SDO HMI 2014-09-09 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 255.18 | 1481.65 | 138.46 | 804.65 | 15.52 | 87.20 | -22.99 | 67.73 | 0.4091 | 254.5 | 23.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-09 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.45 | 0.00 | 0.23 | 8.27 | 93.37 | -16.82 | 85.37 | 0.2886 | -265.0 | -356.6 | |
| 0.00 | 1.43 | 0.00 | 0.75 | 16.04 | 91.57 | -18.62 | 62.57 | 0.3472 | -911.0 | -714.1 | |
| 0.00 | 1.16 | 0.00 | 0.62 | 17.87 | 91.32 | -18.87 | 58.20 | 0.3638 | -749.0 | -628.8 | |
| 0.00 | 4.91 | 0.00 | 2.61 | 17.10 | 90.43 | -19.76 | 61.12 | 0.3706 | 974.0 | 778.0 | |
| 0.00 | 0.89 | 0.00 | 0.47 | 14.86 | 90.49 | -19.70 | 66.79 | 0.3560 | -1002.0 | -716.6 | |
| 0.00 | 1.07 | 0.00 | 0.57 | 15.99 | 90.28 | -19.91 | 64.06 | 0.3656 | 753.0 | 589.0 | |
| 0.00 | 6.07 | 0.00 | 3.25 | 17.63 | 90.03 | -20.16 | 60.25 | 0.3799 | -454.0 | -382.7 | |
| 0.00 | 1.43 | 0.00 | 0.75 | 8.55 | 90.56 | -19.63 | 84.82 | 0.3351 | -851.0 | -686.6 | |
| 0.00 | 0.80 | 0.00 | 0.42 | 11.66 | 90.33 | -19.86 | 75.77 | 0.3448 | -677.0 | -686.6 | |
| 0.00 | 1.34 | 0.00 | 0.70 | 8.70 | 90.48 | -19.71 | 84.39 | 0.3364 | -749.0 | -668.1 | |
| 0.00 | 4.46 | 0.00 | 2.38 | 16.33 | 89.64 | -20.55 | 63.82 | 0.3770 | 282.0 | 399.4 | |
| 0.00 | 2.59 | 0.00 | 1.40 | 18.59 | 89.27 | -20.92 | 58.84 | 0.3971 | 568.0 | 500.6 | |
| 1.16 | 1163.59 | 0.62 | 632.24 | 15.56 | 89.59 | -20.60 | 65.79 | 0.3733 | -276.5 | 83.7 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 15.07 | 89.47 | -20.72 | 67.15 | 0.3723 | -618.0 | -421.4 | |
| 0.00 | 3.21 | 0.00 | 1.74 | 18.60 | 88.89 | -21.30 | 59.21 | 0.4024 | 909.0 | 655.8 | |
| 10.61 | 52.27 | 5.73 | 28.19 | 18.05 | 88.93 | -21.26 | 60.42 | 0.3981 | 1148.7 | 506.8 | |
| 0.45 | 20.87 | 0.24 | 11.12 | 13.51 | 89.35 | -20.84 | 71.30 | 0.3667 | -1153.6 | -655.1 | |
| 1.61 | -17.00 | 0.86 | -17.00 | 14.05 | 89.24 | -20.95 | 69.95 | 0.3709 | -946.8 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.62 | 14.41 | 89.20 | -20.99 | 69.04 | 0.3731 | 523.0 | 366.3 | |
| 1.16 | -17.00 | 0.62 | -17.00 | 13.90 | 89.22 | -20.97 | 70.37 | 0.3705 | -1226.0 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 12.26 | 89.29 | -20.90 | 74.68 | 0.3629 | -947.0 | -749.3 | |
| 0.00 | 1.25 | 0.00 | 0.68 | 18.65 | 88.54 | -21.64 | 59.46 | 0.4075 | -441.0 | -333.9 | |
| 0.00 | 1.43 | 0.00 | 0.76 | 12.40 | 89.15 | -21.04 | 74.36 | 0.3657 | -886.0 | -676.2 | |
| 0.00 | 1.43 | 0.00 | 0.78 | 20.43 | 88.19 | -22.00 | 56.00 | 0.4252 | 857.0 | 744.6 | |
| 2.23 | 4.46 | 1.19 | 2.37 | 12.70 | 89.06 | -21.13 | 73.62 | 0.3682 | -1075.4 | -814.8 | |
| 0.00 | 1.34 | 0.00 | 0.71 | 14.25 | 88.92 | -21.27 | 69.67 | 0.3766 | 562.0 | 273.2 | |
