SDO HMI 2014-09-09 00:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.39 | 37.73 | 7.33 | 22.08 | 9.37 | 147.47 | 32.33 | 276.08 | 0.5324 | 30.1 | -90.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-09 00:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.19 | 7.85 | 2.53 | 4.73 | 9.33 | 150.18 | 35.05 | 275.91 | 0.5719 | -725.7 | -603.7 | |
| 3.30 | 6.15 | 1.98 | 3.70 | 9.59 | 149.99 | 34.85 | 276.37 | 0.5692 | -823.7 | -627.4 | |
| 0.00 | 1.34 | 0.00 | 0.79 | 9.19 | 147.87 | 32.74 | 275.72 | 0.5387 | -744.0 | -598.1 | |
| 0.00 | 1.34 | 0.00 | 0.78 | 9.83 | 146.89 | 31.76 | 276.98 | 0.5246 | -633.0 | -456.6 | |
| 1.78 | 7.22 | 1.03 | 4.19 | 8.82 | 146.64 | 31.51 | 275.04 | 0.5206 | -766.1 | -629.9 | |
| 0.00 | 1.34 | 0.00 | 0.77 | 9.85 | 145.64 | 30.51 | 277.12 | 0.5061 | 560.0 | 431.0 | |
| 3.12 | 5.71 | 1.79 | 3.27 | 9.62 | 145.51 | 30.38 | 276.66 | 0.5040 | 846.6 | 616.4 | |
| 0.00 | 2.14 | 0.00 | 1.22 | 9.82 | 145.21 | 30.08 | 277.09 | 0.4996 | 921.0 | 801.8 | |
| 0.00 | 0.80 | 0.00 | 0.46 | 9.17 | 145.00 | 29.87 | 275.78 | 0.4962 | 557.0 | 519.6 | |
| 0.00 | 1.16 | 0.00 | 0.66 | 9.95 | 145.05 | 29.91 | 277.37 | 0.4973 | 836.0 | 660.7 | |
| 0.00 | 1.16 | 0.00 | 0.66 | 9.30 | 144.87 | 29.74 | 276.05 | 0.4943 | 903.0 | 775.2 | |
| 0.00 | 1.52 | 0.00 | 0.85 | 8.73 | 143.22 | 28.08 | 274.96 | 0.4690 | 802.0 | 564.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
