SDO HMI 2014-09-09 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.73 | 16.77 | 2.55 | 9.05 | 14.33 | 132.64 | 22.45 | 289.27 | 0.3968 | -316.1 | -67.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-09 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.16 | 0.00 | 0.65 | 20.84 | 135.01 | 24.82 | 302.08 | 0.4649 | -729.0 | -566.5 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 19.30 | 134.53 | 24.35 | 299.44 | 0.4486 | -667.0 | -549.1 | |
| 4.73 | 6.87 | 2.55 | 3.70 | 12.20 | 133.26 | 23.07 | 284.10 | 0.3966 | -1021.5 | -799.2 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 19.78 | 133.80 | 23.61 | 301.05 | 0.4418 | -773.0 | -643.1 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 18.09 | 132.75 | 22.56 | 298.42 | 0.4165 | -804.0 | -660.7 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 13.00 | 131.73 | 21.54 | 286.92 | 0.3756 | 762.0 | 609.1 | |
| 0.00 | 3.30 | 0.00 | 1.75 | 12.54 | 130.46 | 20.27 | 286.46 | 0.3542 | 787.0 | 619.4 | |
| 0.00 | 1.25 | 0.00 | 0.66 | 12.37 | 130.25 | 20.06 | 286.11 | 0.3503 | 1010.0 | 904.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