| 0.00 | 1.16 | 0.00 | 0.63 | 20.27 | 88.07 | -22.12 | 56.45 | 0.4255 | 885.0 | 808.8 | |
| 0.00 | 0.45 | 0.00 | 0.24 | 14.15 | 88.82 | -21.36 | 69.98 | 0.3776 | 388.0 | 444.4 | |
| 0.00 | 1.25 | 0.00 | 0.66 | 12.03 | 89.01 | -21.17 | 75.43 | 0.3666 | -978.0 | -696.9 | |
| 0.00 | 0.98 | 0.00 | 0.52 | 13.36 | 88.87 | -21.32 | 71.99 | 0.3736 | -891.0 | -798.3 | |
| 0.27 | -13.00 | 0.14 | -13.00 | 16.73 | 88.34 | -21.85 | 64.04 | 0.3981 | 1263.3 | 999999 | |
| 0.27 | -13.00 | 0.14 | -13.00 | 17.01 | 88.28 | -21.91 | 63.46 | 0.4006 | 1124.7 | 999999 | |
| 2.41 | -13.00 | 1.29 | -13.00 | 15.02 | 88.43 | -21.75 | 68.09 | 0.3875 | 689.6 | 999999 | |
| 0.71 | 17.93 | 0.38 | 9.59 | 13.78 | 88.56 | -21.63 | 71.13 | 0.3800 | -887.4 | -251.8 | |
| 0.80 | -34.00 | 0.43 | -34.00 | 13.38 | 88.56 | -21.63 | 72.14 | 0.3783 | 763.9 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.73 | 18.29 | 88.01 | -22.18 | 60.79 | 0.4124 | 794.0 | 600.9 | |
| 0.00 | 3.39 | 0.00 | 1.81 | 12.62 | 88.63 | -21.56 | 74.07 | 0.3745 | -531.0 | -444.3 | |
| 0.00 | 2.94 | 0.00 | 1.57 | 12.11 | 88.64 | -21.55 | 75.42 | 0.3726 | -411.0 | -631.9 | |
| 4.19 | -13.00 | 2.25 | -13.00 | 14.56 | 88.35 | -21.84 | 69.30 | 0.3866 | 889.3 | 999999 | |
| 5.62 | 21.85 | 3.06 | 11.92 | 18.83 | 87.83 | -22.36 | 59.76 | 0.4185 | 1022.3 | 452.0 | |
| 0.00 | 4.28 | 0.00 | 2.29 | 13.22 | 88.34 | -21.84 | 72.69 | 0.3810 | 249.0 | 136.7 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 13.73 | 88.30 | -21.89 | 71.40 | 0.3838 | -515.0 | -338.4 | |
| 98.11 | -13.00 | 52.94 | -13.00 | 15.86 | 88.00 | -22.19 | 66.39 | 0.3981 | 1369.3 | 999999 | |
| 0.00 | 5.26 | 0.00 | 2.87 | 18.24 | 87.64 | -22.55 | 61.24 | 0.4172 | 912.0 | 697.8 | |
| 2.14 | -13.00 | 1.16 | -13.00 | 16.95 | 87.74 | -22.45 | 64.05 | 0.4080 | 1001.5 | 999999 | |
| 0.00 | 1.78 | 0.00 | 0.96 | 13.51 | 88.12 | -22.07 | 72.08 | 0.3857 | -348.0 | -238.4 | |
| 2.68 | -40.00 | 1.46 | -40.00 | 18.85 | 87.38 | -22.81 | 60.16 | 0.4247 | 899.4 | 999999 | |
| 0.00 | 1.87 | 0.00 | 1.00 | 12.75 | 88.02 | -22.17 | 74.08 | 0.3844 | -1033.0 | -875.4 | |
| 0.00 | 1.96 | 0.00 | 1.05 | 13.60 | 87.94 | -22.25 | 71.97 | 0.3887 | 32.0 | -76.8 | |
| 53.96 | -13.00 | 29.25 | -13.00 | 16.48 | 87.59 | -22.60 | 65.25 | 0.4075 | 1214.7 | 999999 | |
| 0.00 | 1.78 | 0.00 | 0.98 | 18.80 | 87.07 | -23.11 | 60.54 | 0.4286 | 781.0 | 577.4 | |
| 0.00 | 6.87 | 0.00 | 3.69 | 12.70 | 87.69 | -22.50 | 74.36 | 0.3893 | -1169.0 | -867.9 | |
| 0.00 | 1.16 | 0.00 | 0.64 | 19.47 | 86.80 | -23.39 | 59.38 | 0.4367 | 624.0 | 426.0 | |
| 0.89 | 11.59 | 0.48 | 6.23 | 13.03 | 87.56 | -22.63 | 73.61 | 0.3924 | -853.0 | -337.5 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 19.34 | 86.79 | -23.40 | 59.65 | 0.4361 | 761.0 | 585.4 | |
