 | 999999 | |
| 6.24 | -49.00 | 4.49 | -49.00 | -14.62 | 92.51 | -41.35 | 118.14 | 0.7272 | -920.6 | 999999 | |
| 21.32 | -49.00 | 15.26 | -49.00 | -14.16 | 92.58 | -41.28 | 117.60 | 0.7242 | -824.8 | 999999 | |
| 0.00 | 1.78 | 0.00 | 1.26 | -12.99 | 92.79 | -41.07 | 116.23 | 0.7161 | -651.0 | -559.2 | |
| 1.61 | -49.00 | 1.16 | -49.00 | -14.61 | 92.31 | -41.55 | 118.01 | 0.7293 | -720.6 | 999999 | |
| 3.48 | -49.00 | 2.52 | -49.00 | -14.74 | 92.23 | -41.63 | 118.13 | 0.7308 | -550.7 | 999999 | |
| 3.39 | -49.00 | 2.44 | -49.00 | -14.45 | 92.26 | -41.60 | 117.78 | 0.7290 | -638.9 | 999999 | |
| 3.48 | -49.00 | 2.52 | -49.00 | -14.36 | 92.11 | -41.75 | 117.60 | 0.7302 | -452.0 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.77 | -12.83 | 92.03 | -41.83 | 115.62 | 0.7235 | -572.0 | -416.7 | |
| 0.00 | 0.98 | 0.00 | 0.73 | -15.94 | 91.21 | -42.65 | 119.02 | 0.7473 | 282.0 | 136.8 | |
| 0.80 | 1.78 | 0.60 | 1.32 | -15.18 | 90.89 | -42.97 | 117.93 | 0.7468 | -540.1 | -443.2 | |
| 0.00 | 1.25 | 0.00 | 0.90 | -12.83 | 91.32 | -42.54 | 115.24 | 0.7311 | -485.0 | -451.6 | |
| 1.25 | 10.17 | 0.92 | 7.51 | -14.54 | 90.89 | -42.98 | 117.14 | 0.7438 | -677.4 | -476.0 | |
| 0.00 | 1.16 | 0.00 | 0.86 | -15.01 | 90.68 | -43.18 | 117.61 | 0.7482 | -326.0 | -249.5 | |
| 0.00 | 3.03 | 0.00 | 2.21 | -12.82 | 91.02 | -42.84 | 115.08 | 0.7343 | -450.0 | -383.9 | |
| 0.00 | 2.94 | 0.00 | 2.19 | -14.67 | 90.51 | -43.35 | 117.10 | 0.7483 | -438.0 | -314.7 | |
| 0.00 | 1.25 | 0.00 | 0.93 | -14.60 | 90.18 | -43.68 | 116.84 | 0.7513 | -439.0 | -351.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