| 0.00 | 0.98 | 0.00 | 0.54 | 19.55 | 86.61 | -23.58 | 59.38 | 0.4398 | 836.0 | 579.7 | |
| 0.00 | 0.71 | 0.00 | 0.39 | 20.26 | 86.50 | -23.69 | 58.03 | 0.4461 | 622.0 | 490.8 | |
| 0.00 | 2.23 | 0.00 | 1.22 | 18.14 | 86.75 | -23.44 | 62.25 | 0.4289 | 797.0 | 611.9 | |
| 0.00 | 2.14 | 0.00 | 1.17 | 17.71 | 86.78 | -23.41 | 63.17 | 0.4260 | 577.0 | 482.6 | |
| 0.00 | 2.50 | 0.00 | 1.37 | 17.46 | 86.78 | -23.41 | 63.71 | 0.4245 | 584.0 | 537.3 | |
| 0.00 | 0.89 | 0.00 | 0.50 | 20.83 | 85.95 | -24.24 | 57.41 | 0.4573 | 669.0 | 490.7 | |
| 0.00 | 1.25 | 0.00 | 0.67 | 10.97 | 87.04 | -23.15 | 79.01 | 0.3949 | -922.0 | -751.2 | |
| 0.00 | 2.94 | 0.00 | 1.64 | 20.35 | 85.82 | -24.37 | 58.47 | 0.4558 | 650.0 | 564.1 | |
| 0.00 | 4.10 | 0.00 | 2.22 | 11.13 | 86.65 | -23.54 | 78.72 | 0.4012 | -932.0 | -706.1 | |
| 0.00 | 1.25 | 0.00 | 0.68 | 12.46 | 86.47 | -23.72 | 75.53 | 0.4074 | -964.0 | -800.9 | |
| 0.45 | 2.05 | 0.24 | 1.11 | 13.12 | 86.33 | -23.86 | 74.00 | 0.4115 | -1067.0 | -801.4 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 11.16 | 86.45 | -23.74 | 78.73 | 0.4044 | -829.0 | -676.4 | |
| 0.00 | 2.50 | 0.00 | 1.35 | 11.21 | 86.24 | -23.95 | 78.67 | 0.4078 | -738.0 | -600.1 | |
| 2.32 | -13.00 | 1.27 | -13.00 | 14.50 | 85.74 | -24.45 | 71.10 | 0.4253 | -1286.0 | 999999 | |
| 3.39 | 8.92 | 1.85 | 4.86 | 13.01 | 85.90 | -24.29 | 74.47 | 0.4177 | -969.6 | -749.8 | |
| 0.00 | 0.80 | 0.00 | 0.44 | 11.07 | 85.99 | -24.20 | 79.08 | 0.4115 | -700.0 | -569.8 | |
| 0.00 | 0.98 | 0.00 | 0.54 | 12.87 | 85.54 | -24.65 | 74.95 | 0.4227 | -669.0 | -597.1 | |
| 3.12 | -13.00 | 1.72 | -13.00 | 15.14 | 85.21 | -24.97 | 69.94 | 0.4357 | -1204.0 | 999999 | |
| 22.65 | -13.00 | 12.41 | -13.00 | 13.59 | 85.33 | -24.86 | 73.38 | 0.4282 | -1085.9 | 999999 | |
| 2.59 | -13.00 | 1.42 | -13.00 | 14.47 | 85.23 | -24.96 | 71.44 | 0.4329 | -1111.9 | 999999 | |
| 2.76 | -13.00 | 1.52 | -13.00 | 14.08 | 85.24 | -24.95 | 72.33 | 0.4312 | -1060.4 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.44 | 12.80 | 85.31 | -24.88 | 75.22 | 0.4261 | -755.0 | -608.4 | |
| 14.36 | -13.00 | 7.90 | -13.00 | 14.64 | 85.03 | -25.15 | 71.15 | 0.4364 | -1187.0 | 999999 | |
| 2.85 | -13.00 | 1.57 | -13.00 | 14.89 | 85.00 | -25.18 | 70.63 | 0.4378 | -1149.2 | 999999 | |
| 2.94 | -13.00 | 1.63 | -13.00 | 16.10 | 84.85 | -25.34 | 68.05 | 0.4452 | -904.2 | 999999 | |
| 0.00 | 1.78 | 0.00 | 0.98 | 12.64 | 85.26 | -24.93 | 75.60 | 0.4264 | -761.0 | -702.5 | |
| 0.45 | -13.00 | 0.25 | -13.00 | 15.25 | 84.89 | -25.30 | 69.89 | 0.4409 | -1038.4 | 999999 | |
| 4.99 | -13.00 | 2.76 | -13.00 | 15.49 | 84.79 | -25.40 | 69.43 | 0.4434 | -1240.8 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 16.68 | 84.63 | -25.56 | 66.97 | 0.4510 | -848.0 | -697.1 | |
| 0.00 | 3.48 | 0.00 | 1.92 | 14.18 | 84.81 | -25.37 | 72.31 | 0.4379 | -833.0 | -653.7 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 12.75 | 84.91 | -25.28 | 75.50 | 0.4321 | -962.0 | -844.6 | |
| 0.00 | 2.14 | 0.00 | 1.17 | 11.93 | 84.92 | -25.27 | 77.38 | 0.4298 | -831.0 | -739.3 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 16.05 | 84.37 | -25.82 | 68.47 | 0.4519 | -997.0 | -758.7 | |
| 0.00 | 1.69 | 0.00 | 0.94 | 16.44 | 84.24 | -25.95 | 67.71 | 0.4554 | -1015.0 | -835.8 | |
| 0.00 | 0.89 | 0.00 | 0.50 | 16.16 | 84.18 | -26.01 | 68.34 | 0.4551 | -699.0 | -549.3 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 11.37 | 84.70 | -25.49 | 78.74 | 0.4319 | -881.0 | -724.9 | |
| 0.00 | 1.25 | 0.00 | 0.69 | 11.67 | 84.67 | -25.52 | 78.05 | 0.4330 | -676.0 | -528.1 | |
| 0.00 | 4.55 | 0.00 | 2.53 | 15.91 | 84.14 | -26.05 | 68.89 | 0.4546 | -604.0 | -751.3 | |
| 0.45 | 38.62 | 0.25 | 21.27 | 12.33 | 84.50 | -25.69 | 76.60 | 0.4371 | -990.0 | -713.6 | |
| 0.00 | 0.89 | 0.00 | 0.50 | 16.51 | 83.88 | -26.31 | 67.78 | 0.4609 | -533.0 | -348.5 | |
| 0.00 | 0.71 | 0.00 | 0.39 | 11.87 | 84.41 | -25.78 | 77.68 | 0.4374 | -659.0 | -538.4 | |
| 0.00 | 3.30 | 0.00 | 1.84 | 16.17 | 83.79 | -26.40 | 68.55 | 0.4607 | -447.0 | -452.0 | |
| 0.00 | 1.34 | 0.00 | 0.74 | 13.56 | 84.09 | -26.10 | 74.02 | 0.4467 | -688.0 | -498.0 | |
| 2.05 | -94.00 | 1.13 | -94.00 | 12.59 | 84.13 | -26.06 | 76.16 | 0.4434 | -795.8 | 999999 | |
| 0.54 | -94.00 | 0.30 | -94.00 | 12.77 | 84.08 | -26.11 | 75.78 | 0.4446 | -736.8 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 13.10 | 84.04 | -26.15 | 75.05 | 0.4461 | -628.0 | -524.2 | |
| 0.00 | 0.54 | 0.00 | 0.30 | 13.61 | 83.95 | -26.24 | 73.96 | 0.4490 | -393.0 | -376.3 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 13.76 | 83.89 | -26.29 | 73.65 | 0.4502 | -699.0 | -608.5 | |
| 0.00 | 0.27 | 0.00 | 0.15 | 17.87 | 83.32 | -26.87 | 65.36 | 0.4752 | 761.0 | 757.3 | |
| 0.00 | 1.43 | 0.00 | 0.80 | 17.80 | 83.18 | -27.00 | 65.58 | 0.4767 | 801.0 | 635.6 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 13.18 | 83.82 | -26.36 | 74.96 | 0.4496 | -518.0 | -399.7 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 12.22 | 83.62 | -26.57 | 77.14 | 0.4503 | -524.0 | -431.9 | |
| 0.00 | 1.25 | 0.00 | 0.70 | 15.65 | 83.16 | -27.03 | 69.98 | 0.4677 | -770.0 | -660.6 | |
| 0.00 | 1.69 | 0.00 | 0.95 | 15.83 | 83.10 | -27.09 | 69.64 | 0.4693 | -602.0 | -504.5 | |
| 0.00 | 1.07 | 0.00 | 0.61 | 17.89 | 82.49 | -27.70 | 65.84 | 0.4868 | 731.0 | 569.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
